Replacement
Note. ATF of 6 speed automatic transaxle doesn't be replaced. But, if the vehicle is severe use or business use, replace ATF every 60, 000 miles for severe usage. Severe usage is defined as Driving in rough road (Bumpy, Gravel, Snowy, Unpaved road, etc.) Driving in mountain road, ascent/descent Repetition of short distance driving More than 50% operation in heavy city traffic during hot weather above 32° C (89.6° F). Police, Taxi, Commercial type operation or trailer towing, etc.
Scheme 48
- Remove the drain plug (A) and reinstall the drain plug after draining ATF totally. Drain plug tightening torque: 38.2 ~ 48.1 N.m (3.9 ~ 4.9 kgf.m, 28.2 ~ 35.4 lb-ft) CAUTION: The gasket of the drain plug use new one.
- Fill the oil about 5 liters.
- Check the oil level. (Refer to " «FLUID»(ref-609330-S05163393972014041600000) ")
Installation
- Install in the reverse order of removal. NOTE: Adding Automatic Transaxle Fluid (ATF). (Refer to " «FLUID»(ref-609330-S05163393972014041600000) ") Perform Transaxle Control Module (TCM) learning after replacing the valve body to prevent slow transaxle response, jerky acceleration and jerky startup. (Refer to «Repair Procedures»(ref-609332-S10769763752014041600000) ) .
