Body Control Module (BCM): Specifications Hyundai Veloster I

Communication Devices 9 illustrations ~371 words

Specifications

ItemsSpecifications
Rated voltageDC 12V
Operating voltageDC 9 ~ 16V
Operating temperature22°F~167°F (-30°C~ 75°C)
Dark currentBCM & Receiver: 5.0mA or less BCM: 4mA or less

Scheme 1

Scheme 1: Components

* Internal Buzzer: Rear parking assist system buzzer

No. Connector A Connector B Connector C Connector D 1 - Assist door unlock switch Power GND 1 Key sol 2 - Driver door unlock switch Power GND 2 Autolight switch 3 - Door key lock switch Rear washer switch Key IN 4 - Driver key unlock switch From wiper mist switch RPAS off switch 5 - Tailgate open switch CAN H Key interlock switch 6 Front fog relay Rear right door unlock switch CAN L Driver door unlock relay 7 Rear defogger relay Power window door lock switch Rear defogger switch - 8 - Assit key unlock switch Turn signal LH switch - 9 - Assit seal belt switch Hazard switch - 10 Front wiper relay Driver seal bell switch Tailgate release switch - 11 Reserved output 2 Power window door unlock switch Tail lamp switch - 12 Hood switch - Turn signal RH switch AV tail lamp 13 ATM sol - Vehicle info - 14 - - Front wiper INT switch - 15 - MT "R" Rear Wiper INT switch Head lamp low signal 16 - Reserved Input 1 Rear wiper mist switch DRL (EC) relay 17 - Assit door switch From wiper INT volume - 18 - Driver door switch Front washer switch Autolight power 19 - Rear right door switch TMU req Autolight sensor 20 Reserved input 2 Rear loft door switch Burglar horn relay K Line communication 21 Brake switch RPAS Head lamp high switch Tailgate lamp 22 - Safety power window enable Crash unlock RPAS buzzer 23 - Reserved output 1 Front fog switch Room lamp 24 - Rear fog relay Head lamp low switch Rear fog switch 25 Rear wiper relay CAN DRL option 26 - - 27 - Reserved input 3 28 - - 29 - RPAS off IND 30 - - 31 Real left door unlock switch Assit seat belt IND 32 Side airbag option Reserved output 3 33 - 34 - 35 - 36 - 37 - 38 - 39 - 40 Autolight ground

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

BCM (IPM) Input Signal Specification

NoSignal NameDescriptionON/OFF LEVEL(V)Remark
A01L_B+ON = BAT9V~16V
A02L_IGN1ON = BAT (IGN KEY=ON or Start Position)7V or more/4V or less
A03L_IGN2ON = BAT (IGN KEY=ON7V or more/4V or less
A04L_Brake SWON = GND7V or more/4V or less
A05L_MIST SWON = BAT7V or more/4V or less
A06L_CRASH UNLOCK INPUT (PWM)PWM
A07L_HeadLamp LOW SWON = GND2V or less/OPEN (Reference value: 4V or more)
A08L_HeadLamp HIGH SWON = GND2V or less/OPEN (Reference value: 4V or more)
A13L_ACCON = BAT7V or more/4V or less
A16L_INH'R' SWON = BAT7V or more/4V or less
A17L_WASHER SWON = BAT7V or more/4V or less
A18L_WIPER INT SWON = BAT7V or more/4V or less
A20A_Wiper Int VolumeA/D
A21L_KEY IN SWON = GND2V or less/OPEN (Reference value: 4V or more)
A22L_TAIL LAMP SWON = GND2V or less/OPEN (Reference value: 4V or more)
A23L_KEY INTER LOCK SWON = OPEN2V or less/OPEN (Reference value: 4V or more)
B01LIN (RPAS)Communication
B03L_FRONT FOG Lamp SWON = GND2V or less/OPEN (Reference value: 4V or more)
B04L_SIDE AIR OPTON = GND2V or less/OPEN (Reference value: 4V or more)
B08CAN (HIGH)Communication
B09CAN (LOW)Communication
B11A_AUTO LIGHT SIGNALA/D
B13L_AUTO LIGHT SWON = GND2V or less/OPEN (Reference value: 4V or more)
B14DIAGNOSIS (K-Line)Communication
B15L_DEFOGGER SWON = GND2V or less/OPEN (Reference value: 4V or more)

Scheme 6

Scheme 6: Circuit Diagram

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9
