Tail Gate Hyundai Santa Fe III

Scheme 67

1. After loosening the tail gate hinge (A) mounting bolt, adjust the tail gate by moving it up or down, or right or left.
2. Adjust the tail gate height by turning the tail gate overslam bumpers (B).
3. After loosening the tail gate striker (C) mounting bolts, adjust the tail gate striker by moving it up or down, or right or left.

Scheme 68

Replacement

Information

1. When removing and installing the tail gate, an assistant is necessary.

Scheme 69

Scheme 70

Scheme 71

1. Remove the tail gate trim. Refer to «TAIL GATE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#tail-gate) .
2. Remove the tail gate upper trim. Refer to «TAIL GATE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#tail-gate) .
3. Remove the tail gate side trim. Refer to «TAIL GATE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#tail-gate) .
4. Disconnect the washer nozzle hose (A) and high mounted stop lamp connector (B).
5. Using a screwdriver, lift the socket clips (A) up slightly on both ends of the tail gate lifter (B).
6. Disconnect the connectors and tail gate wiring harness (A).
7. After loosening the mounting bolts, then remove the tail gate assembly (B). Tightening torque: 21.6 ~ 26.5 N.m (2.2 ~ 2.7 kgf.m, 15.9 ~ 19.5 lb-ft)
8. Install in the reverse order of removal. NOTE: Make sure the tail gate locks/unlocks and opens/closes properly. Adjust the tail gate alignment. Make sure the connectors are connected in properly. Replace any damaged clips.

Scheme 72

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 73

Scheme 74

Scheme 75

1. Remove the tail gate inside handle caps (A).
2. After loosening the mounting bolts, then remove the tail gate inside handle (A).
3. After loosening the mounting screws and clips, then remove the tail gate trim (A).
4. Install in the reverse order of removal. Information Replace any damaged clips.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 76

1. Using a screwdriver or remover, remove the tail gate upper trim (A).
2. Install in the reverse order of removal. Information Replace any damaged clips.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 77

1. Remove the tail gate trim. Refer to «TAIL GATE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#tail-gate) .
2. Remove the tail gate upper trim. Refer to «TAIL GATE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#tail-gate) .
3. After loosening the mounting screw, then remove the tail gate side trim (A).
4. Install in the reverse order of removal. Information Replace any damaged clips.

Scheme 78

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 79

Scheme 80

1. Remove the tail gate trim. Refer to «TAIL GATE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#tail-gate) .
2. Disconnect the tail gate latch connector (A).
3. After loosening the mounting bolts, then remove the tail gate latch assembly (A). Tightening torque: 6.9 ~ 10.8 N.m (0.7 ~ 1.1 kgf.m, 5.1 ~ 8.0 lb-ft)
4. Install in the reverse order of removal. NOTE: Make sure the tail gate locks/unlocks and opens/closes properly. Adjust the tail gate alignment. Make sure the connectors are connected in properly.

Scheme 81

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 82

Scheme 83

Scheme 84

Scheme 85

1. Remove the tail gate trim. Refer to «TAIL GATE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#tail-gate) .
2. Disconnect the license lamp connector and back view camera connector (A).
3. Loosen the tail gate back panel mounting nuts (A). [Side] [Center]
4. Using a screwdriver or remove the tail gate back panel (A).
5. Install in the reverse order of removal. Information Make sure the connector is plugged in properly. Replace any damaged clips.

Information

1. Take care to not let the tailgate fall on you as the lifts are removed. Have a helper hold the tailgate open, or use a secure method to hold it open.

Scheme 86

1. Using a screwdriver, lift up slightly the socket clips (A) of both ends on the lifter (B), and then remove the lifter from the bracket (C).
2. Push the socket of the lifter into the bracket for installation. Information Make sure the tail gate locks and opens properly and locks securely.

Scheme 87

1. Remove the tail gate weatherstrip (A). NOTE: Do not apply sealant to the body.
2. Install in the reverse order of removal. Information Install the weatherstrip aligned with canter line (B).
