Adjust Hood

1. After loosening the hinge (A) mounting bolt, adjust the hood (B) by moving it up or down, or right or left.
2. Adjust the hood height by turning the hood overslam bumpers (C).
3. After loosening the hood latch (D) mounting bolts, adjust the latch by moving it up or down, or right or left.

Scheme 1

Scheme 2

Scheme 3

1. Detach the clips, then remove the trunk trim (A). NOTE: When removing and installing the trunk lid, an assistant is necessary. Wear gloves to protect hands from injury.
2. Disconnect the connectors.
3. After loosening the mounting bolts, remove the trunk lid (B).
4. Installation is the reverse of removal. NOTE: Replace any damaged clips.

Scheme 4

1. Remove the trunk lid weatherstrip (A).
2. Installation is the reverse of removal.

Scheme 5

1. Remove the trunk lid trim.
2. Disconnect the inside handle cable (A), then loosen the key holder (B) mounting bolts and remove.
3. Installation is the reverse of removal.

Scheme 6

1. Remove the trunk lid trim.
2. Disconnect the cable (A).
3. After loosening the mounting bolt, then remove the latch assembly (B).
4. Installation is the reverse of removal.

Scheme 7

Scheme 8

1. Remove the trunk lid trim.
2. Remove the rear combination lamp (A).
3. Remove the trunk lid panel (A).
4. Installation is the reverse of removal.

Scheme 9

1. After loosening the trunk lid hinge (A) mounting bolt, adjust the trunk lid (B) by moving it up or down, or right or left.
2. Adjust the trunk lid height by turning the trunk lid overslam bumpers (D).
3. After loosening the trunk lid striker (C) mounting bolts, adjust the trunk lid strike by moving it up or down, or right or left.

Scheme 10

Scheme 11

1. Loosen the checker mounting bolts.
2. Detach the clips, then remove the weatherstrip (A).
3. Installation is the reverse of removal.

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. After loosening the mounting bolt, then remove the lock cylinder (A).
2. Remove the lock cylinder (A).
3. Remove the outside handle (A) by sliding it rearward.
4. Disconnect the connector (A).
5. Installation is the reverse of removal. NOTE: Make sure door lock operates and door open/closes properly.

Glass Adjustment

Note. Check the glass run channel for damage or deterioration, and replace them as needed.

Scheme 16

Scheme 17

1. Remove the following parts: Quadrant inner cover. Door trim.
2. Carefully move the glass (A) until the glass mounting bolts are visible, then loosen them.
3. Check that the glass moves smoothly.
4. Raise the glass fully, and check for gaps. Check that the glass contacts the glass run channel evenly.
5. Check for water leaks. Run water over the roof and on the sealing area as shown in illustration, and note these items: Use a 12mm (1/2in.) diameter hose (A). Adjust the rate of water flow as shown (B). Do not use a nozzle. Hold the hose about 300mm(12in.) away from the door.

Door Position Adjustment

Note. After installing the door, check for a flush fit with the body, then check for equal gaps between the front, rear, and bottom, door edges and the body. Check that the door and body edges are parallel. Before adjusting, replace the mounting bolts.

Scheme 18

1. Place the vehicle on a firm, level surface when adjusting the doors.
2. Adjust at the hinges (A): Loosen the door mounting bolts (B) slightly, and move the door IN or OUT until it aligns flush with the body. Loosen the hinge mounting bolts slightly, and move the door BACKWARD or FORWARD, UP or DOWN as necessary to equalize the gaps. Place a shop towel on the jack to prevent damage to the door when adjusting the door.
3. Check that the door and body edges are parallel.
4. Grease the pivot portions of the hinges indicated by the arrows.
5. Check for water leaks.

Door Striker Adjustment

Make sure the door latches securely without slamming it. If necessary adjust the striker (A): The striker nuts are fixed. The striker can be fine adjusted up or down, and in or out.

Scheme 19

1. Loosen the screws (B), then insert a shop towel between the body and striker.
2. Lightly tighten the screws.
3. Wrap the striker with a shop towel, then adjust the striker by tapping it with a plastic hammer. Do not tap the striker too hard.
4. Loosen the screws and remove the shop towel.
5. Lightly tighten the screws.
6. Hold the outer handle out, and push the door against the body to be sure the striker allows a flush fit. If the door latches properly, tighten the screws and recheck.

Scheme 20

Note. Check the glass run channel for damage or deterioration, and replace them necessary.

Scheme 21

Scheme 22

1. Remove the following parts. Door trim.
2. Carefully move the glass (A) until the glass mounting bolts are visible, then loosen them.
3. Check that the glass moves smoothly.
4. Raise the glass fully, and check for gaps. Check that the glass contacts the glass run channel evenly.
5. Check for water leaks. Run water over the roof and on the sealing area as shown in illustration, and note these items: Use a 12mm (1/2Iin.) diameter hose (A). Adjust the rate of water flow as shown (B) in illustration. Do not use a nozzle. Hold the hose about 300mm (12in.) away from the door.

Note. After installing the door, check for a flush fit with the adjacent body panels, then check for equal gaps between the front, rear, and bottom, door edges and the body. Check that the door and body edges are parallel. Before adjusting, replace the mounting bolts.

Scheme 23

1. Place the vehicle on a firm, level surface when adjusting the doors.
2. Adjust at the hinges (A): Loosen the door mounting bolts (B) slightly, and move the door IN or OUT until it aligns flush with the body. Loosen the hinge mounting bolts slightly, and move the door BACKWARD or FORWARD, UP or DOWN as necessary to equalize the gaps. Place a shop towel on the jack to prevent damage to the door when adjusting the door.
3. Check that the door and body edges are parallel.
4. Grease the pivot portions of the hinges indicated by the arrows.
5. Check for water leaks.

Make sure the door latches securely without slamming it. If necessary adjust the striker (A): The striker nuts are fixed. The striker can be fine adjusted up or down, and in or out.

Scheme 24

1. Loosen the screws (B), then insert a shop towel between the body and striker.
2. Lightly tighten the screws.
3. Wrap the striker with a shop towel, then adjust the striker by tapping it with a plastic hammer. Do not tap the striker too hard.
4. Loosen the screws and remove the shop towel.
5. Lightly tighten the screws.
6. Hold the outer handle out, and push the door against the body to be sure the striker allows a flush fit. If the door latches properly, tighten the screws and recheck.
