General Information - Engine Electrical System - g2.4 DOHC — Hyundai Santa Fe II рестайлинг (2010-2012)

Ignition System

Items			Specification
Ignition coil	Primary resistance		0.62 ± 10 % (ohms)
Ignition coil	Secondary resistance		7.0 ± 15 % (kohms)
Spark plugs	Leaded	Type	FK16HQR11
Spark plugs	Leaded	Gap	1.0 ~ 1.1 mm (0.0394 ~ 0.0433 in.)

IGNITION SYSTEM SPECIFICATIONS

Starting System

Items			Specification
Starter	Rated voltage		12V, 1.2kW
	No. of pinion teeth		11
	No-load characteristics	Voltage	11.5V
		Ampere	90A, MAX
		Speed	2, 600rpm, MIN

STARTING SYSTEM SPECIFICATIONS

Charging System

Items		Specification
Alternator	Type	Battery voltage sensing
	Rate voltage	13.5 V, 110A
	Speed in use	1, 000 ~ 18, 000 rpm
	Voltage regulator	IC regulator built-in type
	Regulator setting voltage	14.1 ± 0.3V
	Temperature compensation	3.5 ± 1mV/°C
Battery	Type	54-26GL
	Cold cranking amperage [at -18°C(-0.4°F)]	600A
	Reserve capacity	110min
	Specific gravity [at 25°C (77°F)]	1.280 ± 0.01

CHARGING SYSTEM SPECIFICATIONS

CAUTION

COLD CRANKING AMPERAGE is the amperage a battery can deliver for 30 seconds and maintain a terminal voltage of 7.2V or greater at a specified temperature. RESERVE CAPACITY RATING is amount of time a battery can deliver 25A and maintain a minimum terminal voltage of 10.5V at 26.7°C (80.1°F).

Scheme 1

Scheme 2

Symptom	Suspect area	Remedy
Engine will not start or is hard to start (Cranks OK)	Ignition lock switch	Inspect ignition lock switch, or replace as required
	Ignition coil	Inspect ignition coil, or replace as required
	Spark plugs	Inspect spark plugs, or replace as required
	Ignition wiring disconnected or broken	Repair wiring, or replace as required
Rough idle or stalls	Ignition wiring	Repair wiring, or replace as required
Rough idle or stalls	Ignition coil	Inspect ignition coil, or replace as required
Engine hesitates/poor acceleration	Spark plugs and spark plug cables	Inspect spark plugs/cable, or replace as required
Engine hesitates/poor acceleration	Ignition wiring	Repair wiring, or replace as required
Poor mileage	Spark plugs and spark plug cables	Inspect spark plugs/cable, or replace as required

IGNITION SYSTEM TROUBLESHOOTING

Symptom	Suspect area	Remedy
Charging warning indicator does not light with ignition switch "ON" and engine off.	Fuse blown	Check fuses
	Light burned out	Replace light
	Wiring connection loose	Tighten loose connection
	Electronic voltage regulator	Disconnect the voltage regulator to see if light turns off. If light turns off, replace voltage regulator.
Charging warning indicator does not go out with engine running. (Battery requires frequent recharging)	Drive belt loose or worn	Adjust belt tension or replace belt
	Battery cable loose, corroded or worn	Inspect cable connection, repair or replace cable
	Electronic voltage regulator or alternator	Disconnect the voltage regulator or alternator to see if light turns off. If light turns off, replace voltage regulator
	Wiring	Repair or replace wiring
Overcharge	Electronic voltage regulator	Disconnect the voltage regulator to see if light turns off. If light turns off, replace voltage regulator.
Overcharge	Voltage sensing wire	Repair or replace wiring
Discharge	Drive belt loose or worn	Adjust belt tension or replace belt
	Wiring connection loose or short circuit	Inspect wiring connection, repair or replace wiring
	Electronic voltage regulator or alternator	Disconnect the voltage regulator or alternator to see if light turns off. If light turns off, replace voltage regulator
	Poor grounding	Inspect ground or repair
	Worn battery	Replace battery

CHARGING SYSTEM TROUBLESHOOTING

Symptom	Suspect area	Remedy
Engine will not crank	Battery charge low	Charge or replace battery
	Battery cables loose, corroded or worn out	Repair or replace cables
	Transaxle range switch (Vehicle with automatic transaxle only)	Refer to AUTOMATIC TRANSAXLE SYSTEM - (A6MF2) - 2.4L
	Fuse blown	Replace fuse
	Starter faulty	Replace
	Ignition switch faulty	Replace
Engine cranks slowly	Battery charge low	Charge or replace battery
	Battery cables loose, corroded or worn out	Repair or replace cables
	Starter faulty	Replace
Starter keeps running	Starter	Replace
Starter keeps running	Ignition switch	Replace
Starter spins but engine will not crank	Short in wiring	Repair wiring
	Pinion gear teeth broken or Starter	Replace
	Ring gear teeth broken	Replace fly wheel or torque converter

STARTING SYSTEM TROUBLESHOOTING

Special Service Tools

SPECIAL SERVICE TOOLS Tool (Number and name) Illustration Use Alternator pulley remover wrench (09373-27000) Removal and installation of alternator pulley Micro 570 Battery checker Using with Thermal Printer_182-003A

Scheme 3

Scheme 3: Special Service Tools

Scheme 4

The Micro 570 Analyzer

The Micro 570 Analyzer provides the ability to test the charging and starting systems, including the battery, starter and alternator.

CAUTION

Because of the possibility of personal injury, always use extreme caution and appropriate eye protection when working with batteries.

Scheme 5

Keypad

The Micro 570 button on the key pad provide the following functions

Scheme 6

Scheme 6: Keypad

Scheme 7

Scheme 7: Battery Test Procedure

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Connect the tester to the battery. Red clamp to battery positive (+) terminal. Black clamp to battery negative (-) terminal. CAUTION: Connect clamps securely. If "CHECK CONNECTION" message is displayed on the screen, reconnect clamps securely.
The tester will ask if the battery is connected "IN-VEHICLE" or "OUT-OF-VEHICLE". Make your selection by pressing the arrow buttons; then press ENTER.
Select CCA and press the ENTER button. NOTE: CCA : Cold cranking amps, is an SAE specification for cranking battery at -0.4°F (-18°C).
Set the CCA value displayed on the screen to the CCA value marked on the battery label by pressing up and down buttons and press ENTER. NOTE: The battery ratings (CCA) displayed on the tester must be identical to the ratings marked on battery label.
The tester will conduct battery test.
The tester displays battery test results including voltage and battery ratings. Refer to the following table and take the appropriate action as recommended by the Micro 570.

Battery Test Results

Result On Printer	Remedy
GOOD BATTERY	No action is required.
GOOD RECHARGE	Battery is in a good state. Recharge the battery and use. (Battery may be charged by running the engine at idle for 20 minutes.)
CHARGE & RETEST	Battery is not charged properly. Charge and test the battery again. (Failure to charge the battery fully may read incorrect measurement value.)
REPLACE BATTERY	Replace battery and recheck the charging system. Improper connection between battery and vehicle cables may cause "REPLACE BATTERY", retest the battery after removing cables and connecting the tester to the battery terminal directly prior to replacing the battery.
BAD CELL-REPLACE	Charge and retest the battery. If the Micro 570 recommends "REPLACE BATTERY", replace the battery and recheck the charging system.

BATTERY TEST RESULTS

[Charge and Retest method after battery charge]

Battery charge

Set battery charger to 'Auto Mode' (The Mode that charging current drops as the battery charges.) and charge battery until charging current down close to zero or the charger alerts you with an alarm when charge is complete.

(Minimum charging time recommended: More than 3 hours with Auto Mode that explained above)

If battery is not fully charged, battery surface voltage will be high while the amount of current charged (CCA) in battery is low. If you measure the battery under this condition, tester may misjudge that battery sulfation occurred because the amount of current in battery is too low in comparison with battery voltage. * Surface voltage: When battery is charged electrolyte temperature increases and chemical reaction become active resulting in an excessive increase of battery voltage. It is known that it takes approximate one day to subside this increased surface voltage completely. Battery Test after charge Do not test battery right after the charge. Test battery after battery surface voltage has subsided as instructed in the following procedure. When battery charge is complete, install the battery in the vehicle. Put IG key to ON position and turn on head lamp with low beam, and wait 5 minutes. (Discharge for 5 minutes) Turn off the head lamp and IG key, and wait 5 minutes. (Waiting for 5 minutes) Remove +, - cable from the battery and test battery.

WARNING

Whenever filing a claim for battery, the print out of the battery test results must be attached.

Scheme 13

Scheme 13: Starter Test Procedure

Scheme 14

Scheme 15

7. After the battery test, press ENTER immediately for the starter test.
8. Start the engine.
9. Cranking voltage and starter test results will be displayed on the screen. Refer to the following table and take the appropriate action as recommended by the Micro 570.

Starter Test Results

Result On Printer	Remedy
CRANKING VOLTAGE NORMAL	System shows a normal starter draw.
CRANKING VOLTAGE LOW	Cranking voltage is lower than normal level. Check starter.
CHARGE BATTERY	The state of battery charge is too low to test. Charge the battery and retest.
REPLACE BATTERY	Replace battery. If the vehicle is not started though the battery condition of "GOOD BATTERY" is displayed, check wiring for open circuit, battery cable connection, starter and repair or replace as necessary. If the engine does crank, check fuel system.

STARTER TEST RESULTS

Note. When testing the vehicle with old diesel engines, the test result will not be favorable if the glow plug is not heated. Conduct the test after warming up the engine for 5 minutes.

Scheme 16

Scheme 16: Charging System Test Procedure

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

10. Press ENTER to begin charging system test.
11. The tester displays the actual voltage of alternator. Press ENTER to continue.
12. Turn off all electrical load and rev engine for 5 seconds with pressing the accelerator pedal. (Follow the instructions on the screen)
13. The message that engine RPM is detected will be displayed on the screen. Press ENTER to continue.
14. If the engine RPM is not detected, press ENTER after revving engine.
15. The tester will conduct charging system test during loads off.
16. Turn on electrical loads (air conditioner, lamps, audio and etc). Press ENTER to continue.
17. The tester will conduct charging system test during loads on.
18. Rev engine for 5 seconds with pressing the accelerator pedal. (Follow the instructions on the screen)
19. The message that engine RPM is detected will be displayed on the screen. Press ENTER to continue.
20. If the engine RPM is not detected, press ENTER after revving engine.
21. Turn off electrical loads (air conditioner, lamps, audio and etc). Turn the engine off.
22. Charging voltage and charging system test results will be displayed on the screen. Shut off engine end disconnect the tester clamps from the battery. Refer to the following table and take the appropriate action as recommended by the Micro 570.

Charging System Test Results

Result On Printer	Remedy
CHARGING SYSTEM NORMAL/DIODE RIPPLE NORMAL	Charging system is normal.
NO CHARGING VOLTAGE	Alternator does not supply charging current to battery. Check belts, connection between alternator and battery and replace belts or cable or alternator as necessary.
LOW CHARGING VOLTAGE	Alternator does not supply charging current to battery and electrical load to system fully. Check belts and alternator and replace as necessary.
HIGH CHARGING VOLTAGE	The voltage from alternator to battery is higher than normal limit during voltage regulating. Check connection and ground and replace regulator as necessary. Check electrolyte level in the battery.
EXCESS RIPPLE DETECTED	One or more diodes in the alternator is not functioning properly. Check alternator mounting and belts and replace as necessary.

CHARGING SYSTEM TEST RESULTS
