REMOVAL & INSTALLATION
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures. See AIR BAG DEACTIVATION PROCEDURES article in GENERAL INFORMATION. |
Disconnect brakelight switch electrical connector. Loosen and remove lock nut. Unscrew brakelight switch from brake pedal bracket. To install, reverse removal procedure. Adjust brakelight switch. See BRAKELIGHT SWITCH under ADJUSTMENTS.
Remove center console for access to park position/key lock switch. Disconnect park position/key lock switch electrical connector. Remove switch assembly from gearshift lever. (Scheme 1) To install, reverse removal procedure.
Scheme 1
Scheme 1: Removal & Installation
Remove center console for access to shift lock solenoid. Disconnect shift lock solenoid electrical connector. Remove solenoid assembly from gearshift lever. (Scheme 1) To install, reverse removal procedure.
Shift Interlock System Wiring Diagram (1997 Accent). Scheme 2
Scheme 2: Shift Interlock System Wiring Diagram (1997 Accent)
Shift Interlock System Wiring Diagram (1998 Accent). Scheme 3
Scheme 3: Shift Interlock System Wiring Diagram (1998 Accent)
Shift Interlock System Wiring Diagram (1999 Accent). Scheme 4
Scheme 4: Shift Interlock System Wiring Diagram (1999 Accent)
Shift Interlock System Wiring Diagram (1997 Elantra). Scheme 5
Scheme 5: Shift Interlock System Wiring Diagram (1997 Elantra)
Shift Interlock System Wiring Diagram (1998 Elantra). Scheme 6
Scheme 6: Shift Interlock System Wiring Diagram (1998 Elantra)
Shift Interlock System Wiring Diagram (1999 Elantra). Scheme 7
Scheme 7: Shift Interlock System Wiring Diagram (1999 Elantra)
Shift Interlock System Wiring Diagram (1997 Sonata). Scheme 8
Scheme 8: Shift Interlock System Wiring Diagram (1997 Sonata)
Shift Interlock System Wiring Diagram (1998-99 Sonata). Scheme 9
Scheme 9: Shift Interlock System Wiring Diagram (1998-99 Sonata)
Shift Interlock System Wiring Diagram (1997 Tiburon). Scheme 10
Scheme 10: Shift Interlock System Wiring Diagram (1997 Tiburon)
Shift Interlock System Wiring Diagram (1998 Tiburon). Scheme 11
Scheme 11: Shift Interlock System Wiring Diagram (1998 Tiburon)
Shift Interlock System Wiring Diagram (1999 Tiburon). Scheme 12
Scheme 12: Shift Interlock System Wiring Diagram (1999 Tiburon)
