Lighting System Hyundai Santa Fe III

Specifications

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

1. Bulb Elements Xenon gas: Xenon gas activates the initial reaction for rapid illuminating. Molybdenum electrode: anode arcing Metal halide salts: color composing component Lightening principle When Xenon gas and metal halide salt will discharge the molybdenum anode in a capsule, it emits light.
2. Ignitor Ignitor (A) is an electromagnetic transformer that receives current from ballast and boost voltage to light on the arc light source in any environment.
3. Ballast Ballast (A) delivers an instant high voltage pulse to the ignitor electrode, to initialize discharge in the source. Ballast supplies the stable power to the bulb and the ignitor during initialization and normal state of arc.
4. Stability Durable for vibration as there is no filament. Does not operate if polarity are changed. Doesn't operate if the input voltage is not in the range of 10-16V. Doesn't operate if the circuit is short. Doesn't operate if the bulb burnt out.

Scheme 7

1. Check-points upon head lamp failure (HID) Check the battery voltage. (Low beam will be on when the battery voltage above 9V.) Check the fuse and relay. Check the polarity of ballast. (If the polarity are changed, low beam doesn't lighten) Check the bulb connector securely. Visually bulb checking (no filament): damaged glass, damaged for upper parts and lower parts of glass tube. After (1)~(5), replace the ballast and the ignitor. (ballast assembly).
2. Service procedure and warning (HID) No. Item Service procedures Warning Remarks 1 Replacement of lamp assembly Disconnect the power connector from the lamp. Remove and replace the lamp assembly. Connect the power connector after removing the front bumper cover. Disconnect the head lamp power connector to avoid high voltage. Other description is the same as the halogen bulbs. 2 Replacement of the Bulb Disconnect the power connector from the lamp. (head lamp, turn signal, head lamp leveling device) Remove the lamp assembly. Remove the ballast and dust cover. Remove the bulb socket and replace the bulb. Installation is the reverse of removal. Disconnect the head lamp power connector to avoid high voltage. Be careful not to damage the bulb and use genuine bulbs only. Do not apply excessive force and fit it correctly. 3 Replacement of the Ballast (with built-in ignitor) Disconnect the power connector from the lamp. Remove the lamp and then the ballast and the dust cover. Remove the head lamp leveling device and then the bulb socket. Connect the bulb socket on the replacement ballast and install the leveling device. Installation is the reverse of removal. Disconnect the head lamp power connector to avoid high voltage. Replace the ballast only and install the used lamp. Replace the sub assembly except the ballast. 4 Others Power supply should be according to the rated capacity. Use the rated fuse and wire. Bulb socket shall be free from moisture or dirt. Do not apply the ballast severe shock, water, or extreme All parts should be serviced only at specified service centers. HID lamp should not be installed on other cars (Dangerous, fire may occur.) CAUTION: HID lamp shall not be used on other cars. (Fire may occur.) Fire may occur when HID lamp initially lights due to the fact that arc-discharge generates high voltage (max. 30, 000V) and high current (12- 13A), and are different from the halogen lamp specification.

Characteristic

1. Durable for vibration as there is no filament.
2. HID lamp had a more long life than halogen lamp.
3. Does not operate if polarity is changed.
4. Operating input voltage: 9-16V

Removal

Note. The headlamp bulb should not be removed from the headlamp assembly until just before a new bulb is installed. Removing bulb for an extended period of time may affect headlamp bulb performance. Contaminants may enter the headlamp assembly where they can settle on the lens and reflector. Never turn on the head lamps with the bulb removed from the headlamp assembly.

Scheme 8

Scheme 9

Scheme 10

1. Disconnect the negative (-) battery terminal.
2. Remove the front bumper cover. (Refer to " «FRONT BUMPER COVER»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#front-bumper-grille) ")
3. Loosen the mounting bolts (3EA) of head lamp. Remove the head lamp assembly (B) after disconnecting the lamp connectors (A). NOTE: Take care that retaining clip (A) is not to be damaged.

Installation

1. Install the head lamp bulbs.
2. Reassemble the head lamp bulb covers.
3. Reassemble the head lamp assembly after connecting the lamp connector.

Scheme 11

1. Turn the head lamp switch off.
2. Disconnect the power connector from the lamp.
3. Remove the dust cap.
4. Remove the ignitor clip from the lamp assembly.
5. Disconnect the ignitor connector.
6. Remove the ignitor and bulb (A).
7. Installation is the reverse of removal. CAUTION: Turn the head lamp switch off to avoid high voltage Be careful not to damage the bulb and use genuine bulbs only Do not apply excessive force and fit it correctly. Confirm the bulb locking

Scheme 12

Scheme 13

1. Turn the head lamp switch off.
2. Disconnect the power connector from the lamp.
3. Remove the dust cap.
4. Turn the connector (A) counterclockwise and then remove it. Remove the head lamp low beam bulb (B) after disconnecting the connector (A) from the bulb.
5. Remove the head lamp high beam bulb (B) after disconnecting the connector (A) from the bulb.
6. Installation is the reverse of removal.

Turn signal lamp

1. Turn the head lamp switch off.
2. Remove the bulb socket (A) and bulb (B) from the lamp assembly.

Scheme 14

Scheme 15

1. Turn the head lamp switch off.
2. Disconnect the power connector from the lamp.
3. Remove the head lamp assembly.
4. Remove the ballast (A) after loosening the screws (3EA).
5. Installation is the reverse of removal. NOTE: Turn the head lamp switch off to avoid high voltage. CAUTION: HID lamp shall not be used on other cars. (Fire may occur.) Fire may occur when HID lamp initially lights due to the fact that arc-discharge generates high voltage (max. 20, 000V) and high current (12-13A), and are different from the halogen lamp specification. Install the dust cover after confirming the locking state between bulb and bulb holder. When testing the HID head lamp, turn the power on or off with switch between power supply and lamp because of high voltage. Do not operate the head lamp switch with the bulb not installed, because it generates spark momently.

Head Lamp Aiming Instructions

The head lamps should be aimed with the proper beam-setting equipment, and in accordance with the equipment manufacturer's instructions.

Note. If there are any regulations pertinent to the aiming of head lamps in the area where the vehicle is to be used, adjust so as to meet those requirements.

Alternately turn the adjusting gear to adjust the head lamp aiming. If beam-setting equipment is not available, proceed as follows

Scheme 16

1. Inflate the tires to the specified pressure and remove any loads from the vehicle except the driver, spare tire, and tools.
2. The vehicle should be placed on a flat floor.
3. Draw vertical lines (Vertical lines passing through respective head lamp centers) and a horizontal line (Horizontal line passing through center of head lamps) on the screen.
4. With the head lamp and battery in normal condition, aim the head lamps so the brightest portion falls on the vertical lines. Vertical (Low/High)

Scheme 17

Head lamp

Fog & DRL lamp

Scheme 18

Scheme 19

1. General Type (VOR) Turn the low beam on without driver aboard. The cut-off line should be projected in the allowable range (shaded region) shown in the picture. If head lamp leveling device is equipped, adjust the head lamp leveling device switch with 0 positions.
2. Turn the front fog lamp on with driver seated in the vehicle. The cut-off line should be projected in the allowable range shown in the picture.

Head lamp fogging

Check the below instruction procedure when the head lamp is fogged.

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

1. Disconnect the negative (-) battery terminal.
2. Remove the mirror holder (A) from the outside mirror assembly. NOTE: Be careful not to damage the fixing clip
3. Remove the door mirror housing (A) after loosening a screw.
4. Remove the door mirror cover (A).
5. Loosen the mirror turn signal lamp mounting screw.
6. Remove the door mirror turn signal lamp (B) after disconnecting the connector (A).

Scheme 25

Door Mirror Turn Signal Lamp

1. Install the door mirror turn signal lamp.
2. Install the door mirror cover and housing.
3. Install the door mirror.
4. Connect the negative (-) battery terminal.

Inspection

1. Remove the room lamp assembly then check for continuity between terminals.

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

1. Disconnect the negative (-) battery terminal.
2. Detach the lamp lens (A) from the room lamp with a flat-tip screwdriver.
3. Replace the room lamp bulb (A).
4. Separate the room lamp (A) from the roof trim after loosening the screws (2EA).
5. Remove the room lamp (B) after disconnecting the connector (A).

Scheme 36

1. Install the room lamp assembly after connecting the lamp connector.
2. Install the lamp lens after assembling the bulb.

1. Remove the overhead console lamp assembly then check for continuity between terminals. If the continuity is not as specified, replace the map lamp switch.

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. Disconnect the negative (-) battery terminal.
2. Remove the mounting screws (2EA). And then remove the overhead console (A).
3. Remove the overhead console after disconnect the connector (A).
4. If it is necessary to replace the bulb, replace the bulb after removing the lens (A).

Scheme 43

1. Install the overhead console lamp after connecting the connector.
2. Install the lens after tightening 2 screws.

Scheme 44

Scheme 45

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim. (Refer to " «FRONT DOOR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#front-door) ")
3. Disconnect the door mood lamp connectors (A).
4. Remove the door mood lamp (A) after loosening the screws (3EA).
5. If it is necessary to replace the bulb, replace the bulb (A) after disconnecting the connector.

Scheme 46

1. Install the door mood lamp and connector.
2. Install the front door trim.
3. Connect the negative (-) battery terminal.

Scheme 47

1. The SJB can be diagnosed by using the GDS. The SJB communicates with the GDS which then displays inputs and outputs along with codes. It will be able to diagnose defects of hazard lamp switch with GDS quickly. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
2. To diagnose the SJB function, select the vehicle model, BCM and SJB.
3. To consult the present input/out value of SJB, "Current DATA". It provides information of SJB input/output conditions.

Scheme 48

1. Disconnect the negative (-) battery terminal.
2. Remove the audio unit or AVN head unit. (Refer to " «AUDIO UNIT»(/hyundai/santa-fe/iii-2012-2016/remont/entertainment-systems/#audio-system) ") (Refer to " «AVN HEAD UNIT»(/hyundai/santa-fe/iii-2012-2016/remont/entertainment-systems/#audiovideonavigation-system) ")
3. Remove the heat & A/C control module unit. (Refer to «HEATER & AC CONTROL UNIT (MANUAL)»(/hyundai/santa-fe/iii-2012-2016/remont/automatic-hvac-system/#heater-ac-control-unit) . (Refer to «HEATER & AC CONTROL UNIT (DATC)»(/hyundai/santa-fe/iii-2012-2016/remont/automatic-hvac-system/#heater-ac-control-unit) .

1. Install the heater & A/C control module unit.
2. Install the audio or AVN head unit.
3. Connect the negative (-) battery terminal.

Scheme 49

Scheme 50

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad side cover.
3. Remove the lower crash pad switch assembly (A) after loosening the screws (3EA).
4. Remove the rheostat switch connector (A).
5. Check for intensity of new rheostat switch. If the light intensity of the lamps changes smoothly without any flickering when the rheostat is turned, it can be assumed that the rheostat is normal.

Scheme 51

Front Fog Lamp Switch

1. With the fog lamp switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multifunction switch.

Scheme 52

Scheme 53

Scheme 54

1. Disconnect the negative (-) battery terminal.
2. Remove the front bumper. (Refer to " «FRONT BUMPER COVER»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#front-bumper-grille) ")
3. Remove the front fog lamp assembly (A) after loosening the mounting screws (4EA).
4. Remove the front fog lamp (A) by turning in the counter clock-wise direction after disconnecting the connector.

Scheme 55

1. Install the front fog lamp bulb.
2. Connect the front fog lamp connector.
3. Install the front bumper.

Scheme 56

1. Disconnect the negative (-) battery terminal.
2. Remove the license lamp lens (A) from the panel after loosening a screw.
3. Replace the bulb (B) after removing the license lamp (A).

Scheme 57

Scheme 58

1. Install the bulb.
2. Install the license lamp lens.

High Mounted Stop Lamp

1. Disconnect the negative (-) battery terminal.
2. Remove the rear spoiler. (Refer to " «REAR SPOILER»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#body-side-molding) ")
3. Remove the high mounted stop lamp assembly (A) after loosening screws (4EA).

Scheme 59

1. Install the high mounted stop lamp.
2. Install the rear spoiler.
3. Connect the negative (-) battery terminal.

Scheme 60

Scheme 61

Scheme 62

1. Disconnect the negative (-) battery terminal.
2. Remove the luggage room lamp lens (A) with a flat-tip screwdriver after loosening the screws (2EA).
3. Remove the luggage room lamp bulb (A).
4. Remove the luggage room lamp assembly (A) after disconnecting the connector.
5. If it is necessary to replace the bulb, replace the luggage room lamp bulb.

1. Install the luggage room lamp assembly after connecting the lamp connector.

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

1. Disconnect the negative (-) battery terminal.
2. Loose the screws (2EA) holding the rear combination lamp then disconnect the connector (A) then remove the outside rear combination lamp (B). [LED Type] [Bulb Type]
3. If it is necessary to replace the bulb, remove the rear combination cover (A).
4. Remove the bulb (A) after disconnecting the connector.
5. Remove the tailgate trim. (Refer to «TAIL GATE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#tail-gate) .
6. Remove the inside rear combination lamp assembly (A) after loosening the nuts (4EA) and disconnecting the connector.
7. Remove the bulb (B) after separating the inside rear combination lamp assembly (A). [LED Type] [Bulb Type]
8. If it is necessary to replace the bulb, remove the bulb after removing the tailgate cover.

1. Install the tailgate combination lamp assembly after assembling the bulb.
2. Install the lamp cover to the tailgate after connecting the lamp connector.
3. Install the rear combination lamp assembly after assembling the bulbs and connecting the lamp connector.
