Power Door Mirrors Hyundai Santa Fe III

Scheme 11

Scheme 12

Scheme 13

1. Disconnect the negative (-) battery terminal.
2. Remove the front left door trim. Refer to «FRONT DOOR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#front-door) .
3. Remove the power mirror switch (A) from the door trim.

Installation

1. Install the power mirror switch.
2. Install the front door trim after connecting the connector.
3. Connect the negative (-) battery terminal.

Scheme 14

1. Remove the front left door trim. Refer to «FRONT DOOR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#front-door) .
2. Remove the power mirror switch (A) from the door trim.
3. Check for continuity between the terminals in each switch position according to the table.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Disconnect the negative (-) battery terminal.
2. Disconnect the connector (B) after removing the front door quadrant cover (A).
3. Disconnect the power door mirror connector (A) from the harness.
4. Apply battery voltage to each terminal as shown in the table and verify that the mirror operates properly.

Scheme 19

Scheme 20

Scheme 21

Scheme 22
