Body Control Module (BCM): Other Hyundai Veloster I

Communication Devices 7 illustrations ~626 words

Signal Characteristics

SymbolName
L_Logic input
A_Analog input
O_Logic output
C_CAN signal
S_Serial communication
P_PW signal and frequency signal
D_Data signal
V_Power and ground supply
B_Internal variable
B_Body

The IPM provides the following features

  1. Wiper & Washer control
  2. Lamp control
  3. Buzzer control
  4. Timer control
  5. Door lock/unlock control
  6. Tailgate release control
  7. Turn hazard control
  8. RKE control
  9. Panic alarm flashing control

Scheme 10

Scheme 10: CAN Communication Network

Scheme 11

Scheme 11: LIN Communication Network

Functions

  1. Wiper control Front Wiper Mist Control Function Front Wiper Intermittent Control Function Front Wiper Washer Control Function Front Wiper Washer Control Function Rear Wiper On Switch Control Rear Washer Wiper Control Rear Wiper Intermittent Control
  2. Lamp control Tail Lamp by Switch Control Function Tail Lamp by Auto Light Control Function Tail Lamp by Escort Control Function Tail Lamp by Welcome Control Function Tail Lamp Auto cut Control Function Output control of Tail Lamp Head Lamp Low by Switch Control Function Head Lamp Low by Escort Control Function Head Lamp Low by Welcome Control Function Head Lamp Low by Auto Light Control Function Head Lamp High by Switch Control Function Head Lamp High and Low by Passing Switch Control Function Output Control of Head Lamp Low Output Control of Head Lamp High Output Control of Head Lamp High Indicator EC DRL Lamp Function Tail Lamp Control by Auto light Mode Control Function Head Lamp Low Control by Auto light Mode Control Function AV Tail Control by Auto Light sensor level Control Function Front Fog Lamp by Switch Control Function Rear Fog Lamp by Switch Control Function Room Lamp On/Off/Decaying Control Function Tail Gate Lamp On/Off Control Function
  3. Buzzer control Internal Buzzer Control Function SBW/SBR Function Key Reminder warning (Key Operated Warning) Control Function RKE Teaching Sound Function SMK System warning Control Function
  4. Timer control Rear Defogger Control Function Power Window Main Timer Control Function
  5. Door lock/unlock control Central Door Lock/Unlock Switch Control Function Central Door Lock/Unlock Mechanical Key (Door Key) Control Function Doors Lock/Unlock by RKE Doors Lock/Unlock by SMK Doors Relock by ATWS Function Doors Lock/Unlock by Auto Door Doors Unlock by Crash Doors Unlock by Key Reminder Dead lock/unlock Function Doors Unlock by MTS RKE Door Lock/Unlocking Function Burglar Alarm Relock Door Lock Control Function SMK Door Lock/Unlocking Function Central Door Lock/Unlock Button Control Function Crash Unlock Control Function Door Lock by Shift-Lever Door Lock by Vehicle Speed Door Unlock by Shift-Lever Door Unlock by Key Off Key Reminder Unlock Function Dead Lock/Unlock Function Central Unlocking by EC Unlock Control Function Priority of Door Lock System Shift Lever MT Option Function
  6. Tailgate release control
  7. Turn hazard control Hazard Control Function Turn Signal Control Function Flasher Failure Control Function Burglar Alarm Function Panic Flashing Control Function Tailgate Flashing Control Function RKE Two Turn Unlock Set/Reset Flashing Control Function Emergency Stop Release Flasher Function Flasher Function Priority Control Function
  8. RKE control RF Communication Function RKE (Transmitter) Function Two Turn Unlock RKE Set/Reset Receiver & IPM Control Function IPM RF Control Function RKE Teaching RKE Resynchronization
  9. Panic alarm flashing control
  10. User option Auto Door Lock/Unlock, Two turn unlock, Horn answer back, Head lamp escort, Auto triple turn

Scheme 12

Scheme 12: Removal
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel. (Refer to " «CRASH PAD»(ref-609328-S38971345422014041600000) ")
  3. Disconnect the IPM connectors, loosening the nut (2EA) and the bolt (1EA), then remove the IPM.
  4. The installation is the reverse order of removal.

Scheme 13

Scheme 13: IPM Diagnosis With GDS

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16
  1. It will be able to diagnose defects of IPM with GDS quickly. GDS can operates actuator manually, input/output value monitoring and self diagnosis.
  2. Select model and "IPM".
  3. Select the module to check.
  4. Select "Input/output monitoring", if you will check current data of body network system. It provides input/output status of each module.
  5. If you will check each module data operation manually, select "Actuation test".
  6. To check the DTC of the each module, select "DIAGNOSTIC TROUBLE CODES".
  7. If you want to change user option, select "user option".
