Automatic Transaxle Control System: Adjustments Hyundai Veloster I

Adjustment

Adjusting method for T/M control cable

Scheme 132

1. Set room side shift lever and T/M side manual control lever to "N" position.
2. Connect room side shift lever and shift cable.
3. Push cable to "F" direction illustrated to eliminate FREE PLAY.
4. Tighten adjusting nut (A). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
5. After adjusting according check to be sure that this part operates surely at each range of T/M side corresponding to each position of shift lever.
