Charging System 2 illustrations ~308 words

MALFUNCTION INDICATOR

The IC regulator warning function activates to illuminate "CHARGE" warning lamp, if excessive voltage is produced or no voltage is produced while generator is operating.

No Charging Voltage Or Diode Ripple Not Detected

  1. Is charging lamp on with the ignition switch in the ON position? If yes, then go to next step. If no, then go to «DIAGNOSTIC PROCEDURE 1»(ref-166067-S23352882132004091000000) under ON-VEHICLE TESTING. Repair if needed and if okay, then replace generator.
  2. Is charging lamp on with engine running at idle? If yes, then go to next step. If no, then go to «DIAGNOSTIC PROCEDURE 2»(ref-166067-S17476601912004091000000) under ON-VEHICLE TESTING. Repair if needed and if okay, then replace generator.
  3. Is charging lamp on with engine running at 3000 RPM? If yes, then go to next step. If no, then go to «DIAGNOSTIC PROCEDURE 3»(ref-166067-S05111871572004091000000) under ON-VEHICLE TESTING. If needed repair and if okay then replace the generator.
  4. Check generator drive belt tension. Repair if needed and if okay then replace the generator.

Low Charging Voltage

  1. Go to «DIAGNOSTIC PROCEDURE 4»(ref-166067-S03240149312004091300000) under ON-VEHICLE TESTING. Repair as needed and okay then go to next step.
  2. Check generator drive belt tension. Repair as needed and if okay then replace generator.

High Charge Voltage

Go to DIAGNOSTIC PROCEDURE 5 under ON-VEHICLE TESTING. Repair as needed and if okay then replace generator.

FX35

For overhaul (Scheme 16)

Scheme 16

Scheme 16: FX35

FX45

For overhaul (Scheme 17)

Scheme 17

Scheme 17: FX45
ApplicationSpecification
Generator ModelA3TG0191, MITSUBISHI
Nominal Rating12 Volts, 110 Amps
Ground PolarityNegative
Minimum RPM Under No Load (With 13.5 Volts Applied)1000 RPM
Hot Output Current (With 13.5 Volts Applied)
At 1300 RPM37 Amps
At 2500 RPM92 Amps
At 5000 RPM103 Amps
Regulated Output Voltage14.1-14.7 Volts
Minimum Brush Length.197 in. (5.00 mm)
Brush Spring Pressure17.62-21.94 ozs. (4.9-6.1 N)
Slip Ring Minimum Outer Diameter.870 in. (22.1 mm)
Rotor (Field Coil) Resistance1.7-2.1 Ohms

GENERATOR SPECIFICATIONS (FX35)

ApplicationSpecification
Generator ModelLR1110-716, HITACHI
Nominal Rating12 Volts, 110 Amps
Ground PolarityNegative
Minimum RPM Under No Load (With 13.5 Volts Applied)1100 RPM
Hot Output Current (With 13.5 Volts Applied)
At 1800 RPM70 Amps
At 2500 RPM91 Amps
At 5000 RPM110 Amps
Regulated Output Voltage14.1-14.7 Volts
Minimum Brush Length.236 in. (6.00 mm)
Brush Spring Pressure3.60-12.34 ozs. (1.000-3.432 N)
Slip Ring Minimum Outer Diameter1.024 in. (26.00 mm)
Rotor (Field Coil) Resistance2.31 Ohms

GENERATOR SPECIFICATIONS (FX45)

ApplicationFt. Lbs. (N.m)
Generator Mounting Bolt
Lower21 (28)
Upper48 (65)
Generator Stay Mounting Bolt21 (28)
Pulley Nut87 (118)
INCH Lbs. (N.m)
"B" Terminal Nut89 (10)
Through Bolt & Nut35 (4)

TORQUE SPECIFICATIONS (FX35)

ApplicationFt. Lbs. (N.m)
Generator Mounting Bolt
Lower21 (28)
Upper37 (50)
Generator Stay Mounting Bolt17 (23)
Pulley Nut54 (73)
INCH Lbs. (N.m)
"B" Terminal Nut89 (10)
Ground Harness Bolt18 (2)
Through Bolt & Nut35 (4)

TORQUE SPECIFICATIONS (FX45)

For wiring diagram, see CHARGING SYSTEM under STARTING/CHARGING in SYSTEM WIRING DIAGRAMS article in ELECTRICAL.

For wiring diagram, see CHARGING SYSTEM under STARTING/CHARGING in SYSTEM WIRING DIAGRAMS article in ELECTRICAL.

For wiring diagram, see CHARGING SYSTEM under STARTING/CHARGING in SYSTEM WIRING DIAGRAMS article in ELECTRICAL.

For wiring diagram, see CHARGING SYSTEM under STARTING/CHARGING in SYSTEM WIRING DIAGRAMS article in ELECTRICAL.
