Back View Camera System: Overview Hyundai Genesis I рестайлинг

Navigation System 6 illustrations ~141 words

Scheme 58

Scheme 58: Component Location
Scheme 58: Component Location

Scheme 59

Scheme 59: Circuit Diagram
Scheme 59: Circuit Diagram

Description

Back view camera will activate when the backup light is ON with the ignition switch ON and the shift lever in the R position. This system is a supplemental system that shows behind the vehicle through the AV monitor while backing-up.

WARNINGThis system is a supplementary function only. It is the responsibility of the driver or always check the inside/outside rearview mirror and the area behind the vehicle before and while backing up because there is a dead zone that can't see through the camera.

Scheme 60

Scheme 60: Back View Camera
Scheme 60: Back View Camera

Scheme 61

Scheme 61
Scheme 61
  1. Remove the screws, clip and trunk lid trim in the trunk. (Refer to the «TRUNK LID»(ref-590394-S26993807522013121700000) )
  2. Remove the trunk lid panel (B).
  3. Remove the back view camera (A) after removing the connector and screws (2EA).

Scheme 62

Scheme 62: Back View Camera Unit
Scheme 62: Back View Camera Unit

Scheme 63

Scheme 63
Scheme 63
  1. Disconnect the negative (-) battery terminal.
  2. Remove the trunk left trim in the trunk. (Refer to the «TRUNK LID»(ref-590394-S26993807522013121700000) )
  3. Remove the back view camera unit (A) after removing the nuts (2EA) and connector.
  1. Install the back view camera.
  2. Install the trunk lid panel and trim.
