Description
The ECM (Electro Chromic inside rear view Mirror) is for dimming the reflecting light from a vehicle behind at night, in order the user not to be dazzled by the light. The front looking sensor detects brightness of the surroundings, while the rearward looking sensor the strength of the reflecting light so that adjusts the reflexibility of the mirror in the range of 10~70%. But, when the reverse gear is engaged, it stops functioning.
Scheme 99
- 2. OEC (+)
- 6. Battery (+)
- 7. OEC (-)
- 8. GND
- 9. Reverse inhibit
- 10. IGN (12V)
Scheme 100
Scheme 101
- The front looking sensor sees if the brightness of the surroundings is low enough for the mirror to operate its function.
- The rearward looking sensor detects glaring of the reflecting light from a vehicle behind.
- The ECM is darkened to the level as determined by the rearward looking sensor. When the glaring is no longer detected, the mirror stops functioning.
The compass feature is designed to be integrated into an electro chromic interior rearview mirror.
The mirror assembly shall display a compass heading.
The compass mirror then take the sensor information to determine static field strengths and rotating field information to determine an accurate compass heading.
| Item | Standard value |
|---|---|
| Rate voltage | DC 12V |
| Operating voltage range | DC9 ~ 16V |
| Operating temperature range | 30 ~ +65°C (-22 ~ 149°F) |
| Direction display | 8 |
| Renewal time | 2 sec. |
COMPASS MIRROR SPECIFICATION
The HomeLink Wireless control system provides a convenient way to replace up to three hand-held radio-frequency (RF) transmitters with a single built-in device. This innovative feature will learn the radio frequency codes of most current transmitters to operate devices such as gate operators, garage door openers, entry door locks, security systems, even home lighting.
| ITEM | DESCRIPTION | REMARK |
|---|---|---|
| Rated Voltage | DC 12V | Testing Voltage: 12.8V |
| Operating Voltage | 9 ~ 18V | Should be operation at limit rage |
| Operating Temperature | 30 ~ 85°C (-22 ~ 185°F) | |
| Storage Temperature | 40 ~ 105°C (-40 ~ 221°F) | |
| Operating Humidity | 95% | |
| Operating Current | 23 ~ 100mA | |
| Low power Mode | 4 ~ 16mA | |
| Reduce power Mode | 10 ~ 25mA | |
| Insulation Resistant | 100Mohms (500VM) | The case is exclude in EARTH |
| Dark current | 0.3mA MAX |
HOMELINK WIRELESS CONTROL SYSTEM SPECIFICATION
| Signal | Specification | Remark | |
|---|---|---|---|
| Learn RF Signal | Learning Frequency | 288-390 MHz | |
| Learning Range | 0-1m | Between H/L & Drive seat | |
| Transmit RF Signal | Transmission Frequency | 288-390 MHz | |
| Transmission Range | 13m MIN | ||
| Output Power | 75.6dBμV/m MAX | Do as the FCC | |
LEARN & TRANSMIT SPECIFICATION
* In case of OT (Original Transmitter) range < 80% of Transmission SPEC. It should be apply to transmission range for 80% of OT.
- Follow the OT or OR (Original Receiver) about reception & transmission frequency.
- Transmission Range means the distance from which the receiving device RF signal from HomeLink)
- Reception Range means the distance within which the HomeLink can be trained with RF signal from OT.
