Fender Hyundai Santa Fe III

Exterior Body Panels 6 illustrations ~141 words

Scheme 37

Scheme 37: Component Location
Scheme 37: Component Location

Replacement

Note. Be careful not to damage the fender and body.

Information

  1. When removing the clips, use a clip remover.

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42
  1. Remove the head lamps. Refer to «HEAD LAMPS»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-lights/#lighting-system) .
  2. Remove the side sill molding. Refer to «SIDE STILL MOLDING»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#body-side-molding) .
  3. Loosen the front wheel guard mounting clips and screws.
  4. Remove the fender side repeater lamp (A).
  5. Disconnect the fender side repeater lamp connector (B).
  6. Using a screwdriver or remover, remove the delta garnish (A).
  7. After loosening the mounting clips, then remove the fender side cover (A).
  8. After loosening the mounting screws, bolts, nut, then remove the fender assembly (A).
  9. Install in the reverse order of removal. Information Make sure the connector is plugged in properly. Replace any damaged clips.
