Front Bumper & Grille Hyundai Santa Fe III

Scheme 58

Scheme 59

Replacement

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

1. Loosen the radiator upper cover mounting bolts and clips.
2. Loosen the front bumper lower mounting clips.
3. After loosening the front bumper side's mounting screw, then disconnect the side's.
4. Disconnect the fog lamp connector (A).
5. Remove the front bumper cover (A).
6. Install in the reverse order of removal. Information Make sure the connector is plugged in properly. Replace any damaged clips.

Scheme 65

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 66

1. Remove the front bumper cover. (Refer to Front Bumper - " «FRONT BUMPER COVER»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#front-bumper-grille) ")
2. Loosen the radiator grill mounting screws.
3. Unlock the lock pins (B) by pushing it up with a screwdriver or remover and then remove the radiator grill (A).
4. Install in the reverse order of removal. Information Replace any damaged clips.

See also:
• FRONT BUMPER COVER
