Actuation Test
| No. | Description |
|---|---|
| 1 | SSB Ember LED |
| 2 | SSB Blue LED |
| 3 | Fob Holder Illumination |
| 4 | SSB Illumination |
| 5 | ACC Output |
| 6 | ING1 Output |
| 7 | ING2 Output |
| 8 | Start Output |
| 9 |
ACTUATION TEST DESCRIPTION CHART
Scheme 37
Scheme 38
Scheme 39
- Disconnect the negative (-) battery terminal.
- Remove the glove box housing. (Refer to the " «CRASH PAD»(ref-419431-S35859312612011091200000) ")
- Remove the smart key unit (A) and PDM (B) with bracket after loosening the mounting nuts (2EA), bolts (2EA) and screw (1EA).
- In case of Canada, remove the PDM with bracket (A) after loosening the mounting nuts and screws and shear bolt. CAUTION: Do not reuse the shear bolts. When installing the new shear bolts to the smart key unit, tighten the shear bolts until its head is cut off.
- Remove the PDM from the bracket after disconnecting the connectors.
