Timing System - 3.8L: Removal & Installation Hyundai Genesis I рестайлинг

Removal

Note. Mark all wiring and hoses to avoid misconnection. Turn the crankshaft pulley so that the No. 1 piston is at top dead center.

Scheme 437

Scheme 438

Scheme 439

Scheme 440

Scheme 441

Scheme 442

Scheme 443

Scheme 444

Scheme 445

Scheme 446

Scheme 447

Scheme 448

Scheme 449

Scheme 450

Scheme 451

Scheme 452

Scheme 453

Scheme 454

Scheme 455

Scheme 456

Scheme 457

Scheme 458

Scheme 459

Scheme 460

Scheme 461

Scheme 462

Scheme 463

Scheme 464

Scheme 465

Scheme 466

Scheme 467

Scheme 468

Scheme 469

Scheme 470

Scheme 471

Scheme 472

Scheme 473

Scheme 474

Scheme 475

Scheme 476

Scheme 477

Scheme 478

Scheme 479

Scheme 480

Scheme 481

Scheme 482

Scheme 483

Scheme 484

Scheme 485

Scheme 486

Scheme 487

Scheme 488

Scheme 489

Scheme 490

Scheme 491

Scheme 492

1. Disconnect the battery negative cable.
2. Remove the engine cover (A), engine side covers (B) and the radiator grill upper cover (C).
3. Loosen the drain plug and drain the engine coolant.
4. Remove the intake air hose and air cleaner assembly. Remove the air duct (A). Disconnect the MAFS connector (B). Disconnect the breather hose (C). Disconnect the vacuum hose (D). Remove the intake air hose (E) and air cleaner assembly (F).
5. Remove the radiator upper hose (A) and lower hose (B).
6. Disconnect the fuel hose (A), PCSV hose (B) and the intensifier hose (C).
7. Disconnect the engine wiring harness connectors and hoses. RH ignition coil connector (A) RH knock sensor connector (B) RH exhaust oil control valve (OCV) connector (A) RH injector connector (B) VIS solenoid valve connector (C) LH exhaust oil control valve (OCV) connector (A) LH/RH intake oil control valve (OCV) connector (B) Oil pressure switch connector (C) LH Injector connector (D) Ignition coil condenser connector (E) LH knock sensor connector (F) ETC connector (A), PCV hose (B) RH exhaust camshaft position sensor (CMPS) connector (C) Water temperature sensor (D) Ignition coil condenser connector (E) RH front oxygen sensor connector (F) Fuel pump connector (A) LH ignition coil connector (B) LH exhaust camshaft position sensor (CMPS) connector (C) LH front oxygen sensor connector (D) PCSV connector (A) LH intake camshaft position sensor (CMPS) connector (B) MAP sensor connector (C) Oil temperature sensor connector (D) RH intake camshaft position sensor (CMPS) connector (E)
8. Remove the surge tank assembly (A).
9. Remove the breather pipe & hose (A).
10. Remove the high pressure fuel tube bracket bolt (A).
11. Disconnect the water hose (C) & pipe (A) and then remove the intake manifold (B). CAUTION: Be sure to drain the engine coolant before removing the intake manifold. If any coolant drained from the cylinder head vent hole has entered the intake port. This can potentially lead to engine trouble.
12. Remove the high pressure fuel pipe (A).
13. Remove the RH ignition coils (A) and the wiring.
14. Remove the LH ignition coils (A) and the wiring.
15. Remove the fuel pump (B) and the roller tappet (C).
16. Remove the LH/RH cylinder head cover (B) after remove the OCV cap (A).
17. Drain the engine oil. (Refer to «ENGINE OIL»(ref-590356-S30392821762013121700000) )
18. Remove the lower oil pan (A). Insert the blade of SST (09215-3C000) between the upper oil pan and lower oil pan. Cut off applied sealer and remove the lower oil pan. NOTE: Insert the SST between the oil pan and the ladder frame by tapping it with a plastic hammer in the direction of arrow. After tapping the SST with a plastic hammer along the direction of arrow around more than 2/3 edge of the oil pan, remove it from the ladder frame. Do not turn over the SST abruptly without tapping. It be result in damage of the SST. Be careful not to damage the contact surfaces of Upper oil pan and lower oil pan.
19. Turn the tensioner counterclockwise and loosen then, remove the drive belt (A).
20. Remove the air conditioner compressor (A). (Refer to «COMPRESSOR»(ref-590438-S13212645472013121700000) )
21. Remove the alternator (A). (Refer to «ALTERNATOR»(ref-590360-S38651890382013121700000) )
22. Remove the oil filter body (A).
23. Remove the water pump pulley (A).
24. Remove the drive belt idler (A).
25. Remove the drive belt auto tensioner (A).
26. Set No. 1 cylinder to TDC/compression. Turn the crankshaft pulley clockwise and align its groove with the timing mark "T" of the lower timing chain cover. Check that the mark of the camshaft timing sprockets are in straight line on the cylinder head surface as shown in the illustration. If not, turn the crankshaft clockwise one revolution (360°). NOTE: Do not rotate engine counterclockwise.
27. Remove the crankshaft pulley (A). NOTE: Use the SST (09231-3M100) to remove the crankshaft pulley bolt.
28. Remove the water pump (A) and the gaskets (B).
29. Remove the timing chain cover (A). CAUTION: Be careful not to damage the contact surfaces of cylinder block, cylinder head and timing chain cover. NOTE: Before removing the timing chain, mark the RH/LH timing chain with an identification based on the location of the sprocket because the identification mark on the chain for TDC (Top Dead Center) can be erased.
30. Remove the oil pump chain cover (A).
31. Remove the oil pump chain tensioner assembly (A).
32. Release the ratchet using a thin rod. Compress the piston and then insert a stopper pin into the hole on the ratchet to hold the compressed piston.
33. Remove the RH timing chain cam to cam guide (A).
34. Remove the RH timing chain auto tensioner (A) and the RH timing chain tensioner arm (B).
35. Remove the RH timing chain guide (A).
36. Remove the RH timing chain (A).
37. Remove the crankshaft RH timing chain sprocket (A).
38. Remove the oil pump chain sprocket (A) and oil pump chain (B).
39. Remove the crankshaft oil pump chain sprocket (A).
40. Release the ratchet using a thin rod. Compress the piston and then insert a stopper pin into the hole on the ratchet to hold the compressed piston.
41. Remove the LH timing chain cam to cam guide (A).
42. Remove the LH timing chain auto tensioner (A) and LH timing chain tensioner arm (B).
43. Remove the LH timing chain guide (A).
44. Remove the timing chain (A).
45. Remove the crankshaft LH timing chain sprocket (A).
46. Remove the tensioner adapter assembly (A).
