Ignition System - g3.5 DOHC Hyundai Santa Fe II рестайлинг

Description

Ignition timing is controlled by the electronic control ignition timing system. The standard reference ignition timing data for the engine operating conditions are preprogrammed in the memory of the ECM (Engine Control Module).

The engine operating conditions (speed, load, warm-up condition, etc.) are detected by the various sensors. Based on these sensor signals and the ignition timing data, signals to interrupt the primary current are sent to the ECM. The ignition coil is activated, and timing is controlled.

On-vehicle Inspection

Spark Test

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

1. Remove the ignition coil connector (A). NOTE: When removing the ignition coil connector, pull the lock pin (A) and push the clip (B).
2. Remove the ignition coil (A).
3. Using a spark plug socket, remove the spark plug.
4. Install the spark plug to the ignition coil.
5. Ground the spark plug to the engine.
6. Check if spark occurs while engine is being cranked. NOTE: To prevent fuel being injected from injectors while the engine is being cranked, disconnect the fuel pump connector. Crank the engine for no more than 5 ~ 10 seconds.
7. Inspect all the spark plugs.
8. Using a spark plug socket, install the spark plug.
9. Install the ignition coil.
10. Reconnect the ignition coil connector.

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

1. Remove the ignition coil connector (A). NOTE: When removing the ignition coil connector, pull the lock pin (A) and push the clip (B).
2. Remove the ignition coil (A).
3. Using a spark plug socket, remove the spark plug. CAUTION: Be careful that no contaminates enter through the spark plug holes.
4. Inspect the electrodes (A) and ceramic insulator (B). Inspection Of Electrodes ELECTRODES INSPECTION CHART Condition Dark deposits White deposits Description Fuel mixture too rich Low air intake Fuel mixture too lean Advanced ignition timing Insufficient plug tightening torque
5. Check the electrode gap (A). Standard : 1.0 ~ 1.1 mm (0.0394 ~ 0.0433 in.)

Scheme 91

1. Measure the primary coil resistance between terminals (+) and (-). Standard value: 0.62ohms ± 10%

Scheme 92

Scheme 93

Scheme 94

1. Remove the engine cover.
2. Disconnect the ignition coil connector (A). NOTE: When removing the ignition coil connector, pull the lock pin (A) and push the clip (B).
3. Remove the ignition coil (A).
4. Installation is the reverse of removal.
