Audio/video/navigation: Removal & Installation Hyundai Genesis I рестайлинг

Installation

1. Install the AVN head unit after connecting the connectors.
2. Install the crash pad lower pannel.
3. Connect the negative (-) battery terminal.

Scheme 7

Scheme 8

Scheme 9

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad lower panel. (Refer to the " «CRASH PAD»(ref-590392-S04150349602013121700000) ")
3. Remove the cluster fascia panel.
4. Remove the crash pad side garnish (A) after removing the screws.
5. Remove the center fascia panel (A) after removing the screws.
6. Remove the LCD monitor unit after removing the screws.

1. Install the LCD monitor unit after connecting the connectors.
2. Install the center fascia panel.
3. Install the crash pad side garnish, cluster fascia pannel and crash pad lower panel.

Scheme 10

1. Install the Multi media Jack.
2. Connect the Multi Media Jack connectors.
3. Install the under cover to the floor console.

Scheme 11

Scheme 12

1. Remove the rear roof trim. (Refer to the " «ROOF TRIM»(ref-590392-S04478021052013121700000) ")
2. Disconnect the GPS cable (A) and XM radio cable (B) after removing a nut (C).
3. Remove the roof antenna (A).

Scheme 13
