Restraints - General Information Hyundai Santa Fe III

The supplemental restraint system (SRS) is designed to supplement the seat belt to help reduce the risk or severity of injury to the driver and passenger by activating and deploying the driver, passenger, side airbag and belt pretensioner in certain frontal or side collisions.

The SRS (Airbag) consists of; a driver side airbag module located in the center of the steering wheel, which contains the folded cushion and an inflator unit; a passenger side airbag module located in the passenger side crash pad contains the folded cushion assembled with inflator unit; side airbag modules located in the front seat contain the folded cushion and an inflator unit; curtain airbag modules located inside of the headliner which contains folded cushions and inflator units. The impact sensing function of the SRSCM is carried out by electronic accelerometer that continuously measure the vehicle's acceleration and delivers a corresponding signal through amplifying and filtering circuitry to the microprocessor.

SRSCM (SRS Control Module)

SRSCM will detect front impact with front impact sensor, and side impact with side impact sensor, to determine airbag module deployment.

1. DC/DC converter: DC/DC converter in power supply unit includes up/down transformer converter, and provide ignition voltage for 2 front airbag ignition circuits and the internal operation voltage of the SRSCM. If the internal operation voltage is below critical value setting, it will perform resetting.
2. Back up power supply: SRSCM has separate back up power supply, that will supply deployment energy instantly in low voltage condition or upon power failure by front crash.
3. Self diagnosis: SRSCM will constantly monitor current SRS operation status and detect system failure while vehicle power supply is on, system failure may be checked with trouble codes using GDS.
4. Airbag warning lamp on: Upon detecting error, the module will transmit signal to SRSCM indicator lamp located at cluster. MIL lamp will indicate to the driver of SRS error. Upon ignition key on, SRS lamp will turn on for about six seconds.
5. Trouble code registration: Upon error occurrence in the system, SRSCM will store DTC's corresponding to the error. A DTC can be cleared only by GDS. However, if an internal fault code is logged or if a crash is recorded, the fault code(s) cannot be cleared.
6. Self diagnostic connector: Data stored in SRSCM memory will be output to GDS or other external output devices through connector located below the driver side crash pad.
7. Once an airbag is deployed. The SRSCM should not be used again and should be replaced.
8. The SRSCM will determine if the passenger seat belt is engaged then deploy airbags in a crash event accordingly.
9. Side airbag deployment will be determined by SRSCM that detects satellite sensor impact signal upon a side crash, regardless of to seat belt condition.
10. SRSCM senses a vehicle rollover by using the rollover sensors. SAB, CAB, BPT will be able to expand if mechanic moves the SRSCM during IGN ON state. For this reason, disconnect the battery negative cable during the SRSCM repair procedure.
11. Check for the normal operation of SRSCM after repair procedure.

Tightening Torques

Special Service Tools

Tool (Number and Name) Illustration Use Deployment tool 0957A-34100A Airbag deployment tool. Deployment adapter 0957A-3F100 Use with deployment tool. (KAB) Deployment adapter 0957A-2W100 Use with deployment tool. (SAB) Deployment adapter 0957A-3Q100 Use with deployment tool. (DAB, PAB, CAB, BPT, EFD) Dummy 0957A-38200 Simulator to check the resistance of each wiring harness. Dummy adapter 0957A-3F000 Use with dummy. (KAB) Dummy adapter 0957A-2W200 Use with dummy. (SAB) Dummy adapter 0957A-2G000 Use with dummy. (DAB, PAB, CAB, BPT, EFD) DAB: Driver Airbag PAB: Passenger Airbag SAB: Side Airbag CAB: Curtain Airbag KAB: Knee Airbag BPT: Seat Belt Pretensioner EFD: Emergency Fastening Device

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

General Precautions

Please read the following precautions carefully before performing the airbag system service.

Observe the instructions described in this service information, or the airbags could accidentally deploy and cause damage or injuries.

1. Except when performing electrical inspections, always turn the ignition switch OFF and disconnect the negative cable from the battery, and wait at least three minutes before beginning work.

Note. The contents in the memory are not erased even if the ignition switch is turned OFF or the battery cables are disconnected from the battery.

Scheme 25

1. Use the replacement parts which are manufactured to the same standards as the original parts and quality. Do not install used SRS parts from another vehicle. Use only new parts when making SRS repairs.
2. Carefully inspect any SRS part before you install it. Do not install any part that shows signs of being dropped or improperly handled, such as dents, cracks or deformation.
3. Before removing any of the SRSCM parts (including the disconnection of the connectors), always disconnect the SRSCM connector.

Airbag Handling and Storage

Do not disassemble the airbags; it has no serviceable parts. Once an airbag has been deployed, it cannot be repaired or reused.

For temporary storage of the air bag during service, please observe the following precautions.

Scheme 26

1. Store the removed airbag with the pad surface up.
2. Keep free from any oil, grease, detergent, or water to prevent damage to the airbag assembly.
3. Store the removed airbag on secure, flat surface away from any high heat source (exceeding 85 C/185 F).
4. Never perform electrical inspections to the airbags, such as measuring resistance.
5. Do not position yourself in front of the airbag assembly during removal, inspection, or replacement.
6. Refer to «DISPOSAL OF DAMAGED AIRBAG»(/hyundai/santa-fe/iii-2012-2016/remont/airbag/#airbag-modules-clock-spring__disposal-of-damaged-airbag) procedures for disposal of the damaged airbag.
7. Be careful not to bump or impact the SRS unit or the side impact sensors or front impact sensors whenever the ignition switch is ON, wait at least three minutes after the ignition switch is turned OFF before begin work.
8. During installation or replacement, be careful not to bump (by impact wrench, hammer, etc.) the area around the SRS unit and the side impact sensor and the front impact sensors. The airbags could accidentally deploy and cause damage or injury.
9. Replace the front airbag module, SRSCM, FIS when deploying the front airbag. Replace the airbag wiring when the airbag wiring get damaged. Replace the side airbag module, the curtain airbag module, SRSCM, SIS when deploying the side airbag. Replace the airbag when the airbag wiring get damaged.
10. After a collision in which the airbags or the side air bags did not deploy, inspect for any damage or any deformation on the SRS unit and the side impact sensors. If there is any damage, replace the SRS unit, the front impact sensor and/or the side impact sensors.
11. Do not disassemble the SRS unit, the front impact sensor or the side impact sensors.
12. Turn the ignition switch OFF, disconnect the battery negative cable and wait at least three minutes before beginning installation or replacement of the SRS unit.
13. Be sure the SRS unit, the front impact sensor and side impact sensors are installed securely with the mounting bolts.
14. Do not spill water or oil on the SRS unit, or the front impact sensor or the side impact sensors and keep them away from dust.
15. Store the SRS unit, the front impact sensor and the side impact sensors in a cool (15 ~ 25 C/59 ~ 77 F) and dry (30 ~ 80% relative humidity, no moisture) area.

Wiring Precautions

SRS wiring can be identified by special yellow outer covering. Observe the instructions described in this service information.

Scheme 27

Scheme 28

1. Never attempt to modify, splice, or repair SRS wiring. If there is an open or damage in SRS wiring, replace the harness.
2. Be sure to install the harness wires so that they are not pinched, or interfere with other parts.
3. Make sure all SRS ground locations are clean, and grounds are securely fastened for optimum metal-to-metal contact. Poor grounding can cause intermittent problems that are difficult to diagnose.

Scheme 29

1. When using electrical test equipment, insert the probe of the tester into the wire side of the connector. Do not insert the probe of the tester into the terminal side of the connector, and do not tamper with the connector.
2. Use a u-shaped probe. Do not insert the probe forcibly.
3. Use specified service connectors for troubleshooting. Using improper tools could cause an error in inspection due to poor metal contact.

Spring-Loaded Lock Connector

Some SRS system connectors have a spring-loaded lock.

Disconnecting

To release the lock, pull the spring-loaded sleeve (A) and the slider (B), while holding the opposite half of the connector.

Pull the connector halves apart. Be sure to pull on the sleeve and not on the connector half.

Scheme 30

Connecting

Hold both connector halves and press firmly until the projection (C) of the sleeve-side connector clicks to lock.

Scheme 31

Warning Lamp Behavior after Ignition On

As soon as the operating voltage is applied to the SRSCM ignition input, the SRSCM activates the warning lamp for a LED lamp check.

The lamp shall turn on for 6 seconds during the initialization phase and be turned off afterward.

To alert the driver, the warning lamp shall turn on for 6 seconds and off for one second then on continuously after the operating voltage is applied if any active fault exists.

Scheme 32

Scheme 33

Scheme 34

Scheme 35

1. Active fault or historical fault counter is greater or equal to 10.
2. Normal or historical fault counter is less than 10.
3. When turning the ignition switch ON during variant coding (EOL) mode, the airbag warning lamp illuminates and blinks at intervals of 1 second till the coding is completed. In case the variant coding is completed normally, the airbag warning lamp is turned on for 6 seconds, and then turned off. Otherwise the airbag warning lamp continuously blinks at intervals of 1 second. In case the variant coding is completed normally. In case the variant coding is not completed. When there is active fault in airbag system or SRSCM internal fault, the variant coding (EOL) can't be completed. In this case, do the variant coding (EOL) procedure again after troubleshooting with the GDS.

SRSCM Independent Warning Lamp Activation

There are certain fault conditions in which the SRSCM cannot function and thus cannot control the operation of the standard warning lamp. In these cases, the standard warning lamp is directly activated by appropriate circuitry that operates independently of the SRSCM. These cases are

1. Loss of battery supply to the SRSCM: warning lamp turned on continuously.
2. Loss of internal operating voltage: warning lamp turned on continuously.
3. Loss of Microprocessor operation: warning lamp turned on continuously.
4. SRSCM not connected: warning lamp turned on continuously.

Telltale Lamp Activation

The Telltale Lamp indicates the Passenger Airbag (PAB) enabled and disabled status based on occupant status of passenger seat. If the passenger seat is empty or occupied with a child (or child seat), the Passenger Airbag is disabled and the Telltale Lamp is turned ON to inform the driver that the PAB is disabled. As soon as operating voltage is applied to the SRSCM ignition input, the SRSCM activates telltale lamp prove out. ODS (Occupant Detection System) will send an indeterminate status to the SRSCM as a default setting for passenger airbag deployment during the prove out period.

After ignition on, telltale lamp will turn on for 4 seconds and turn off for 3 seconds during the initialization phase and be turned ON afterward until receipt of valid enabled message from ODS system.

Scheme 36

Component Replacement After Deployment

Note. Before doing any SRS repairs, use the GDS to check for DTCs. Refer to AIRBAG (PODS-F) SYSTEM DIAGNOSIS - SANTA FE article for the Diagnostic Trouble Code list for repairing of the related DTCs.

When the front airbag(s) deploys after a collision, replace the following items.

1. SRSCM
2. Deployed airbag(s)
3. Seat belt pretensioner(s)
4. Front impact sensors
5. SRS wiring harnesses
6. Inspect the clock spring for heat damage. If any damage found, replace the clock spring.

When the side/curtain airbag(s) deploys after a collision, replace the following items.

1. SRSCM
2. Seat belt pretensioner(s)
3. Deployed airbag(s)
4. Side impact sensor(s) for the deployed side(s)
5. SRS wiring harnesses

After the vehicle is completely repaired, confirm the SRS airbag system is OK.

1. Turn the ignition switch ON; the SRS indicator should come on for about six seconds and then go off.

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

See also:
• DISPOSAL OF DAMAGED AIRBAG
• AIRBAG (PODS-F) SYSTEM DIAGNOSIS - SANTA FE
