Automatic Transaxle System: Diagnosis Hyundai Tucson I

INSPECTION CHART FOR TROUBLE SYMPTOMS

INSPECTION CHART FOR TROUBLE SYMPTOMS

SCAN TOOL FUNCTION

Scan tool offers the following functionality

Diagnostic trouble codes

Freeze frame data

Current data

Actuation test

SERVICE DATA LIST (WITH SCAN TOOL)

ITEM DATA DESCRIPTION

ACTUATOR INSPECTION

ITEM CONDITION CHART

ROAD TEST

ITEM CONDITION CHART

STANDARD HYDRAULIC PRESSURE TEST

STANDARD HYDRAULIC PRESSURE TEST REFERENCE CHART

* The values are subject to change according to vehicle model or condition

Scheme 36

HYDRAULIC PRESSURE TEST DIAGNOSIS TABLE

HYDRAULIC PRESSURE TEST DIAGNOSIS TABLE

Scheme 37

1. Drive the vehicle until the fluid reaches normal operating temperature [70~80°C].
2. Place the vehicle on a level surface.
3. Move the selector lever through all gear position. This will fill the torque converter and the hydraulic system with fluid and move the selector lever to the "N" (Neutral) position.
4. Before removing the oil level gauge, wipe all contaminants from around the oil level gauge. Then take out the oil level gauge and check the condition of the fluid. NOTE: If the fluid smells as if it is burning, it means that the fluid has been contaminated by fine particles from the bushes and friction materials, a transaxle overhaul may be necessary.
5. Check that the fluid level is at the HOT mark on the oil level gauge. If the fluid level is low, automatic transaxle fluid until the level reaches the "HOT" mark. Auto transaxle fluid: DIAMOND ATF SP-III, SK ATF SP-III Quantity: 7.8 l (8.2 US qt, 6.9 Imp.qt) NOTE: Low fluid level can cause a variety of a abnormal conditions because it allows the pump to take in air along with fluid. Air trapped in the hydraulic system forms bubbles, which are compressible. Therefore, pressures will be erratic, causing delayed shifting, slipping clutches and brakes, etc. Improper filling can also raise fluid level too high. When the transaxle has too much fluid, gears churn up foam and cause the same conditions which occur with low fluid level, resulting in accelerated deterioration of automatic transaxle fluid. In either case, air bubbles can cause overheating, and fluid oxidation, which can interfere with normal valve, clutch, and brake operation. Foaming can also result in fluid escaping from the transaxle vent sheer it may be mistaken for a leak.
6. Insert the oil level gauge (A) securely. NOTE: When new, automatic transmission fluid should be red. The red dye is added so the assembly plant can identify it as transmission fluid and distinguish it from engine oil or antifreeze. The red dye, which is not an indicator of fluid quality, is not permanent. As the vehicle is driven the transmission fluid will begin to look darker. The color may eventually appear light brown.

DTC DETECTING CONDITION

DTC DETECTING CONDITION CHART

Scheme 38

1. Ignition "ON" Engine "OFF".
2. Disconnect the "C24-2" of TCM connector.
3. Measure the voltage between terminal "8" of the "C24-2" of TCM harness connector and chassis ground. Specification: Approx. B+
4. Is voltage within specifications? YES : --> Fault is intermittent caused by poor contact in the sensor's and/or TCM's connector or was repaired and TCM memory was not cleared. And Go to «COMPONENT INSPECTION»(ref-276745-S20669096092008011000000) procedure. NO : --> Check the Fuse 37-10A is installed or not blown. --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30340310842008011000000) " procedure.

COMPONENT INSPECTION

1. Connect scantool to data link connector.
2. Ignition "ON" & Engine "OFF".
3. Monitor the "DTC".
4. Is DTC Re-displayed? YES : --> Substitute with a known-good TCM and check for proper operation. If the problem is corrected, replace TCM as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30340310842008011000000) " procedure. NO : --> Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30340310842008011000000) " procedure.

DTC DETECTING CONDITION CHART

1. Ignition "ON" & Engine "OFF".
2. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
3. Using a scan tool, Clear DTC.
4. Using a "SCAN TOOL", Operate "LEARNING" Reset.
5. Perform the "LEARNING"
6. IG OFF - IG ON (Repeat 2~3 times), and then Monitor the "DTC"
7. Is DTC Re-displayed ? YES : --> Substitute with a known-good TCM and check for proper operation. If the problem is corrected, replace TCM as necessary and then Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S08517573042008011000000) " procedure. NO : --> Fault is intermittent caused by poor contact in the sensor's and/or TCM's connector or was repaired and TCM memory was not cleared. And Go to «COMPONENT INSPECTION»(ref-276745-S41218852782008011000000) procedure. METHOD OF LEARNING RESET * IT IS NECESSARY TO LEARNING RESET, AFTER REPLACED TRANSMISSION ERASING CONDITION SELECT LEVER POSITION IS "P" OR "N" VEHICLE SPEED = 0 km/h IGNITION "ON", ENGINE "OFF" USING A SCAN TOOL, OPERATE "LEARNING" RESET IG "ON" - IG "OFF" (2~3 TIMES), AFTER RESET

DTC DETECTING CONDITION CHART

Scheme 39

1. Connect scantool to data link connector (DLC).
2. Ignition "ON" & Engine "OFF".
3. Monitor the "BRAKE LAMP SWITCH" parameter on the scantool.
4. Depress and release Foot Brake.
5. Does "STOP LAMP SWITCH" follow the reference data? YES : --> Fault is intermittent caused by poor contact in the sensor's and/or TCM(PCM)'s connector or was repaired and TCM(PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S05933772762008011000000) " procedure. NO : --> Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-276745-S11012026972008011000000) " procedure.

TERMINAL & CONNECTOR INSPECTION

1. Many malfunctions in the electrical system are caused by poor harness and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES : --> Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S05933772762008011000000) " procedure. NO : --> Go to " «SIGNAL CIRCUIT INSPECTION»(ref-276745-S26834273622008011000000) " procedure.

Scheme 40

1. Ignition "ON" & Engine "OFF".
2. Disconnect "BRAKE LAMP SWITCH" connector.
3. Measure voltage between terminal "1" of the sensor harness connector and chassis ground. Specification: 0V
4. Is voltage within specifications? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S41218852782008011000000) " procedure. NO : --> Check for Short to power circuit in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S05933772762008011000000) " procedure.

Scheme 41

Scheme 42

Scheme 43

1. Check "STOP LAMP SWITCH". Ignition "OFF". Disconnect "STOP LAMP SWITCH" connector and Remove "STOP LAMP SWITCH". Measure resistance between terminal "1" and "2" of the STOP LAMP SWITCH when plunger of the STOP LAMP SWITCH is pushed in. Specification: Infinite Is resistance within specifications? YES : --> Go to step 2 "Adjust STOP LAMP SWITCH" below. NO : --> Replace "STOP LAMP SWITCH" as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S05933772762008011000000) " procedure.
2. Adjust "STOP LAMP SWITCH" Clearance: Ignition "OFF". Reinstall "STOP LAMP SWITCH". Adjust "STOP LAMP SWITCH" Clearance as below. Specification: 0.9 mm (0.04 in) After Adjusting, Has problem been solved? YES : --> Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S05933772762008011000000) " procedure. NO : --> Substitute with a known-good TCM/PCM and check for proper operation. If the problem is corrected, replace TCM/PCM as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S05933772762008011000000) " procedure.

DTC DETECTING CONDITION CHART

Scheme 44

1. Connect scantool to data link connector (DLC).
2. Ignition "ON" & Engine "OFF".
3. Monitor the "TRANSAXLE RANGE SWITCH" parameter on the scantool.
4. Move selector lever from "P" range to other range.
5. Does "TRANSAXLE RANGE SWITCH" follow the reference data? YES : --> Fault is intermittent caused by poor contact in the sensor's and/or TCM(PCM)'s connector or was repaired and TCM(PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30044469482008011000000) " procedure. NO : --> Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-276745-S09268915092008011000000) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES : --> Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30044469482008011000000) " procedure. NO : --> Go to " «POWER SUPPLY CIRCUIT INSPECTION»(ref-276745-S41133941842008011000000) " procedure.

Scheme 45

1. CHECK POWER TO RANGE SWITCH Disconnect "TRANSAXLE RANGE SWITCH" connector. Ignition "ON" & Engine "OFF". Measure voltage between terminal "8" of the sensor harness connector and chassis ground. Specification: approx. B+ Is voltage within specifications? YES : --> Go to " «SIGNAL CIRCUIT INSPECTION»(ref-276745-S17354553332008011000000) " procedure. NO : --> Check that Fuse 24-10A is installed or not blown. --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30044469482008011000000) " procedure.

Scheme 46

Scheme 47

1. Ignition "OFF".
2. Disconnect "TRANSAXLE RANGE SWITCH" and "TCM(PCM)" connector.
3. Measure resistance between each terminal of the sensor harness connector and TCM(PCM) harness connector as below. Specification : 2.7 GSL TRANSAXLE RANGE SWITCH SPECIFICATION Pin No of "TRANSAXLE RANGE SWITCH" C08 No1 C08 No3 C08 No4 C08 No7 Pin No of "TCM(PCM)" harness C24-3 No17 C24-3 No5 C24-3 No6 C24-3 No16 Specification 0ohms 0ohms 0ohms 0ohms 2.0 GSL TRANSAXLE RANGE SWITCH SPECIFICATION Pin No of "TRANSAXLE RANGE SWITCH" C108 No1 C108 No3 C108 No4 C108 No7 Pin No of "TCM(PCM)" harness C130-2 No29 C130-2 No22 C130-2 No6 C130-2 No14 Specification 0ohms 0ohms 0ohms 0ohms
4. Is resistance within specifications? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S27364972052008011000000) " procedure. NO : --> Check for Open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30044469482008011000000) " procedure.

Scheme 48

Scheme 49

1. Ignition "OFF".
2. Remove "TRANSAXLE RANGE SWITCH".
3. Measure the resistance between each terminal of the sensor. Specification: approx. 0 ohms
4. Is resistance within specifications? YES : --> Substitute with a known-good PCM/TCM and check for proper operation. If the problem is corrected, replace PCM/TCM as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30044469482008011000000) " procedure. NO : --> Replace "TRANSAXLE RANGE SWITCH" as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30044469482008011000000) " procedure.

DTC DETECTING CONDITION

Refer to DTC P0707 .

Scheme 50

1. Disconnect "TRANSAXLE RANGE SWITCH" connector.
2. Ignition "ON" & Engine "OFF".
3. Measure voltage between each terminal (C09) of the sensor harness connector and chassis ground. Specification: Shown below TERMINAL SPECIFICATION TERMINAL (C151) 1 3 4 7 8 9 10 SPECIFICSTION 0V 12V (PULL UP) 12V (PULL UP) 0V 0V 0V 0V
4. Is voltage within specifications? YES : --> Go to " «SIGNAL CIRCUIT INSPECTION»(ref-276745-S39052945412008011000000) " procedure. NO : --> Check for Short in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S37587971442008011000000) " procedure.

Scheme 51

1. Ignition "OFF".
2. Disconnect "TRANSAXLE RANGE SWITCH" and "TCM(PCM)" connector.
3. Measure resistance between each terminals of the sensor harness to check for Short. Specification: Infinite
4. Is resistance within specifications? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S11629338542008011000000) " procedure. NO : --> Check for Open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S37587971442008011000000) " procedure.

Scheme 52

1. Ignition "OFF".
2. Remove "TRANSAXLE RANGE SWITCH".
3. Measure the resistance between each terminal of the sensor. Specification: Approx. 0 ohms
4. Is resistance within specifications? YES : --> Substitute with a known-good PCM/TCM and check for proper operation. If the problem is corrected, replace PCM/TCM as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S37587971442008011000000) " procedure. NO : --> Replace "TRANSAXLE RANGE SWITCH" as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S37587971442008011000000) " procedure.

DTC DETECTING CONDITION

1. Many malfunctions in the electrical system are caused by poor harness and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES : --> Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S06284137272008011000000) " procedure. NO : --> Go to " «COMPONENT INSPECTION»(ref-276745-S10444101882008011000000) " procedure.

Scheme 53

Scheme 54

1. CHECK "TRANSAXLE FLUID TEMPERATURE SENSOR" Ignition "OFF". Disconnect the "TRANSAXLE FLUID TEMPERATURE SENSOR" connector. Measure the resistance between terminals "1" and "2" of the "TRANSMISSION FLUID TEMPERATURE SENSOR". Specification: Refer to table below "Reference data". [REFERENCE DATA] RESISTANCE REFERENCE DATA Temp.[°C (°F)] Resistance (kohms) Temp.[°C (°F)] Resistance (kohms) -40 (-40) 139.5 80 (176) 1.08 -20 (-4) 47.7 100 (212) 0.63 0 (32) 18.6 120 (248) 0.38 20 (68) 8.1 140 (284) 0.25 40 (104) 3.8 160 (320) 0.16 60 (140) 1.98 Is resistance within specifications? YES : --> "CHECK PCM/TCM" go to 2 below. NO : --> Replace "TRANSAXLE FLUID TEMPERATURE SENSOR" as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S06284137272008011000000) " procedure.
2. CHECK TCM Ignition "ON" & Engine "OFF". Connect "TRANSAXLE FLUID TEMPERATURE SENSOR" connector. Install scantool and select a SIMU-SCAN. Simulate voltage (0-->5V) to "TRANSMISSION FLUID TEMPERATURE SENSOR" signal circuit. * The values are subject to change according to vehicle model Is FLUID TEMP. SENSOR signal value changed according to simulation voltage? YES : --> Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S06284137272008011000000) " procedure. NO : --> Substitute with a known-good PCM/TCM and check for proper operation. If the problem is corrected, replace PCM/TCM as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S06284137272008011000000) " procedure.

DTC DETECTING CONDITION

Refer to DTC P0711 .

Scheme 55

1. Ignition "ON" & Engine "OFF".
2. Disconnect the "TRANSAXLE FLUID TEMPERATURE SENSOR" connector.
3. Measure the voltage between terminal "1" of the "TRANSMISSION FLUID TEMPERATURE SENSOR" harness connector and chassis ground. Specification: Approx. 5V
4. Is voltage within specifications? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S11302900822008011000000) " procedure. NO : --> Check for short to ground in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S17636711782008011000000) " procedure.

1. CHECK "TRANSAXLE FLUID TEMPERATURE SENSOR" Ignition "OFF". Disconnect the "TRANSAXLE FLUID TEMPERATURE SENSOR" connector. Measure the resistance between terminals "1" and "2" of the "TRANSMISSION FLUID TEMPERATURE SENSOR". Specification: Refer to table below. "Reference data" [REFERENCE DATA] RESISTANCE REFERENCE DATA Temp.[°C (°F)] Resistance (kohms) Temp.[°C (°F)] Resistance (kohms) -40 (-40) 139.5 80 (176) 1.08 -20 (-4) 47.7 100 (212) 0.63 0 (32) 18.6 120 (248) 0.38 20 (68) 8.1 140 (284) 0.25 40 (104) 3.8 160 (320) 0.16 60 (140) 1.98 Is resistance within specifications? YES : --> "CHECK PCM/TCM" go to step 2 below. NO : --> Replace "TRANSAXLE FLUID TEMPERATURE SENSOR" as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S17636711782008011000000) " procedure.
2. CHECK TCM Ignition "ON" & Engine "OFF". Connect "TRANSAXLE FLUID TEMPERATURE SENSOR" connector. Install scantool and select a SIMU-SCAN. Simulate voltage (0-->5V) to "TRANSMISSION FLUID TEMPERATURE SENSOR" signal circuit. Is FLUID TEMP. SENSOR signal value changed according to simulation voltage? YES : --> Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S17636711782008011000000) " procedure. NO : --> Substitute with a known-good PCM/TCM and check for proper operation. If the problem is corrected, replace PCM/TCM as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S17636711782008011000000) " procedure.

DTC DETECTING CONDITION

Refer to DTC P0711 .

SIGNAL CIRCUIT INSPECTION

Refer to DTC P0712 .

Scheme 56

1. Ignition "OFF".
2. Disconnect the "TRANSAXLE FLUID TEMPERATURE SENSOR" connector.
3. Measure the resistance between terminal "2" of the "TRANSMISSION FLUID TEMPERATURE SENSOR" harness connector and chassis ground. Specification: Approx. 0 ohms
4. Is resistance within specifications? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S12205514472008011000000) " procedure. NO : --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S00434873532008011000000) " procedure.

Refer to DTC P0712 .

DTC DETECTING CONDITION

1. Many malfunctions in the electrical system may be caused from poor harness and terminals. These faults can be caused by interference from other electrical systems and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES : --> Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09552227372008011000000) " procedure. NO : --> Go to " «SIGNAL SUPPLY CIRCUIT INSPECTION»(ref-276745-S25102777472008011000000) " procedure.

Scheme 57

1. Ignition "ON" & Engine "OFF".
2. Disconnect the "INPUT SPEED SENSOR" connector.
3. Measure voltage between terminal "2" of the INPUT SPEED SENSOR harness connector and chassis ground. Specification: approx. 5V
4. Is voltage within specification? YES : --> Go to " «POWER SUPPLY CIRCUIT INSPECTION»(ref-276745-S22988660572008011000000) " procedure. NO : --> Check for open or short in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09552227372008011000000) " procedure --> If signal circuit in harness is OK, Go to step 2 "Check PCM/TCM" of the "Component Inspection" procedure.

Scheme 58

1. Ignition "ON" & Engine "OFF".
2. Disconnect "INPUT SPEED SENSOR" connector.
3. Measure voltage between terminal "3" of the INPUT SPEED SENSOR harness connector and chassis ground. Specification: approx. B+
4. Is voltage within specification ? YES : --> Go to " «GROUND CIRCUIT INSPECTION»(ref-276745-S28582989152008011000000) " procedure. NO : --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09552227372008011000000) " procedure.

Scheme 59

1. Ignition "ON" & Engine "OFF".
2. Disconnect the "INPUT SPEED SENSOR" connector.
3. Measure resistance between terminal "1" of the INPUT SPEED SENSOR harness connector and chassis ground. Specification: approx. 0 ohms
4. Is resistance within specification ? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S19271770732008011000000) " procedure. NO : --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09552227372008011000000) " procedure. --> If ground circuit in harness is OK, "Check PCM/TCM" go to step 2 under " «COMPONENT INSPECTION»(ref-276745-S19271770732008011000000) ".

Scheme 60

Scheme 61

1. Check "INPUT SPEED SENSOR" Ignition "OFF". Disconnect the INPUT SPEED "SENSOR" connector. Measure resistance between terminal "1", "2" and "2","3" and "1","3" of the "INPUT SPEED SENSOR" connector. Is resistance within specifications? [REFERENCE DATA] RESISTANCE REFERENCE DATA Data Reference Data Current 22 mA Air Gap Input sensor 1.3 mm Output sensor 0.85 mm Resistance 1 (red)-2 (black) Infinite 1 (black) - 2(red) Approx. 3.89 Mohms 1 (red) - 3 (black) Approx. 6.55 Mohms 1 (black) - 3 (red) Approx. 5.27 Mohms 2 (red) - 3 (black) Approx. 17.5 Mohms 2 (black) - 3 (red) Infinite YES : --> Go to step 2 "CHECK PCM/TCM" below. NO : --> Replace "INPUT SPEED SENSOR" as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09552227372008011000000) " procedure.
2. CHECK PCM/TCM Ignition "ON" & Engine "OFF". Connect "INPUT SPEED SENSOR" connector. Install scan tool and select a SIMU-SCAN. Simulate frequency to INPUT SPEED SENSOR signal circuit. Is "INPUT SPEED SENSOR" signal value changed according to simulation frequency? YES : --> Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09552227372008011000000) " procedure. NO : --> Substitute with a known-good PCM/TCM and check for proper operation. If the problem is corrected, replace PCM/TCM as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09552227372008011000000) " procedure.

DTC DETECTING CONDITION

1. Many malfunctions in the electrical system may be caused from poor harness and terminals. These faults can be caused by interference from other electrical systems and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES : --> Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S42689378672008011000000) " procedure. NO : --> Go to " «SIGNAL CIRCUIT INSPECTION»(ref-276745-S40924523672008011000000) " procedure.

Scheme 62

1. Ignition "ON" & Engine "OFF".
2. Disconnect the "OUTPUT SPEED SENSOR" connector.
3. Measure voltage between terminal "2" of the OUTPUT SPEED SENSOR harness connector and chassis ground. Specification: approx. 5V
4. Is voltage within specification? YES : --> Go to " «POWER SUPPLY CIRCUIT INSPECTION»(ref-276745-S19301121022008011000000) " procedure. NO : --> Check for open or short in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S42689378672008011000000) " procedure --> If signal circuit in harness is OK, Go to step 2 "Check PCM/TCM" of the "Component Inspection" procedure.

Scheme 63

1. Ignition "ON" & Engine "OFF".
2. Disconnect the "INPUT SPEED SENSOR" connector.
3. Measure voltage between terminal "3" of the OUTPUT SPEED SENSOR harness connector and chassis ground. Specification: approx. B+
4. Is voltage within specification? YES : --> Go to " «GROUND CIRCUIT INSPECTION»(ref-276745-S03272452752008011000000) " procedure. NO : --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S42689378672008011000000) " procedure.

Scheme 64

1. Ignition "ON" & Engine "OFF".
2. Disconnect the "OUTPUT SPEED SENSOR" connector.
3. Measure resistance between terminal "1" of the OUTPUT SPEED SENSOR harness connector and chassis ground. Specification: approx. 0 ohms
4. Is resistance within specification? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S02175083572008011000000) " procedure. NO : --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S42689378672008011000000) " procedure. --> If ground circuit in harness is OK, "Check PCM/TCM" go to step 2 under " «COMPONENT INSPECTION»(ref-276745-S02175083572008011000000) ".

Scheme 65

Scheme 66

1. Check "OUTPUT SPEED SENSOR" Ignition "OFF". Disconnect the "OUTPUT SPEED SENSOR" connector. Measure resistance between terminal "1", "2" and "2","3' and "1","3" of the "OUTPUT SPEED SENSOR" connector. Specification: Refer to table below "Reference data". Is resistance within specifications? [REFERENCE DATA] RESISTANCE REFERENCE DATA Data Reference Data Current 22 mA Air Gap Input sensor 1.3 mm Output sensor 0.85 mm Resistance 1 (red)-2 (black) Infinite 1 (black) - 2 (red) Approx. 3.89 Mohms 1 (red) - 3 (black) Approx. 6.55 Mohms 1 (black) - 3 (red) Approx. 5.27 Mohms 2 (red) - 3 (black) Approx. 17.5 Mohms 2 (black) - 3 (red) Infinite YES : --> Go to step 2 "CHECK PCM/TCM" below. NO : --> Replace "OUTPUT SPEED SENSOR" as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S42689378672008011000000) " procedure.
2. CHECK PCM/TCM Ignition "ON" & Engine "OFF". Connect "OUTPUT SPEED SENSOR" connector. Install scan tool and select a SIMU-SCAN. Simulate frequency to OUTPUT SPEED SENSOR signal circuit. Is "OUTPUT SPEED SENSOR" signal value changed according to simulation frequency? YES : --> Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S42689378672008011000000) " procedure. NO : --> Substitute with a known-good PCM/TCM and check for proper operation. If the problem is corrected, replace PCM/TCM as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S42689378672008011000000) " procedure.

DTC DETECTING CONDITION

Scheme 67

Scheme 68

1. Connect scantool to data link connector (DLC).
2. Engine "ON".
3. Monitor the "ENGINE SPEED, INPUT SPEED SENSOR, OUTPUT SPEED SENSOR, GEAR POSITION" parameter on the scantool.
4. Perform the "STALL TEST" with gear position "1" Specification: 2000~2700 engine RPM

1. Connect Oil pressure gauge to "UD" and "L/R" port.
2. Engine "ON".
3. Drive a car with gear position 1 in "SPORTS MODE".
4. Compare it with reference data as below. Specification: shown below STANDARD HYDRAULIC PRESSURE CHART Measurement condition Standard hydraulic pressure kPa (psi) Selector lever position Shift position Engine speed (RPM) Under drive clutch pressure Reverse clutch pressure Overdrive clutch pressure Low and reverse brake pressure Second brake pressure Torque converter pressure P - 2,500 - - - 310-390 (45-56) - 250-350 (36-56) R Reverse 2,500 - 1,270-1,770 (185-256) - 1,270-1,770 (185-256) - 500-700 (185-256) N 2,500 - - - - 310-390 (45-56) - 250-390 (36-56) D 1st gear 2,500 1,010-1,050 (146-152) - - 1,010-1,050 (146-152) - 500-700 (73-101) 2nd gear 2,500 1,010-1,050 (146-152) - - - 1,010-1,050 (146-152) 500-700 (73-101) 3rd gear 2,500 590-690 (85-100) - 590-690 (85-100) - - 450-650 (65-94) 4th gear 2,500 - - 590-690 (85-100) - 590-690 (85-100) 450-650 (65-94) * The values are subject to change according to vehicle model or condition
5. Is oil pressure value within specification? YES : --> Repair AUTO TRANSAXLE (Clutch or Brake) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S08775898952008011000000) " procedure. NO : --> Replace AUTO TRANSAXLE (BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S08775898952008011000000) " procedure.

DTC DETECTING CONDITION

1. Connect Oil pressure gauge to "UD" and "2ND" port.
2. Engine "ON".
3. Drive a car with gear position 2 in "SPORTS MODE".
4. Compare it with reference data as below. Specification: shown below STANDARD HYDRAULIC PRESSURE CHART Measurement condition Standard hydraulic pressure kPa (psi) Selector lever position Shift position Engine speed (RPM) Under drive clutch pressure Reverse clutch pressure Overdrive clutch pressure Low and reverse brake pressure Second brake pressure Torque converter pressure P - 2,500 - - - 310-390 (45-56) - 250-350 (36-56) R Reverse 2,500 - 1,270-1,770 (185-256) - 1,270-1,770 (185-256) - 500-700 (185-256) N 2,500 - - - - 310-390 (45-56) - 250-390 (36-56) D 1st gear 2,500 1,010-1,050 (146-152) - - 1,010-1,050 (146-152) - 500-700 (73-101) 2nd gear 2,500 1,010-1,050 (146-152) - - - 1,010-1,050 (146-152) 500-700 (73-101) 3rd gear 2,500 590-690 (85-100) - 590-690 (85-100) - - 450-650 (65-94) 4th gear 2,500 - - 590-690 (85-100) - 590-690 (85-100) 450-650 (65-94) * The values are subject to change according to vehicle model or condition
5. Is oil pressure value within specification? YES : --> Repair AUTO TRANSAXLE (Clutch or Brake) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S21202743882008011000000) " procedure. NO : --> Replace AUTO TRANSAXLE (BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S21202743882008011000000) " procedure.

DTC DETECTING CONDITION

DTC DETECTING CONDITION

1. Connect Oil pressure gauge to "OD" and "2nd" port.
2. Engine "ON".
3. Drive a car with gear position "4".
4. Compare it with reference data as below. Specification: shown below STANDARD HYDRAULIC PRESSURE CHART Measurement condition Standard hydraulic pressure kPa (psi) Selector lever position Shift position Engine speed (RPM) Under drive clutch pressure Reverse clutch pressure Overdrive clutch pressure Low and reverse brake pressure Second brake pressure Torque converter pressure P - 2,500 - - - 310-390 (45-56) - 250-350 (36-56) R Reverse 2,500 - 1,270-1,770 (185-256) - 1,270-1,770 (185-256) - 500-700 (185-256) N 2,500 - - - - 310-390 (45-56) - 250-390 (36-56) D 1st gear 2,500 1,010-1,050 (146-152) - - 1,010-1,050 (146-152) - 500-700 (73-101) 2nd gear 2,500 1,010-1,050 (146-152) - - - 1,010-1,050 (146-152) 500-700 (73-101) 3rd gear 2,500 590-690 (85-100) - 590-690 (85-100) - - 450-650 (65-94) 4th gear 2,500 - - 590-690 (85-100) - 590-690 (85-100) 450-650 (65-94) * The values are subject to change according to vehicle model or condition
5. Is oil pressure value within specification? YES : --> Repair AUTO TRANSAXLE (Clutch or Brake) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S11277538942008011000000) " procedure. NO : --> Replace AUTO TRANSAXLE (BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S11277538942008011000000) " procedure.

DTC DETECTING CONDITION

1. Connect Oil pressure gauge to "RVS" and "LR" port.
2. Engine "ON".
3. Drive a car with gear position R.
4. Compare it with reference data as below. Specification: shown below STANDARD HYDRAULIC PRESSURE CHART Measurement condition Standard hydraulic pressure kPa (psi) Selector lever position Shift position Engine speed (RPM) Under drive clutch pressure Reverse clutch pressure Overdrive clutch pressure Low and reverse brake pressure Second brake pressure Torque converter pressure P - 2,500 - - - 310-390 (45-56) - 250-350 (36-56) R Reverse 2,500 - 1,270-1,770 (185-256) - 1,270-1,770 (185-256) - 500-700 (185-256) N 2,500 - - - - 310-390 (45-56) - 250-390 (36-56) D 1st gear 2,500 1,010-1,050 (146-152) - - 1,010-1,050 (146-152) - 500-700 (73-101) 2nd gear 2,500 1,010-1,050 (146-152) - - - 1,010-1,050 (146-152) 500-700 (73-101) 3rd gear 2,500 590-690 (85-100) - 590-690 (85-100) - - 450-650 (65-94) 4th gear 2,500 - - 590-690 (85-100) - 590-690 (85-100) 450-650 (65-94) * The values are subject to change according to vehicle model or condition
5. Is oil pressure value within specification? YES : --> Repair AUTO TRANSAXLE (Clutch or Brake) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S13135662942008011000000) " procedure. NO : --> Replace AUTO TRANSAXLE (BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S13135662942008011000000) " procedure.

DTC DETECTING CONDITION

Scheme 69

1. Connect scantool to data link connector (DLC).
2. Engine "ON".
3. Select "D RANGE" and drive vehicle.
4. Monitor the "TORQUE CONVERTER (DAMPER) CLUTCH" parameter on the scantool. Specification: TCC SLIP > 5 RPM
5. Are "TCC SOLENOID DUTY and TCC SLIP" within specifications YES : --> Fault is intermittent caused by poor contact in the sensor's and/or TCM(PCM)'s connector or was repaired and TCM(PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S16630135302008011000000) " procedure. NO : --> Go to " «COMPONENT INSPECTION»(ref-276745-S05808886542008011000000) " procedure.

1. CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE Connect scantool to data link connector (DLC). Ignition "ON" & Engine "OFF". Select A/T Solenoid valve Actuator test and Operate Actuator test. Can you hear operating tone for using TCC SOLENOID VALVE Actuator Testing Function? YES : --> Go to step 2 "CHECK OIL PRESSURE" below. NO : --> Replace "TCC SOLENOID VALVE" as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S16630135302008011000000) " procedure.
2. CHECK OIL PRESSURE Connect Oil pressure gauge to "DR" port. Ignition "ON" & Engine "OFF". After connecting Scantool and monitor the "TCC SOLENOID VALVE DUTY" parameter on the Scantool data list. Select 1st gear and accelerate Engine speed to 2500 RPM. Measure oil pressure. Specification: approx. 6.1 kg/cm 2 Is oil pressure value within specification? YES : --> Repair TORQUE CONVERTER CLUTCH (REPLACE Torque Converter) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S16630135302008011000000) " procedure. NO : --> Replace A/T assy (possible to BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S16630135302008011000000) " procedure.

DTC DETECTING CONDITION

1. CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE Connect scantool to data link connector (DLC). Ignition "ON" & Engine "OFF". Select A/T Solenoid valve Actuator test and Operate Actuator test. Can you hear operating tone for using TCC SOLENOID VALVE Actuator Testing Function? YES : --> Go to step 2 "CHECK OIL PRESSURE" below. NO : --> Replace "TCC SOLENOID VALVE" as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09613631312008011000000) " procedure.
2. CHECK OIL PRESSURE Connect Oil pressure gauge to "DR" port. Ignition "ON" & Engine "OFF". After connecting Scantool and monitor the "TCC SOLENOID VALVE DUTY" parameter on the Scantool data list. Select 1st gear and accelerate Engine speed to 2500 RPM. Measure oil pressure. Specification: approx. 6.1 kg/cm 2 Is oil pressure value within specification? YES : --> Repair TORQUE CONVERTER CLUTCH (REPLACE Torque Converter) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09613631312008011000000) " procedure. NO : --> Replace A/T assy (possible to BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09613631312008011000000) " procedure.

DTC DETECTING CONDITION

1. Many malfunctions in the electrical system are caused by poor harness and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES : --> Repair as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09284303872008011000000) " procedure. NO : --> Go to " «POWER SUPPLY CIRCUIT INSPECTION»(ref-276745-S25408240452008011000000) " procedure.

Scheme 70

1. Disconnect "A/T SOLENOID VALVE" connector.
2. Measure voltage between terminal "10" of the sensor harness connector and chassis ground.
3. Turn ignition switch OFF --> ON Specification: 12V is measured only for approx. 0.5sec
4. Is voltage within specifications? YES : --> Go to " «SIGNAL CIRCUIT INSPECTION»(ref-276745-S00649042472008011000000) " procedure. NO : --> Check that A/T-30A Fuse in engine room junction is installed or not blown. --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09284303872008011000000) " procedure.

Scheme 71

Scheme 72

1. Check signal circuit open inspection. Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector and "PCM/TCM" connector. Measure resistance between terminal "7" of the ATM SOLENOID VALVE harness connector and terminal "15" of the TCM harness connector. Specification: approx. 0 ohms Is resistance within specifications? YES : --> Check signal circuit short Inspection" procedure. Go to step 2 . NO : --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09284303872008011000000) " procedure.
2. Check signal circuit short inspection Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector and "PCM/TCM" connector Measure resistance between terminal "7" of the ATM SOLENOID VALVE harness and chassis ground. Specification: Infinite Is resistance within specifications? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S39909968482008011000000) " procedure. NO : --> Check for short to ground in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09284303872008011000000) " procedure.

Scheme 73

1. CHECK SOLENOID VALVE Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector. Measure resistance between terminal "7" and terminal "10" of the ATM SOLENOID VALVE harness connector. Specification: Approximately 2.7~3.4 ohms (20°C) Is resistance within specification? YES : --> Go to step 2 "CHECK PCM/TCM" below. NO : --> Replace TCC SOLENOID VALVE as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09284303872008011000000) " procedure.
2. CHECK PCM/TCM Connect scantool to data link connector (DLC). Ignition "ON" & Engine "OFF". Select A/T Solenoid valve Actuator test and Operate Actuator test. Can you hear operating sound for TCC SOLENOID VALVE Actuator Testing Function? YES : --> Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09284303872008011000000) " procedure. NO : --> Replace PCM/TCM as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09284303872008011000000) " procedure ACTUATOR TEST CONDITION IG SWITCH ON TRANSAXLE RANGE SWITCH is normal P RANGE Vehicle Speed 0km/h Throttle position sensor 1V IDLE SWITCH ON ENGINE RPM 0

DTC DETECTING CONDITION

1. Many malfunctions in the electrical system are caused by poor harness and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES : --> Repair as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30912087142008011000000) " procedure. NO : --> Go to " «POWER SUPPLY CIRCUIT INSPECTION»(ref-276745-S24210505292008011000000) " procedure.

Scheme 74

1. Disconnect "A/T SOLENOID VALVE" connector.
2. Measure voltage between terminal "10" of the sensor harness connector and chassis ground.
3. Turn ignition switch OFF --> ON. Specification: 12V is measured only for approx. 0.5sec
4. Is voltage within specifications? YES : --> Go to " «SIGNAL CIRCUIT INSPECTION»(ref-276745-S21059751632008011000000) " procedure. NO : --> Check that A/T-20A Fuse in engine room junction is installed or not blown. --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30912087142008011000000) " procedure.

Scheme 75

Scheme 76

1. Check signal circuit open inspection Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector and "PCM/TCM" connector. Measure resistance between terminal "6" of the ATM SOLENOID VALVE harness connector and terminal "12" of the PCM/TCM harness connector Specification: approx. 0 ohms Is resistance within specifications? YES : --> Check signal circuit short Inspection" procedure. Go to step 2 . NO : --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30912087142008011000000) " procedure.
2. Check signal circuit short inspection Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector and "PCM/TCM" connector. Measure resistance between terminal "6" of the ATM SOLENOID VALVE harness and chassis ground. Specification: Infinite Is resistance within specifications? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S12702148552008011000000) " procedure. NO : --> Check for short to ground in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30912087142008011000000) " procedure.

Scheme 77

1. CHECK SOLENOID VALVE Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector. Measure resistance between terminal "6" and terminal "10" of the ATM SOLENOID VALVE harness connector. Specification: Approximately 2.7~3.4 ohms (20°C) Is resistance within specification? YES : --> Go to step 2 "CHECK PCM/TCM" below. NO : --> Replace LR SOLENOID VALVE as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30912087142008011000000) " procedure.
2. CHECK PCM/TCM Connect scantool to data link connector (DLC). Ignition "ON" & Engine "OFF". Select A/T Solenoid valve Actuator test and Operate Actuator test. Can you hear operating sound for LR SOLENOID VALVE Actuator Testing Function? YES : --> Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30912087142008011000000) " procedure. NO : --> Replace PCM/TCM as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S30912087142008011000000) " procedure. ACTUATOR TEST CONDITION IG SWITCH ON TRANSAXLE RANGE SWITCH is normal P RANGE Vehicle Speed 0km/h Throttle position sensor 1V IDLE SWITCH ON ENGINE RPM 0

DTC DETECTING CONDITION

1. Many malfunctions in the electrical system are caused by poor harness and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES : --> Repair as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S11160688402008011000000) " procedure. NO : --> Go to " «POWER SUPPLY CIRCUIT INSPECTION»(ref-276745-S41699073822008011000000) " procedure.

Scheme 78

1. Disconnect "A/T SOLENOID VALVE" connector.
2. Measure voltage between terminal "9" of the sensor harness connector and chassis ground.
3. Turn ignition switch OFF --> ON Specification: 12V is measured only for approx. 0.5sec
4. Is voltage within specifications? YES : --> Go to " «SIGNAL CIRCUIT INSPECTION»(ref-276745-S17322722062008011000000) " procedure. NO : --> Check that A/T-30A Fuse in engine room junction is installed or not blown. --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S11160688402008011000000) " procedure.

Scheme 79

Scheme 80

1. Check signal circuit open inspection Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector and "PCM/TCM" connector Measure resistance between terminal "3" of the ATM SOLENOID VALVE harness connector and terminal "1" of the PCM/TCM harness connector Specification: approx. 0 ohms Is resistance within specifications? YES : --> Check signal circuit short Inspection" procedure. Go to step 2 . NO : --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S11160688402008011000000) " procedure.
2. Check signal circuit short inspection Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector and "PCM/TCM" connector. Measure resistance between terminal "3" of the ATM SOLENOID VALVE harness and chassis ground. Specification: Infinite Is resistance within specifications? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S38390842152008011000000) " procedure. NO : --> Check for short to ground in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S11160688402008011000000) " procedure.

Scheme 81

1. CHECK SOLENOID VALVE Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector. Measure resistance between terminal "3" and terminal "9" of the ATM SOLENOID VALVE harness connector. Specification: Approximately 2.7~3.4 ohms (20°C) Is resistance within specification? YES : --> Go to step 2 "CHECK PCM/TCM" below. NO : --> Replace UD SOLENOID VALVE as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S11160688402008011000000) " procedure.
2. CHECK PCM/TCM Connect scantool to data link connector (DLC) Ignition "ON" & Engine "OFF". Select A/T Solenoid valve Actuator test and Operate Actuator test. Can you hear operating sound for UD SOLENOID VALVE Actuator Testing Function? YES : --> Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S11160688402008011000000) " procedure. NO : --> Replace PCM/TCM as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S11160688402008011000000) " procedure. ACTUATOR TEST CONDITION IG SWITCH ON TRANSAXLE RANGE SWITCH is normal P RANGE Vehicle Speed 0km/h Throttle position sensor 1V IDLE SWITCH ON ENGINE RPM 0

DTC DETECTING CONDITION

1. Many malfunctions in the electrical system are caused by poor harness and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES : --> Repair as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S23017787482008011000000) " procedure. NO : --> Go to " «POWER SUPPLY CIRCUIT INSPECTION»(ref-276745-S08743471582008011000000) " procedure.

POWER SUPPLY CIRCUIT INSPECTION

Refer to DTC P0755 .

Scheme 82

Scheme 83

1. Check signal circuit open inspection Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector and "PCM/TCM" connector Measure resistance between terminal "4" of the ATM SOLENOID VALVE harness connector and terminal "16" of the PCM/TCM harness connector Specification: approx. 0 ohms Is resistance within specifications? YES : --> Check signal circuit short Inspection" procedure. Go to step 2 . NO : --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S23017787482008011000000) " procedure.
2. Check signal circuit short inspection Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector and "PCM/TCM" connector. Measure resistance between terminal "4" of the ATM SOLENOID VALVE harness and chassis ground. Specification: Infinite Is resistance within specifications? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S14005606382008011000000) " procedure. NO : --> Check for short to ground in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S23017787482008011000000) " procedure.

Scheme 84

1. CHECK SOLENOID VALVE Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector. Measure resistance between terminal "4" and terminal "9" of the ATM SOLENOID VALVE harness connector. Specification: Approximately 2.7~3.4 ohms (20°C) Is resistance within specification? YES : --> Go to step 2 "CHECK PCM/TCM" below. NO : --> Replace 2nd SOLENOID VALVE as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S23017787482008011000000) " procedure.
2. CHECK PCM/TCM Connect scantool to data link connector (DLC) Ignition "ON" & Engine "OFF". Select A/T Solenoid valve Actuator test and Operate Actuator test. Can you hear operating sound for LR SOLENOID VALVE Actuator Testing Function? YES : --> Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S23017787482008011000000) " procedure. NO : --> Replace PCM/TCM and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S23017787482008011000000) " procedure. ACTUATOR TEST CONDITION IG SWITCH ON TRANSAXLE RANGE SWITCH is normal P RANGE Vehicle Speed 0km/h Throttle position sensor 1V IDLE SWITCH ON ENGINE RPM 0

DTC DETECTING CONDITION

Refer to DTC P0760 .

Refer to DTC P0755 .

Scheme 85

1. Check signal circuit open inspection Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector and "PCM/TCM" connector. Measure resistance between terminal "5" of the ATM SOLENOID VALVE harness connector and terminal "14" of the PCM/TCM harness connector Specification: approx. 0 ohms Is resistance within specifications? YES : --> Check signal circuit short Inspection" procedure. Go to step 2 . NO : --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S18170519962008011000000) " procedure.
2. Check signal circuit short inspection Ignition "OFF" & Engine "OFF". Disconnect "A/T SOLENOID VALVE" connector and "PCM/TCM" connector. Measure resistance between terminal "5" of the ATM SOLENOID VALVE harness and chassis ground. Specification: Infinite Is resistance within specifications? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S26600745442008011000000) " procedure. NO : --> Check for short to ground in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S18170519962008011000000) " procedure.

Scheme 86

1. CHECK SOLENOID VALVE Ignition "OFF". Disconnect "A/T SOLENOID VALVE" connector. Measure resistance between terminal "5" and terminal "9" of the ATM SOLENOID VALVE harness connector. Specification: Approximately 2.7~3.4 ohms (20°C) Is resistance within specification? YES : --> Go to step 2 "CHECK PCM/TCM" below. NO : --> Replace 2nd SOLENOID VALVE as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S18170519962008011000000) " procedure.
2. CHECK PCM/TCM Connect scantool to data link connector (DLC). Ignition "ON" & Engine "OFF". Select A/T Solenoid valve Actuator test and Operate Actuator test. Can you hear operating sound for LR SOLENOID VALVE Actuator Testing Function? YES : --> Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S18170519962008011000000) " procedure. NO : --> Replace PCM/TCM and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S18170519962008011000000) " procedure. ACTUATOR TEST CONDITION IG SWITCH ON TRANSAXLE RANGE SWITCH is normal P RANGE Vehicle Speed 0km/h Throttle position sensor 1V IDLE SWITCH ON ENGINE RPM 0

DTC DETECTING CONDITION

Scheme 87

1. Connect scantool to data link connector (DLC).
2. Ignition "ON" & Engine "OFF".
3. Monitor the "A/T CON. RELAY VOLT" parameter on the scantool. Specification: Approx. B+
4. Is A/T RELAY VOLT within specifications? YES : --> Fault is intermittent caused by poor contact in the sensor's and/or TCM(PCM)'s connector or was repaired and TCM(PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S20516847302008011000000) " procedure. NO : --> Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-276745-S07082188922008011000000) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES : --> Repair as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S20516847302008011000000) " procedure. NO : --> Go to " «POWER SUPPLY CIRCUIT INSPECTION»(ref-276745-S14144493722008011000000) " procedure.

Scheme 88

1. Ignition "ON" & Engine "OFF".
2. Disconnect the "A/T CONTROL RELAY" connector.
3. Measure the voltage between terminal "1" of the "A/T CONTROL RELAY" harness connector and chassis ground. Specification: Approx. B+
4. Is voltage within specifications? YES : --> Go to " «SIGNAL CIRCUIT INSPECTION»(ref-276745-S35515864572008011000000) " procedure. NO : --> Check that A/T-30A Fuse in engine room junction is installed or not blown. --> Check for Open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S20516847302008011000000) " procedure.

Scheme 89

Scheme 90

1. CHECK A/T control relay harness Ignition "OFF". Disconnect the "A/T CONTROL RELAY" connector. Measure the voltage between terminal "4" of the "A/T CONTROL RELAY" harness connector and chassis ground. Turn ignition switch OFF --> ON. Specification: 12V is measured only for approx. 0.5 sec Is voltage within specifications? YES : --> Go to step 2 "Check Supplying Power to solenoid valve". NO : --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S20516847302008011000000) " procedure --> If signal circuit is OK, Substitute with a known-good PCM/TCM and check for proper operation. If the problem is corrected, replace PCM/TCM and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S20516847302008011000000) " procedure.
2. CHECK Supplying Power to solenoid valve harness Ignition "OFF". Disconnect the "A/T CONTROL RELAY" and PCM/TCM connector. Measure the resistance between terminal "3" of the "A/T CONTROL RELAY" harness connector and terminal "2, 3" of the PCM/TCM harness connector Specification: Approx. 0 ohms Is resistance within specifications? YES : --> Go to " «GROUND CIRCUIT INSPECTION»(ref-276745-S19104682542008011000000) " procedure. NO : --> Check for Open in C-35 (2.7 GAS) joint connector. --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S20516847302008011000000) " procedure.

Scheme 91

1. Ignition "OFF".
2. Connect the "A/T CONTROL RELAY" connector.
3. Measure the resistance between terminal "2" of the "A/T CONTROL RELAY" harness connector and chassis ground. Specification: Approx. 0 ohms
4. Is resistance within specifications? YES : --> Go to " «COMPONENT INSPECTION»(ref-276745-S41906082032008011000000) " procedure. NO : --> Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S20516847302008011000000) " procedure.

Scheme 92

1. Ignition "OFF".
2. Remove "A/T CONTROL RELAY"
3. Measure the resistance between each terminal of the sensor. Specification: ITEM SPECIFICATION Item Terminal No. Resistance 1 (red) - 3 (pink) INFINITE 2 (black) - 4 (pink) supply (B+) to number 4 and supply (B-) to number 2. 1 (red) - 3 (pink) 0 ohms
4. Is resistance with in specification? YES : --> Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S20516847302008011000000) " procedure. NO : --> Replace ATM CONTROL RELAY and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S20516847302008011000000) " procedure.

DTC DETECTING CONDITION

REFER TO ECM DIAGNOSIS PROCEDURE.

DTC DETECTING CONDITION

Scheme 93

1. Connect scantool to data link connector (DLC).
2. Engine "ON".
3. Monitor the "CAN COMMUNICATION SERVICE DATA (ENGINE RPM, VEHICLE SPEED SENSOR, THROTTLE P. SENSOR)" parameters on the scantool.
4. Compare it with reference data as below.
5. Does "CAN BUS LINE DATA" follow the reference data? YES : --> Fault is intermittent caused by poor contact in the sensor's and/or TCM's connector or was repaired and TCM memory was not cleared. And go to «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09169975322008011000000) procedure. NO : --> Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-276745-S25815323522008011000000) " procedure.

TERMINAL AND CONNECTOR INSPECTION

1. Many malfunctions in the electrical system are caused by poor harness and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES : --> Fault is intermittent caused by poor contact in the sensor's and/or TCM's connector or was repaired and TCM memory was not cleared. And go to «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09169975322008011000000) procedure. NO : --> Go to " «SIGNAL CIRCUIT INSPECTION»(ref-276745-S02870779952008011000000) " procedure.

Scheme 94

1. Ignition "ON" & Engine "OFF".
2. Disconnect the "TCM" connector.
3. Measure resistance between terminal "3" and "4" of the "TCM" harness connector. Specification: approx. 60 ohms
4. Is measured resistance within specifications? YES : --> Substitute with a known-good TCM and check for proper operation. If the problem is corrected, replace TCM as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09169975322008011000000) " procedure. NO : --> Check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage of ECM. And then Repair or replace Resistance for CAN communication as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-276745-S09169975322008011000000) " procedure.

DTC DETECTING CONDITION
