Airbag Modules & Clock Spring Hyundai Santa Fe III

Description

Driver Airbag (DAB) is installed in the steering wheel and electrically connected to SRSCM via the clock spring. It protects the driver by deploying the airbag when frontal crash occurs. The SRSCM determines deployment of the Driver Airbag (DAB).

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. Disconnect the battery negative cable and wait for at least three minutes before beginning work.
2. Remove the driver airbag module by putting in a flat tool (Ø5mm) into the guide hole and then press the omega spring.
3. Remove the wiring fixing clip (C) and disconnect the horn connector (A).
4. Release the connector locking pin, then disconnect the driver airbag module connector (C). CAUTION: The removed airbag module should be stored in a clean, dry place with the pad cover facing up.
5. Remove the steering wheel and steering wheel column shroud. Refer to «STEERING COLUMN AND SHAFT»(/hyundai/santa-fe/iii-2012-2016/remont/electronic-steering/#electric-power-steering) .
6. Disconnect the clock spring and horn connector, then remove the clock spring.

Driver Airbag (DAB)

If any improper parts are found during the following inspection, replace the airbag module with a new one.

Scheme 6

1. Check pad cover for dents, cracks or deformities.
2. Check the airbag module for denting, cracking or deformation.
3. Check hooks and connectors for damage, terminals for deformities, and harness for binds.
4. Check airbag inflator case for dents, cracks or deformities.
5. Install the airbag module to the steering wheel to check for fit or alignment with the wheel.

Scheme 7

1. If, as a result of the following checks, even one abnormal point is discovered, replace the clock spring with a new one.
2. Check connectors and protective tube for damage, and terminals for deformities.

Scheme 8

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable from the battery and wait for at least three minutes before beginning work.
3. Connect the clock spring harness connector and horn harness connector to the clock spring.
4. Set the center position by setting the marks between the clock spring and the cover into line. The mark (<-->) should be matched by turning the clock spring clockwise to the stop and then 2.0 revolutions counterclockwise.
5. Install the steering wheel column shroud and the steering wheel. Refer to «STEERING COLUMN AND SHAFT»(/hyundai/santa-fe/iii-2012-2016/remont/electronic-steering/#electric-power-steering) .
6. Connect the driver airbag (DAB) module connector and horn connector, and then install the driver airbag (DAB) module on the steering wheel. NOTE: First, fix the wire on the fixing clip and then connect the connector.
7. Connect the battery negative cable.
8. After installing the driver airbag, confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off. Make sure horn button works.

Passenger Airbag (PAB) module is located in the passenger crash pad. This PAB contains 2 firing squibs of airbag and 1 firing squib of active vent. Depending of crash speed or the tightening of seat belt, it is decided a timing about both 2 firing squibs of airbag and 1 firing squib of active vent. At the moment of vehicles collisions, the firing squib of active vent make airbag distended and then consecutively leaked gases of airbag through a hole at once. These operations reduce an injury of the passenger's head. At first, the active vent sets a rapid deployment of airbag by keeping the pressure, after deployment of airbag it emits the gases of upper airbag. The Working Principle of Tether Cutter: When receive an electrical signal, Tether Cutter cuts a strap which is been attached Active vent in order to open a hole of upper airbag.

The working range of Active Vent

1. If occupant in passenger seat is not belted, active vent is disposed in the end of crash event regardless of crash severity.
2. If occupant is belted and crash severe enough to require 2 stage passenger airbag deployment is occurred, active vent is activated to optimize occupant protection.
3. Low-Speed + Belted: Inflator of Primary Fire + 2 Stage & Active Vent disposal in the end of crash event. CAUTION: Never attempt to measure the circuit resistance of the airbag module (squib) even if you are using the specified tester. If the circuit resistance is measured with a tester, accidental airbag deployment will result in serious personal injury.

Scheme 9

Scheme 10

Scheme 11

1. Disconnect the battery negative cable and wait for at least three minutes before beginning work.
2. Remove the glove box housing. Refer to «GLOVE BOX HOUSING»(/hyundai/santa-fe/iii-2012-2016/remont/gauges-instrument-panels/#crash-pad) .
3. Remove the passenger airbag mounting nuts (A).
4. Disconnect the passenger airbag connector (A) and active vent connector (B).
5. Remove the crash pad. Refer to «MAIN CRASH PAD ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/gauges-instrument-panels/#crash-pad) . NOTE: Replace the crash pad which is damaged while PAB is deployed.
6. Remove the mounting bolts from the crash pad. Then remove the passenger airbag. CAUTION: The removed airbag module should be stored in a clean, dry place with the airbag cushion up.

Scheme 12

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable from battery and wait for at least three minutes before beginning work.
3. Place a passenger airbag on the crash pad and tighten the passenger airbag mounting bolts (A). Tightening torque : 3.9 ~ 5.9 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
4. Install the crash pad. Refer to «MAIN CRASH PAD ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/gauges-instrument-panels/#crash-pad) .
5. Tighten the passenger airbag mounting bolts. Tightening torque : 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-.ft)
6. Connect the passenger airbag harness connector to the SRS main harness connector.
7. Reinstall the glove box housing. Refer to «GLOVE BOX HOUSING»(/hyundai/santa-fe/iii-2012-2016/remont/gauges-instrument-panels/#crash-pad) .
8. Reconnect the battery negative cable.
9. After installing the passenger airbag (PAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

The Side Airbags (SAB) are installed inside the front seat and protects the driver and passenger from danger when side crash occurs. The SRSCM determines deployment of side airbag by using Side Impact Sensor (SIS) signal.

Scheme 13

Removal

1. Disconnect the battery negative cable and wait for at least 3 minutes before beginning work.
2. Remove the front seat assembly. Refer to «FRONT SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#front-seat) .
3. Remove the seat back assembly. NOTE: The side airbag cannot be disassembled from the seat back assembly, so replace the seat back assembly when replacing the side airbag.

Installation

Note. Do not open the lid of the side airbag cover. Make sure that the airbag assembly cover is installed properly. Improper installation may prevent the proper deployment.

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable and wait for at least three minutes.
3. Install the new seat back assembly.
4. Install the front seat assembly. Refer to «FRONT SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#front-seat) .
5. Recline and slide the front seat forward fully, make sure the harness wires are not pinched of interfere with other parts.
6. Reconnect the battery negative cable.
7. After installing the side airbag (SAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

Curtain airbags are installed inside the headliner (LH and RH) and protect the driver and passenger from danger when side crash occurs. The SRSCM determines deployment of curtain airbag by using side impact sensor (SIS) signal.

Scheme 14

Scheme 15

Scheme 16

1. Disconnect the battery negative cable and wait for at least 3 minutes before beginning work.
2. Remove the roof trim. Refer to «ROOF TRIM ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#roof-trim) .
3. Disconnect the curtain airbag harness connector (A).
4. After loosening the mounting bolts and nuts remove the curtain airbag.

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable and wait for at least three minutes.
3. Tighten the curtain airbag mounting bolts and nuts. Tightening torque Bolt: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft) Nunt: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft) CAUTION: Never twist the airbag module when installing it. If the module is twisted, airbag module may operate abnormally.
4. Connect the curtain airbag connector.
5. Install the roof trim. Refer to «ROOF TRIM ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#roof-trim) .
6. Reconnect the battery negative cable.
7. After installing the curtain airbag (CAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

The Knee Airbag (KAB) is installed inside the crash pad lower panel and protects the driver in the event of a frontal crash. The SRSCM determines if and when to deploy the KAB.

Scheme 17

Scheme 18

1. Disconnect the battery negative cable and wait for at least three minutes before beginning work.
2. Remove the crash pad lower panel. Refer to «CRASH PAD LOWER PANEL»(/hyundai/santa-fe/iii-2012-2016/remont/gauges-instrument-panels/#crash-pad) .
3. After loosening the mounting nuts and then remove the knee airbag (A).
4. Disconnect the knee airbag harness connector.

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable and wait for at least three minutes.
3. Connect the knee airbag connector.
4. Tighten the knee airbag mounting nuts. Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
5. Install the crash pad lower panel. Refer to «CRASH PAD LOWER PANEL»(/hyundai/santa-fe/iii-2012-2016/remont/gauges-instrument-panels/#crash-pad) .
6. Install the crash pad side cover. Refer to «CRASH PAD SIDE COVER»(/hyundai/santa-fe/iii-2012-2016/remont/gauges-instrument-panels/#crash-pad) .
7. Reconnect the battery negative cable.
8. After installing the knee airbag, confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

Airbag Disposal

Special tool required

Deployment tool 0957A-34100A

Before scrapping any airbags or side airbags (including those in a whole vehicle to be scrapped), the airbags or side airbags must be deployed. If the vehicle is still within the warranty period, before deploying the airbags or side airbags, the Technical Manager must give approval and/or special instruction. Only after the airbags or side airbags have been deployed (as the result of vehicle collision, for example), can they be scrapped. If the airbags or side airbags appear intact (not deployed), treat them with extreme caution. Follow this procedure.

Deploying airbags in the vehicle

If an SRS equipped vehicle is to be entirely scrapped, its airbags or side airbags should be deployed while still in the vehicle. The airbags or side airbags should not be considered as salvageable parts and should never be installed in another vehicle.

1. Turn the ignition switch OFF, and disconnect the battery negative cable and wait at least three minutes.
2. Confirm that each airbag or side airbag is securely mounted.
3. Confirm that the special tool is functioning properly by following the check procedure. Driver's Airbag: Remove the driver's airbag and install the SST (0957A-3Q100). Install the driver's airbag on the steering wheel. Front Passenger's Airbag: Remove the glove box housing, and then disconnect the connector between the front passenger's airbag and SRS main harness. Install the SST(0957A-3Q100). Side Airbag: Disconnect the 2P connector between the side airbag and wire harness. Install the SST (0957A-2W100). Curtain Airbag: Disconnect the 2P connector between the curtain airbag and wire harness. Install the SST(0957A-3Q100). Knee Airbag: Disconnect the 2P connector between the knee airbag and wire harness. Install the SST (0957A-3F100). Seat Belt Pretensioner: Disconnect the 2P connector from the seat belt pretensioner. Install the SST (0957A-3Q100). Emergency Fastening Device: Disconnect the 2P connector from the anchor pretensioner. Install the SST (0957A-3Q100).
4. Place the deployment tool at least thirty feet (10 meters) away from the airbag.
5. Connect a 12 volt battery to the tool.
6. Push the tool's deployment switch. The airbag should deploy (deployment is both highly audible and visible: a loud noise and rapid inflation of the bag, followed by slow deflation)
7. Dispose of the complete airbag. No parts can be reused. Place it in a sturdy plastic bag and seal it securely.

Deploying the airbag out of the vehicle

If an intact airbag has been removed from a scrapped vehicle, or has been found defective or damage during transit, storage or service, it should be deployed as follows

1. Confirm that the special is functioning properly by following the check procedure on this page.
2. Position the airbag face up, outdoors on flat ground at least thirty feet (10 meters) from any obstacles or people.

Disposal of damaged airbag

1. If installed in a vehicle, follow the removal procedure of driver's airbag front passenger's and side airbag.
2. In all cases, make a short circuit by twisting together the two airbag inflator wires.
3. Package the airbag in exactly the same packing that the new replacement part come in.
