Timing System - 3.8L: Other Hyundai Genesis I рестайлинг

Sprockets, Chain Tensioner, Chain Guide, Chain Tensioner Arm

1. Check the camshaft sprocket and crankshaft sprocket for abnormal wear, cracks, or damage. Replace as necessary.
2. Inspect the tensioner arm and chain guide for abnormal wear, cracks, or damage. Replace as necessary.
3. Check that the tensioner piston moves smoothly when the ratchet pawl is released with thin rod.

Scheme 493

Scheme 494

Scheme 495

Scheme 496

Scheme 497

Scheme 498

Scheme 499

Scheme 500

Scheme 501

Scheme 502

Scheme 503

Scheme 504

Scheme 505

Scheme 506

Scheme 507

Scheme 508

Scheme 509

Scheme 510

Scheme 511

Scheme 512

Scheme 513

Scheme 514

Scheme 515

Scheme 516

Scheme 517

Scheme 518

Scheme 519

Scheme 520

Scheme 521

Scheme 522

Scheme 523

Scheme 524

Scheme 525

Scheme 526

Scheme 527

Scheme 528

Scheme 529

Scheme 530

Scheme 531

Scheme 532

Scheme 533

Scheme 534

Scheme 535

Scheme 536

Scheme 537

Scheme 538

Scheme 539

Scheme 540

Scheme 541

Scheme 542

Scheme 543

Scheme 544

Scheme 545

Scheme 546

Scheme 547

Scheme 548

Scheme 549

Scheme 550

Scheme 551

1. The key (A) of crankshaft should be aligned with the timing mark (B) of cylinder block. As a result of this, the piston of No. 1 cylinder is placed at the top dead center on compression stroke.
2. Install the tensioner adapter assembly (A).
3. Install the crankshaft LH timing chain sprocket (A).
4. Install the LH timing chain (A). NOTE: To install the timing chain with no slack between each shaft (cam, crank), follow the below procedure. Crankshaft sprocket --> Timing chain guide --> Exhaust camshaft sprocket --> Intake camshaft sprocket. The timing mark of each sprockets should be matched with timing mark (color link) of timing chain at installing timing chain.
5. Install the LH timing chain guide (A). Tightening torque: 19.6 ~ 24.5N.m (2.0 ~ 2.5kgf.m, 14.5 ~ 18.1lb-ft)
6. Install the LH timing chain tensioner arm (B) and LH timing chain auto tensioner (A). Tightening torque 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft) 18.6 ~ 21.6N.m (1.9 ~ 2.2kgf.m, 13.7 ~ 15.9lb-ft)
7. Install the LH timing chain cam to cam guide (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
8. Remove the tensioner stopper pin (A).
9. Install the crankshaft oil pumpchain sprocket (A).
10. Install the oil pump chain sprocket (A) with oil pump chain (B). Tightening torque: 18.6 ~ 21.6N.m (1.9 ~ 2.2kgf.m, 13.7 ~ 15.9lb-ft)
11. Install the RH timing chain (A). NOTE: To install the timing chain with no slack between each shaft (cam, crank), follow the below procedure. Crankshaft sprocket -->Timing chain guide --> Intake camshaft sprocket --> Exhaust camshaft sprocket. The timing mark of each sprockets should be matched with timing mark (color link) of timing chain at installing timing chain.
12. Install the RH timing chain guide (A). Tightening torque: 19.6 ~ 24.5N.m (2.0 ~ 2.5kgf.m, 14.5 ~ 18.1lb-ft)
13. Install the RH timing chain tensioner arm (B) and RH timing chain auto tensioner (A). Tightening torque 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft) 18.6 ~ 21.6N.m (1.9 ~ 2.2kgf.m, 13.7 ~ 15.9lb-ft)
14. Install the RH timing cam to cam guide (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
15. Remove the tensioner stopper pin (A).
16. Install the oil pump chain tensioner assembly (A). Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft) NOTE: The hook of tensioner must be around the guide.
17. Install the oil pump chain cover (A). Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft)
18. After rotating the crankshaft 2 revolutions in regular direction (clockwise viewed from front), confirm the timing mark. NOTE: Always turn the crankshaft clockwise. Turning the crankshaft counter clockwise before building up oil pressure in the hydraulic timing chain tensioner may result in the chain disengaging from the sprocket teeth.
19. Install the timing chain cover. The sealant locations on chain cover and on counter parts (cylinder head, cylinder block, and lower oil pan) must be free of engine oil and etc. Before assembling the timing chain cover, the liquid sealant TB 1217H should be applied on the gap between cylinder head and cylinder block. The part must be assembled within 5 minutes after sealant was applied. Bead width: 2.5mm (0.1in.) After applying liquid sealant TB1217H on timing chain cover. The part must be assembled within 5 minutes after sealant was applied. Sealant should be applied without discontinuity. NOTE: Fill the T-joint area (6EA*) with sealant. Apply sealant all around the dowel pin hole (2EA). Install the new gasket (A) to the timing chain cover. NOTE: During timing cover installation, care not to take off applied sealant on the timing cover by contact with other parts. The dowel pins on the cylinder block and holes on the timing chain cover should be used as a reference in order to assemble the timing chain cover to be in exact position. Tightening torque (16EA): 18.6 ~ 21.6N.m (1.9 ~ 2.2kgf.m, 13.7 ~ 15.9lb-ft) (2EA): 24.5 ~ 26.5N.m (2.5 ~ 2.7kgf.m, 18.1 ~ 19.5lb-ft) (2EA): 58.8 ~ 68.6N.m (6.0 ~ 7.0kgf.m, 43.4 ~ 50.6lb-ft) (3EA): 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft) The firing and/or blow out test should not be performed within 30 minutes after the timing chain cover was assembled.
20. Install the water pump. Install the new gaskets (B) and then install the water pump (A). NOTE: Clean the contact face before assemble. Always use a new seal bolt (Bolt C) and the gaskets. Tightening torque (3EA): 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) (1EA): 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) (1EA): 19.6 ~ 26.5N.m (2.0 ~ 2.7kgf.m, 14.5 ~ 19.5lb-ft) (1EA): 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) (1EA): 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) (1EA): 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) (4EA): 19.6 ~ 23.5N.m (2.0 ~ 2.4kgf.m, 14.5 ~ 17.4lb-ft)
21. Using SST (09231-3C100), install timing chain cover oil seal.
22. Install the crankshaft pulley (A). Tightening torque: 284.4 ~304.0N.m (29.0~31.0kgf.m, 209.8~224.2lb-ft) NOTE: Use the SST (09231-3M100) to install the crankshaft pulley bolt.
23. Install the drive belt auto tensioner (A). Tightening torque Bolt (B): 81.4 ~ 85.3N.m (8.3 ~ 8.7kgf.m, 60.0 ~ 62.9lb-ft) Bolt (C): 17.7 ~ 21.6N.m (1.8 ~ 2.2kgf.m, 13.0 ~ 15.9lb-ft)
24. Install the drive belt idler (A). Tightening torque: 53.9 ~ 57.9N.m (5.5 ~ 5.9kgf.m, 39.8 ~ 42.7lb-ft)
25. Install the water pump pulley (A). Tightening torque: 7.8 ~ 9.8N.m (0.8 ~ 1.0kgf.m, 5.8 ~ 7.2lb-ft)
26. Install the oil filter body (A). Tightening torque: 19.6 ~ 21.6N.m (2.0 ~ 2.2kgf.m, 14.5 ~ 15.9lb-ft)
27. Install the air conditioner compressor (A). (Refer to «COMPRESSOR»(ref-590438-S13212645472013121700000) )
28. Install the alternator (A). (Refer to «ALTERNATOR»(ref-590360-S38651890382013121700000) ) Tightening torque: 26.5 ~ 33.3N.m (2.7 ~ 3.4kgf.m, 19.5 ~ 24.6lb-ft)
29. Rotate the auto tensioner counterclockwise. With the tensioner turned, install the drive belt (A).
30. Install the lower oil pan (A). Using a gasket scraper, remove all the old packing material from the gasket surfaces. Before assembling the oil pan, the liquid sealant TB 1217H should be applied on oil pan. The part must be assembled within 5 minutes after the sealant was applied. Bead width: 2.5mm (0.1in.) CAUTION: Clean the sealing face before assembling two parts. Remove harmful foreign matters on the sealing face before applying sealant. When applying sealant gasket, sealant must not be protruded into the inside of oil pan. To prevent leakage of oil, apply sealant gasket to the inner threads of the bolt holes. Install the oil pan (A). Uniformly tighten the bolts in several passes. Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft)
31. Install the LH/RH cylinder head cover (A). CAUTION: Install the cylinder head cover under the exhaust OCV cup is removed. To prevent engine oil leakage, surely install the exhaust OCV cap after installing the cylinder head cover. The hardening sealant located on the upper area between timing chain cover and cylinder head should be removed before assembling cylinder head cover. After applying sealant (TB1217H), it should be assembled within 5 minutes. Bead width: 2.5mm (0.1in.) The firing and/or blow out test should not be performed within 30 minutes after the cylinder head cover was assembled. Install the cylinder head cover bolts as following method. Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft) CAUTION: Do not reuse cylinder head cover gasket. Install the exhaust OCV cap. Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft)
32. Install the RH ignition coils (A) and then connect the connectors. Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
33. Install the LH ignition coils (A) and then connect the connectors. Install the roller tappet (C) and the fuel pump (B). Tightening torque Ignition coil bolts: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) Fuel pump bolts: 12.7 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft)
34. Install high pressure fuel pipe (A). Tightening torque: 26.5 ~ 32.4N.m (2.7 ~ 3.3kgf.m, 19.5 ~ 23.9lb-ft)
35. Install the intake manifold (B) and then connect the water hose (C) and the pipe (A). NOTE: Tighten the intake manifold bolts, in several passes as below. a~h: 1st step order 1~8: 2nd step order Tightening torque Step 1: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft) Step 2: 26.5 ~ 31.4N.m (2.7 ~ 3.2kgf.m, 19.5 ~ 23.1 lb-ft) Step 3: Repeat 2nd step twice or more
36. Install the fuel tube bracket bolt (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
37. Install the breather pipe & hose (A). Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft)
38. Install the surge tank assembly (A). Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft)
39. Connect the engine wiring harness connectors and hoses. RH ignition coil connector (A) RH knock sensor connector (B) RH exhaust oil control valve (OCV) connector (A) RH injector connector (B) VIS solenoid valve connector (C) LH exhaust oil control valve (OCV) connector (A) LH/RH intake oil control valve (OCV) connector (B) Oil pressure switch connector (C) LH Injector connector (D) Ignition coil condenser connector (E) LH knock sensor connector (F) ETC connector (A), PCV hose (B) RH exhaust camshaft position sensor (CMPS) connector (C) Water temperature sensor (D) Ignition coil condenser connector (E) RH front oxygen sensor connector (F) Fuel pump connector (A) LH ignition coil connector (B) LH exhaust camshaft position sensor (CMPS) connector (C) LH front oxygen sensor connector (D) PCSV connector (A) LH intake camshaft position sensor (CMPS) connector (B) MAP sensor connector (C) Oil temperature sensor connector (D) RH intake camshaft position sensor (CMPS) connector (E)
40. Install the fuel hose (A), PCSV hose (B) and the intensifier hose (C).
41. Install the radiator upper hose (A) and lower hose (B).
42. Install the intake air hose and air cleaner assembly. Install the intake air hose (E) and air cleaner assembly (F). Tightening torque Hose clamp: 2.9 ~ 4.9N.m (0.3 ~ 0.5kgf.m, 2.2 ~ 3.6lb-ft) Air cleaner bolts: 7.8 ~ 9.8N.m (0.8 ~ 1.0kgf.m, 5.8 ~ 7.2lb-ft) Connect the vacuum hose (D). Connect the breather hose (C). Connect the MAFS connector (B). Install the air duct (A)
43. Install the engine cover (A), engine side covers (B) and the radiator grill upper cover (C).
44. Connect the battery negative cable. Tightening torque: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft) NOTE: Refill engine oil. Clean the battery posts and cable terminals with sandpaper. Assemble and then apply grease to prevent corrosion. Inspect for fuel leakage. After assembling the fuel line, turn on the ignition switch (do not operate the starter) so that the fuel pump runs for approximately two seconds and fuel line pressurizes. Repeat this operation two or three times, then check for fuel leakage at any point in the fuel lines. Refill radiator and reservoir tank with engine coolant. Bleed air from the cooling system. Start engine and let it run until it warms up. (Until the radiator fan operates 3 or 4 times.) Turn Off the engine. Check the level in the radiator, add coolant if needed. This will allow trapped air to be removed from the cooling system. Put radiator cap on tightly, then run the engine again and check for leaks.
