Scheme 3
Scheme 3: Component Location
Replacement
| CAUTION | Put on gloves to protect your hands. |
Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.
Scheme 4
Scheme 5
- Using a screwdriver or remover, remove the front door quadrant inner cover (A).
- Disconnect the outside rear view mirror connector (B).
- After loosening the mounting nuts, then remove the outside rear view mirror (A). Tightening torque: 6.9 ~ 10.8 N.m (0.7 ~ 1.1 kgf.m, 5.1 ~ 8.0 lb-ft)
- Install in the reverse order of removal. Information Make sure the connector is connected properly. Replace any damaged clips.
Scheme 6
Scheme 6: Component Location
| CAUTION | Put on gloves to protect your hands. |
Scheme 7
- Loosen the inside rear view mirror mounting screw (C).
- Push the inside rear view mirror base (B) up to remove the inside rear view mirror assembly (A).
- Install in the reverse order of removal.
| CAUTION | Put on gloves to protect your hands. |
Scheme 8
Scheme 9
Scheme 10
- Remove the ECM mirror cover (A).
- Disconnect the ECM mirror connector (B).
- Loosen the ECM mirror mounting screw.
- Push the ECM mirror base up to remove the ECM mirror assembly (A).
- Install in the reverse order of removal. Information Make sure the connector is connected properly.
