Button Engine Start System - Except Hev: Removal & Installation Hyundai Sonata VI

Starter 14 illustrations ~313 words

Installation

  1. Install the start/stop button.
  2. Install the key set bezel.
  3. Install the crash pad center lower cover.
  4. Install the crash pad lower panel.

Scheme 109

Scheme 109: Components
Scheme 109: Components

Scheme 110

Scheme 110: Removal
Scheme 110: Removal

Scheme 111

Scheme 111
Scheme 111
  1. Disconnect the negative (-) battery terminal.
  2. Remove the floor console. (Refer to the " «CONSOLE»(ref-424764-S38718715452011100100000) ")
  3. Disconnect the fob holder connector (A).
  4. Remove the fob holder (A) by pushing both sides of the hooks.
  1. Install the fob holder.
  2. Install the floor console.

Scheme 112

Scheme 112: Component
Scheme 112: Component

Scheme 113

Scheme 113: System Circuit Diagram
Scheme 113: System Circuit Diagram

Scheme 114

Scheme 114: PDM Diagnosis With GDS
Scheme 114: PDM Diagnosis With GDS

Scheme 115

Scheme 115
Scheme 115

Scheme 116

Scheme 116
Scheme 116

Scheme 117

Scheme 117
Scheme 117
  1. It will be able to diagnose defects of Smart key with GDS quickly. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
  2. Select model and "Smart key system (Button start)" menu if you want to check PDM.
  3. Select "PDM" in the menu.
  4. Select "Current Data", if you want to check current data of PDM. It provides the input/output status of each module.
  5. If you want to check PDM data operation forcefully, select "Actuation test".

Input/output Current Data

NODescriptionUnit
1Load Battery VoltageV
2Abs Speed Sensor (main)Km/h
3Start Stop Button SWOFF/ON
4ACC inputOFF/ON
5IGN1 InputOFF/ON
6IGN2 InputOFF/ON
7Fob In SwitchRELEASE/INSERT
8Start Relay Monitoring Input
9SSB Ember LED OutputOFF/ON
10SSB Blue LED OutputOFF/ON
11Fob Holder Illumination OutputOFF/ON
12SSB Illumination OutputOFF/ON
13ACC Relay OutputOFF/ON
14IGN1 Relay OutputOFF/ON
15IGN2 Relay OutputOFF/ON
16Start Relay S1 OutputOFF/ON
17
18
19CPU Battery VoltageV
20Engine SpeedDATA*1.0
21ACC Relay SCBOFF/ON
22IGN1 Relay SCBOFF/ON
23IGN2 Relay SCBOFF/ON
24Start Relay SCBOFF/ON
25SCC Relay OpenOFF/ON
26IGN1 Relay OpenOFF/ON
27IGN2 Relay OpenOFF/ON
28ACC Output SCBOFF/ON
29IGN1 Output SCBOFF/ON
30IGN2 Output SCBOFF/ON
31Start Output SCBOFF/ON
32ACC Output SCGOFF/ON
33IGN1 Output SCGOFF/ON
34IGN2 Output SCGOFF/ON
35Start Output SCGOFF/ON

INPUT/OUTPUT CURRENT DATA REFERENCE CHART

Actuation Test

No.Description
1SSB Ember LED
2SSB Blue LED
3Fob Holder Illumination
4SSB Illumination
5ACC Output
6ING1 Output
7ING2 Output
8Start Output
9

ACTUATION TEST DESCRIPTION CHART

Scheme 118

Scheme 118: ESCL Open Status Check
Scheme 118: ESCL Open Status Check

Scheme 119

Scheme 119
Scheme 119

Scheme 120

Scheme 120
Scheme 120
  1. Select the "ESCL open status check" menu if you want to check ESCL open.

Scheme 121

Scheme 121: Removal
Scheme 121: Removal

Scheme 122

Scheme 122
Scheme 122
  1. Disconnect the negative (-) battery terminal.
  2. Remove the glove box housing. (Refer to the " «CRASH PAD»(ref-424764-S23522138592011100100000) ")
  3. Remove the smart key unit (A) and PDM (B) with bracket after loosening the mounting nuts (2EA) and screw (1EA).
  4. In case of Canada, remove the PDM with bracket (A) after loosening the mounting nuts and screws and shear bolt. CAUTION: Do not reuse the shear bolts. When installing the new shear bolts to the smart key unit, tighten the shear bolts until its head is cut off.
  5. Remove the PDM from the bracket after disconnecting the connectors.
  1. Install the power distribution module.
  2. Install the glove box housing.
