Automatic Transaxle System: Removal & Installation Hyundai Tucson I

Automatic Trans 15 illustrations ~1069 words

REPLACEMENT

If you have a fluid changer, use this changer to replace the fluid. If you do not, replace it using by the following procedure.

Scheme 95

Scheme 95: REPLACEMENT
Scheme 95: REPLACEMENT
  1. Disconnect the hose, which connects the transmission and the oil cooler which is within the radiator only in 2.0L engine (2.7L the oil cooler is separated).
  2. Start the engine and let the fluid drain out. Running conditions: "N" range with engine idling. CAUTION: The engine should be stooped within one minute after it is started. If the fluid has all drained out before then, the engine should be stopped at that point.
  3. Remove the drain plug from the bottom of the transmission case to drain the fluid.
  4. Install the drain plug via the fasket, and tighten it the specified torque. Tightening torque: 29 ~ 34 Nm (290 ~ 340 kgf.cm, 21.4 ~ 25.1 lbf.ft)
  5. Pour the new fluid in through the oil filler tube. CAUTION: Stop pouring if the full volume of fluid cannot be poured in.
  6. Repeat the procedure in step (2). NOTE: Check the old fluid for contamination. If it has been contamination. If it has been contaminated, repeat the steps (5) and (6).
  7. Pour the new fluid in through the oil filler tube.
  8. Reconnect the hose, which was disconnected in step (1) above, and firmly replace the oil level gauge. (In case of this "replace", this means after wiping off any dirt around the oil level gauge, insert it into the filler tube.)
  9. Start the engine and run it at idle for 1~2 minutes.
  10. Move the select lever through all positions, and then move it to the "N" position.
  11. Drive the vehicle until the fluid temperature rises to the normal temperature (70~80°C), and then check the fluid level again. The fluid level must be at the HOT mark.
  12. Firmly insert the oil level gauge (A) into the oil filler tube.

Scheme 96

Scheme 96: REPLACEMENT
Scheme 96: REPLACEMENT

Scheme 97

Scheme 97
Scheme 97
  1. Pull up the parking brake.
  2. Position the shift lever in 'N' range.
  3. Remove the air cleaner assembly.
  4. Remove the battery.
  5. Remove the battery tray (A).
  6. Remove the inhibitor switch connector.
  7. Remove the shift cable mounting nut (A).
  8. Remove the inhibitor switch loosening the mounting bolts.
  9. Referring to 'INSPECTION', check for continuity. If there is an error, replace the inhibitor switch.
  10. After tightening the shift cable mounting nut, connect the inhibitor switch.
  11. Install the battery, battery tray and the air cleaner assembly.

Scheme 98

Scheme 98: INSPECTION
Scheme 98: INSPECTION

Scheme 99

Scheme 99
Scheme 99
  1. Check for the starter motor when the ignition switch is at 'START' position and the shift lever at 'P' or 'N' range.
  2. Check for the rear lamp when the ignition switch if it does not work properly.
  3. Check for the inhibitor switch if it does not work properly.
  4. If the inhibitor switch is not fixed in a proper position, reassemble it in the right position.
  5. Re-check 1 and 2 procedures.
  6. Using a scan tool, confirm the DTCs.
  7. Disconnect the battery (-) terminal and the inhibitor switch.
  8. Check for continuity between terminals at the switch connector.
  9. If there are not continuity between the terminals in the table above for each switch position, replace the inhibitor switch. See «INHIBITOR SWITCH - CONTINUITY CHECK (SPORTS MODE)»(ref-276745-S42501304602008011000000) .

Scheme 100

Scheme 100: ADJUSTMENT
Scheme 100: ADJUSTMENT

Scheme 101

Scheme 101
Scheme 101
  1. Set the select lever to the "N" position.
  2. Loosen the control cable to manual control lever coupling nut to free the cable and lever.
  3. Set the manual control lever to the neutral position.
  4. Loosen the transaxle range switch body mounting bolts and then turn the transaxle range switch body so the hole in the end of the manual control lever and the hole (cross section A-A in the figure) in the flange of the transaxle range switch body flange are aligned.
  5. Tighten the transaxle range switch body mounting bolts to the specified torque. Make sure at this time that the position of the switch body did not move. Tightening torque: 10~12 Nm (100~120 kg.cm, 7~8 lb.ft)
  6. Gently pull the transmission control cable in the direction of the arrow, and then tighten the adjusting nut.
  7. Check that the select lever is in the "N" position.

Scheme 102

Scheme 102: REPLACEMENT
Scheme 102: REPLACEMENT
  1. Remove the automatic transaxle assembly.
  2. Remove the valve body cover.
  3. Disconnect the oil temperature sensor connector.
  4. Remove the oil temperature sensor (B), loosening the mounting bolt (A).
  5. Replace the sensor with the new one and reassemble the rest parts.

Scheme 103

Scheme 103: INSPECTION
Scheme 103: INSPECTION

Scheme 104

Scheme 104
Scheme 104
  1. Remove the oil temperature sensor (A).
  2. Measure the resistance between the terminal 1 and 2 of the sensor connector. RESISTANCE REFERENCE Temp. [°C (°F)] Resistance (Kohms) 0 (32) 18.6 100 (212) 0.63
  3. If the value is out of the specification, replace the oil temperature sensor.

Scheme 105

Scheme 105: REPLACEMENT
Scheme 105: REPLACEMENT

Scheme 106

Scheme 106
Scheme 106
  1. Remove the battery and air cleaner (see «REPLACEMENT»(ref-276745-S18857412482008011000000) ).
  2. Remove the transaxle range switch connector.
  3. Remove the control cable to transaxle range switch mounting nut.
  4. Remove the clip (A) of the control cable (B).
  5. Remove the control cable mounting bracket.
  6. Remove the input shaft speed sensor (A). Disconnect the input shaft speed sensor connector. Remove the bolt (B). Inspect the input shaft speed sensor bore.
  7. Apply a light coat of automatic transaxle fluid to the O-ring seal before installation.
  8. Install the input shaft speed sensor.
  9. Install the control cable mounting bracket.
  10. Connect the input shaft speed sensor connector.
  11. Install the holder of the control cable.
  12. Adjust the control cable to transaxle range switch and tighten the transaxle manual lever to the control cable mounting nut. See «AUTOMATIC TRANSAXLE CONTROL SYSTEM»(ref-276699) and «ADJUSTMENT»(ref-276745-S34902690762008011000000) .
  13. Installation is the reverse of removal.

Scheme 107

Scheme 107: REPLACEMENT
Scheme 107: REPLACEMENT
  1. Remove the battery and air cleaner (see «REPLACEMENT»(ref-276745-S18857412482008011000000) ).
  2. Remove the output shaft speed sensor (A). Disconnect the output shaft speed sensor connector (B). Remove the bolt (C). Inspect the output shaft speed sensor bore.
  3. Apply a light coat of automatic transaxle fluid to the O-ring seal before installation.
  4. Installation is the reverse of removal.

Scheme 108

Scheme 108: REPLACEMENT
Scheme 108: REPLACEMENT
  1. Lift up the vehicle.
  2. Remove the vehicle speed sensor (A). Disconnect the vehicle speed sensor connector (B). Remove the bolt (10 mm (0.4 in)). Inspect the vehicle speed sensor bore.
  3. Inspect the O-ring for nicks or cut. Install a new O-ring as necessary.
  4. Apply a light coat of automatic transaxle fluid to the O-ring seal before installation.
  5. Install the vehicle speed sensor.
  6. Connect the vehicle speed sensor connector.
  7. Installation is the reverse of removal.

Scheme 109

Scheme 109: COMPONENT LOCATION
Scheme 109: COMPONENT LOCATION

INSTALLATION

  1. Installation is in the reverse order of removal.
  2. After installation, reset the adaptive learning value of the TCM (Refer to TSB No. HT2005041303).
