Automatic Transaxle Control System: Removal & Installation Hyundai Veloster I

Automatic Trans 10 illustrations ~911 words

Replacement

Note. When replacing the Transaxle Control Module (TCM), the vehicle equipped with immobilizer must be performed the procedure as below. [In the case of installing used TCM] Perform "TCM neutralization mode" procedure with GDS. Insert the key and turn it to the IGN ON and OFF position. Then the TCM key register process is completed automatically. [In the case of installing new TCM]- Insert the key and turn it to the IGN ON and OFF position. Then the TCM key register process is completed automatically.

Scheme 135

Scheme 135: Replacement
Scheme 135: Replacement

Scheme 136

Scheme 136
Scheme 136
  1. Turn ignition switch OFF.
  2. Disconnect the negative (-) battery cable.
  3. Disconnect the TCM connector (A).
  4. Remove the TCM (A) after removing the mounting bolts and nut. TCM installation bolt/nut: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)

Installation

Note. In the case of the vehicle equipped with immobilizer or button engine start system, perform "Key Teaching" procedure together. (Refer to TEACHING PROCEDURES .

  1. Install in the reverse order of removal.
  1. Install in the reverse order of removal. NOTE: Adding Automatic Transaxle Fluid (ATF). (Refer to " «FLUID»(ref-609330-S05163393972014041600000) ") Perform Transaxle Control Module (TCM) learning after replacing the valve body to prevent slow transaxle response, jerky acceleration and jerky startup. (Refer to Automatic Transaxle Control System - " «REPAIR PROCEDURES»(ref-609332-S30256913832014041600000) ")
  1. Install in the reverse order of removal. NOTE: Adding Automatic Transaxle Fluid (ATF). (Refer to " «FLUID»(ref-609330-S05163393972014041600000) ") Perform Transaxle Control Module (TCM) learning after replacing the valve body to prevent slow transaxle response, jerky acceleration and jerky startup. (Refer to Automatic Transaxle Control System - " «Repair Procedures»(ref-609332-S35268241552014041600000) ")
  1. Install in the reverse order of removal. NOTE: Adding Automatic Transaxle Fluid (ATF). (Refer to " «FLUID»(ref-609330-S05163393972014041600000) ") Perform Transaxle Control Module (TCM) learning after replacing the valve body to prevent slow transaxle response, jerky acceleration and jerky startup. (Refer to Automatic Transaxle Control System - " «REPAIR PROCEDURES»(ref-609332-S24065859212014041600000) ")
  1. Install in the reverse order of removal. NOTE: Adding Automatic Transaxle Fluid (ATF). (Refer to " «FLUID»(ref-609330-S05163393972014041600000) ") Perform Transaxle Control Module (TCM) learning after replacing the valve body to prevent slow transaxle response, jerky acceleration and jerky startup. (Refer to Automatic Transaxle Control System - " «REPAIR PROCEDURES»(ref-609332-S09844339562014041600000) ")

Removal

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY ")

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY ")

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY ")

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY ")

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY ")

  1. Install in the reverse order of removal. NOTE: Adding coolant. (Refer to " «COOLANT»(ref-609294-S25286250992014041600000) ") Adding Automatic Transaxle Fluid (ATF). (Refer to " «FLUID»(ref-609330-S05163393972014041600000) ") Perform Transaxle Control Module (TCM) learning after replacing the valve body to prevent slow transaxle response, jerky acceleration and jerky startup. (Refer to Automatic Transaxle Control System - " «Repair Procedures»(ref-609332-S14977337942014041600000) ")
  1. Install in the reverse order of removal. NOTE: Adding coolant. (Refer to " «COOLANT»(ref-609294-S25286250992014041600000) ") Adding Automatic Transaxle Fluid (ATF). (Refer to " «FLUID»(ref-609330-S05163393972014041600000) ") Perform Transaxle Control Module (TCM) learning after replacing the valve body to prevent slow transaxle response, jerky acceleration and jerky startup. (Refer to Automatic Transaxle Control System - " «Repair Procedures»(ref-609332-S07968207062014041600000) ")
  1. Install in the reverse order of removal.

Scheme 137

Scheme 137: Components
Scheme 137: Components

Scheme 138

Scheme 138: Removal
Scheme 138: Removal

Scheme 139

Scheme 139
Scheme 139

Scheme 140

Scheme 140
Scheme 140
  1. Remove the floor console. (Refer to «CONSOLE»(ref-609328-S41528823382014041600000) .
  2. Disconnect sports mode connector (A).
  3. Disconnect the shift cable (A).
  4. Remove the shift lever assembly (A) by removing the bolts (C-4ea). Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
  1. Install in the reverse order of removal. CAUTION: Set shift lever and inhibitor switch manual control lever to "N" position.

Scheme 141

Scheme 141: Components
Scheme 141: Components

Scheme 142

Scheme 142: Removal
Scheme 142: Removal

Scheme 143

Scheme 143
Scheme 143

Scheme 144

Scheme 144
Scheme 144
  1. Remove the floor console. (Refer to «CONSOLE»(ref-609328-S41528823382014041600000) .
  2. Disconnect the shift cable (A).
  3. Remove the retainer (A) and nut (B). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
  4. Remove the nut (C) from the manual control lever. Tightening torque: 14.7 ~ 21.6 N.m (1.5 ~ 2.2 kgf.m, 10.9 ~ 15.9 lb-ft)
  5. Remove the cable (B) from the bracket (A) at transaxle assembly side.
  6. Remove the shift cable by pulling it toward the interior.
  1. Install in the reverse order of removal. CAUTION: Set shift lever and inhibitor switch manual control lever to "N" position.
