Specifications
Ignition System
| Items | Specification | ||
|---|---|---|---|
| Ignition coil | Primary resistance | 0.62 ± 10 % | |
| Secondary resistance | 7.0kohms ± 15 % | ||
| Spark plugs | Type | M12 | SILIKR7B11/RER8WMPB4 |
| Gap | 1.0 ~ 1.1mm (0.0394 ~ 0.0433in.) | ||
IGNITION SYSTEM SPECIFICATIONS
Starting System
| Items | Specification | ||
|---|---|---|---|
| Starter | Rated voltage | 12 V, 1.4 kW | |
| No. of pinion teeth | 8 | ||
| No-load characteristics | Voltage | 11.5 V | |
| Ampere | 90A, MAX | ||
| Speed | 2, 600 rpm, MIN | ||
STARTING SYSTEM SPECIFICATIONS
Charging System
| Items | Specification | |
|---|---|---|
| Alternator | Rate voltage | 13.5 V, 150A |
| Speed in use | 1, 500 ~ 18, 000 rpm | |
| Voltage regulator | IC regulator built-in type | |
| Regulator setting voltage | 11.7 ~ 12.3V | |
| Battery | Type | 54 - 26 FL |
| Cold cranking amperage [at -18°C(-0.4°F)] | 600 A | |
| Reserve capacity | 110 min | |
| Specific gravity [at 25°C (77°F)] | 1.280 ± 0.01 | |
CHARGING SYSTEM SPECIFICATIONS
| CAUTION | COLD CRANKING AMPERAGE is the amperage a battery can deliver for 30 seconds and maintain a terminal voltage of 7.2V or greater at a specified temperature. RESERVE CAPACITY RATING is amount of time a battery can deliver 25A and maintain a minimum terminal voltage of 10.5V at 26.7°C (80.1°F). |
Scheme 47
Scheme 48
Troubleshooting
Ignition System
| Symptom | Suspect area | Remedy |
|---|---|---|
| Engine will not start or is hard to start (Cranks OK) | Ignition lock switch | Inspect ignition lock switch, or replace as required |
| Ignition coil | Inspect ignition coil, or replace as required | |
| Spark plugs | Inspect spark plugs, or replace as required | |
| Ignition wiring disconnected or broken | Repair wiring, or replace as required | |
| Rough idle or stalls | Ignition wiring | Repair wiring, or replace as required |
| Ignition coil | Inspect ignition coil, or replace as required | |
| Engine hesitates/poor acceleration | Spark plugs and spark plug cables | Inspect spark plugs/cable, or replace as required |
| Ignition wiring | Repair wiring, or replace as required | |
| Poor mileage | Spark plugs and spark plug cables | Inspect spark plugs/cable, or replace as required |
IGNITION SYSTEM TROUBLESHOOTING
Charging System
| Symptom | Suspect area | Remedy |
|---|---|---|
| Charging warning indicator does not light with ignition switch "ON" and engine off. | Fuse blown | Check fuses |
| Light burned out | Replace light | |
| Wiring connection loose | Tighten loose connection | |
| Electronic voltage regulator | Disconnect the voltage regulator to see if light turns off. If light turns off, replace voltage regulator. | |
| Charging warning indicator does not go out with engine running. (Battery requires frequent recharging) | Drive belt loose or worn | Adjust belt tension or replace belt |
| Battery cable loose, corroded or worn | Inspect cable connection, repair or replace cable | |
| Electronic voltage regulator or alternator | Disconnect the voltage regulator or alternator to see if light turns off. If light turns off, replace voltage regulator. | |
| Wiring | Repair or replace wiring | |
| Overcharge | Electronic voltage regulator | Disconnect the voltage regulator to see if light turns off. If light turns off, replace voltage regulator. |
| Voltage sensing wire | Repair or replace wiring | |
| Discharge | Drive belt loose or worn | Adjust belt tension or replace belt |
| Wiring connection loose or short circuit | Inspect wiring connection, repair or replace wiring | |
| Electronic voltage regulator or alternator | Disconnect the voltage regulator or alternator to see if light turns off. If light turns off, replace voltage regulator. | |
| Poor grounding | Inspect ground or repair | |
| Worn battery | Replace battery |
CHARGING SYSTEM TROUBLESHOOTING
Starting System
| Symptom | Suspect area | Remedy |
|---|---|---|
| Engine will not crank | Battery charge low | Charge or replace battery |
| Battery cables loose, corroded or worn out | Repair or replace cables | |
| Transaxle range switch (Vehicle with automatic transaxle only) | Refer to AUTOMATIC TRANSAXLE SYSTEM - (A6LF2) - 3.5L | |
| Fuse blown | Replace fuse | |
| Starter motor faulty | Replace | |
| Ignition switch faulty | Replace | |
| Engine cranks slowly | Battery charge low | Charge or replace battery |
| Battery cables loose, corroded or worn out | Repair or replace cables | |
| Starter motor faulty | Replace | |
| Starter keeps running | Starter motor | Replace |
| Ignition switch | Replace | |
| Starter spins but engine will not crank | Short in wiring | Repair wiring |
| Pinion gear teeth broken or starter motor | Replace | |
| Ring gear teeth broken | Replace fly wheel or torque converter |
STARTING SYSTEM TROUBLESHOOTING
Reference Service Tools
SPECIAL SERVICE TOOLS Tool (Number and name) Illustration Use Micro-570 Battery checker (Using with Thermal Printer_182-003A)
Scheme 49
The Micro 570 Analyzer
The Micro 570 Analyzer provides the ability to test the charging and starting systems, including the battery, starter and alternator.
| CAUTION | * Because of the possibility of personal injury, always use extreme caution and appropriate eye protection when working with batteries. * When charging battery by test result, Battery must be fully charged. To get accurate test result, battery surface voltage must have subsided ahead before test when you test battery after charged. (See following Battery Test Results)™ |
Scheme 50
Keypad
The Micro 570 button on the key pad provide the following functions
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
Scheme 59
Scheme 60
Scheme 61
Scheme 62
Scheme 63
Scheme 64
Scheme 65
Scheme 66
Scheme 67
Scheme 68
Scheme 69
Scheme 70
Scheme 71
Scheme 72
Scheme 73
Scheme 74
Scheme 75
Scheme 76
Scheme 77
Scheme 78
Scheme 79
Scheme 80
- Connect the tester to the battery. Red clamp to battery positive (+) terminal. Black clamp to battery negative (-) terminal. CAUTION: Connect clamps securely. If "CHECK CONNECTION" message is displayed on the screen, reconnect clamps securely.
- The tester will ask if the battery is connected "IN-VEHICLE" or "OUT-OF-VEHICLE". Make your selection by pressing the arrow buttons; then press ENTER.
- Select CCA and press the ENTER button. NOTE: CCA : Cold cranking amps, is an SAE specification for cranking battery at -0.4°F (-18°C).
- Set the CCA value displayed on the screen to the CCA value marked on the battery label by pressing up and down buttons and press ENTER. NOTE: The battery ratings (CCA) displayed on the tester must be identical to the ratings marked on battery label.
- The tester will conduct battery test.
- The tester displays battery test results including voltage and battery ratings. Refer to the following table and take the appropriate action as recommended by the Micro 570. Battery Test Results BATTERY TEST RESULTS Result On Printer Remedy GOOD BATTERY No action is required. GOOD RECHARGE Battery is in a good state. Recharge the battery and use. (Battery may be charged by running the engine at idle for 20 minutes.) CHARGE & RETEST Battery is not charged properly. Charge and test the battery again. (Failure to charge the battery fully may read incorrect measurement value.) REPLACE BATTERY Replace battery and recheck the charging system. Improper connection between battery and vehicle cables may cause "REPLACE BATTERY", retest the battery after removing cables and connecting the tester to the battery terminal directly prior to replacing the battery. BAD CELL-REPLACE Charge and retest the battery. If the Micro 570 recommends "REPLACE BATTERY", replace the battery and recheck the charging system. [Charge and Retest method after battery charge] Battery charge Set battery charger to 'Auto Mode' (The Mode that charging current drops as the battery charges.) and charge battery until charging current down close to zero or the charger alerts you with an alarm when charge is complete. (Minimum charging time recommended: More than 3 hours with Auto Mode that explained above) A. If battery is not fully charged, battery surface voltage will be high while the amount of current charged (CCA) in battery is low. If you measure the battery under this condition, tester may misjudge that battery sulfation occurred because the amount of current in battery is too low in comparison with battery voltage. * Surface voltage: When battery is charged electrolyte temperature increases and chemical reaction become active resulting in an excessive increase of battery voltage. It is known that it takes approximate one day to subside this increased surface voltage completely. Battery Test after charge Do not test battery right after the charge. Test battery after battery surface voltage has subsided as instructed in the following procedure. When battery charge is complete, install the battery in the vehicle. Put IG key to ON position and turn on head lamp with low beam, and wait 5 minutes. (Discharge for 5 minutes) Turn off the head lamp and IG key, and wait 5 minutes. (Waiting for 5 minutes) Remove +, - cable from the battery and test battery. WARNING: Whenever filing a claim for battery, the print out of the battery test results must be attached. Starter Test Procedure
- After the battery test, press ENTER immediately for the starter test.
- Start the engine.
- Cranking voltage and starter test results will be displayed on the screen. Refer to the following table and take the appropriate action as recommended by the Micro 570. Starter Test Results STARTER TEST RESULTS Result On Printer Remedy CRANKING VOLTAGE NORMAL System shows a normal starter draw. CRANKING VOLTAGE LOW Cranking voltage is lower than normal level. Check starter. CHARGE BATTERY The state of battery charge is too low to test. Charge the battery and retest. REPLACE BATTERY Replace battery. If the vehicle is not started though the battery condition of "GOOD BATTERY" is displayed, check wiring for open circuit, battery cable connection, starter and repair or replace as necessary. If the engine does crank, check fuel system. NOTE: When testing the vehicle with old diesel engines, the test result will not be favorable if the glow plug is not heated. Conduct the test after warming up the engine for 5 minutes. Charging System Test Procedure
- Press ENTER to begin charging system test.
- The tester displays the actual voltage of alternator. Press ENTER to continue.
- Turn off all electrical load and rev engine for 5 seconds with pressing the accelerator pedal. (Follow the instructions on the screen)
- The message that engine RPM is detected will be displayed on the screen. Press ENTER to continue.
- If the engine RPM is not detected, press ENTER after revving engine.
- The tester will conduct charging system test during loads off.
- Turn on electrical loads (air conditioner, lamps, audio and etc). Press ENTER to continue.
- The tester will conduct charging system test during loads on.
- Rev engine for 5 seconds with pressing the accelerator pedal. (Follow the instructions on the screen)
- The message that engine RPM is detected will be displayed on the screen. Press ENTER to continue.
- If the engine RPM is not detected, press ENTER after revving engine.
- Turn off electrical loads (air conditioner, lamps, audio and etc). Turn the engine off.
- Charging voltage and charging system test results will be displayed on the screen. Shut off engine end disconnect the tester clamps from the battery. Refer to the following table and take the appropriate action as recommended by the Micro 570. Charging System Test Results CHARGING SYSTEM TEST RESULTS Result On Printer Remedy CHARGING SYSTEM NORMAL/DIODE RIPPLE NORMAL Charging system is normal. NO CHARGING VOLTAGE Alternator does not supply charging current to battery. Check belts, connection between alternator and battery and replace belts or cable or alternator as necessary. LOW CHARGING VOLTAGE Alternator does not supply charging current to battery and electrical load to system fully. Check belts and alternator and replace as necessary. HIGH CHARGING VOLTAGE The voltage from alternator to battery is higher than normal limit during voltage regulating. Check connection and ground and replace regulator as necessary. Check electrolyte level in the battery. EXCESS RIPPLE DETECTED One or more diodes in the alternator is not functioning properly. Check alternator mounting and belts and replace as necessary.
