Automatic Transmission Control System - 3.8L: Specifications Hyundai Genesis I рестайлинг

Automatic Trans 18 illustrations ~199 words

Specifications

  1. Type: Negative Thermal Coefficient Type
Temp.[(°C)°F]Resistance (kohms)
(-40)-40139.5
(-20)-4.047.4
(0) 32.018.6
(20) 68.08.1
(40) 104.03.8
(60) 140.01.98
(80) 176.01.08
(100) 212.00.63
(120) 248.00.38
(140) 284.00.25
(150) 302.00.16

Scheme 530

Scheme 530: Circuit Diagram
Scheme 530: Circuit Diagram
  1. Type: Hall effect sensor
  2. Specifications
Operation condition (°C)°F((-) 40~150)) -40~302
Air gap (mm) in.1.3(0.0512)
Output voltageHigh1.4
Low0.7

Scheme 531

Scheme 531: Circuit Diagram
Scheme 531: Circuit Diagram

Scheme 532

Scheme 532: Inspection
Scheme 532: Inspection
  1. Check signal waveform of output speed sensor using the GDS. Specification: Refer to "Signal Wave Form" section.
  1. Type: Hall effect sensor
  2. Specifications
Operation condition (°C)°F((-) 40~150)) -40~302
Air gap (mm) in.1.3(0.0512)
Output voltageHigh1.4
Low0.7

Scheme 533

Scheme 533: Circuit Diagram
Scheme 533: Circuit Diagram

Scheme 534

Scheme 534: Inspection
Scheme 534: Inspection
  1. Check signal waveform of Input speed sensor using the GDS. Specification: Refer to "Signal Wave Form" section.
  1. Type: Hall effect sensor
  2. Specifications
Operation condition (°C)°F((-) 40~150)) -40~302
Air gap (mm) in.1.3(0.0512)
Output voltage (V)High1.4
Low0.7

Scheme 535

Scheme 535: Circuit Diagram
Scheme 535: Circuit Diagram

Scheme 536

Scheme 536: Inspection
Scheme 536: Inspection
  1. Check signal waveform of middle speed sensor using the GDS. Specification: Refer to "Signal Wave Form" section.
Specifications (20°C (68°F))
OFF => ON146 ± 40 kPa
ON => OFF50 kPa

Scheme 537

Scheme 537: Circuit Diagram
Scheme 537: Circuit Diagram

Direct control VFS[6/C]

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)0~1569.06 (0~16, 0~227.57)
Current value (mA)0~1100
Internal resistance(ohms)5.0~5.6

Scheme 538

Scheme 538: Circuit Diagram
Scheme 538: Circuit Diagram

Direct control VFS[4&OD/C]

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)0~1569.06 (0~16, 0~227.57)
Current value (mA)0~1100
Internal resistance(ohms)5.0~5.6

Scheme 539

Scheme 539: Circuit Diagram
Scheme 539: Circuit Diagram

Direct control VFS[35R/C]

  1. Control Type: Normal high type
Control Pressure kpa (kgf/cm 2 , psi)0~2108.42 (0~21.5~305.80)
Current value (mA)0~1100
Internal resistance(ohms)5.0~5.6

Scheme 540

Scheme 540: Circuit Diagram
Scheme 540: Circuit Diagram

Direct control VFS[27/B]

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)0~1569.06 (0~16, 0~227.57)
Current value (mA)0~1100
Internal resistance(ohms)5.0~5.6

Scheme 541

Scheme 541: Circuit Diagram
Scheme 541: Circuit Diagram

Direct control VFS[UD/C]

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)0~1569.06 (0~16, 0~227.57)
Current value (mA)0~1100
Internal resistance(ohms)5.0~5.6

Scheme 542

Scheme 542: Circuit Diagram
Scheme 542: Circuit Diagram

Direct control VFS[8LR/B]

  1. Control Type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)0~2108.42 (0~21.5~305.80)
Current value (mA)0~1100
Internal resistance(ohms)5.0~5.6

Scheme 543

Scheme 543: Circuit Diagram
Scheme 543: Circuit Diagram

Line Pressure Control VFS

  1. Control type: Normal high type
Control Pressure kpa (kgf/cm 2 , psi)0~500.14 (0~5.1, 0~72.54)
Current value (mA)0~850
Internal resistance(ohms)4.8~5.4

Scheme 544

Scheme 544: Circuit Diagram
Scheme 544: Circuit Diagram

Damper Clutch Control VFS

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)0~500.14 (0~5.1, 0~72.54)
Current value (mA)0~850
Internal resistance(ohms)4.8~5.4

Scheme 545

Scheme 545: Circuit Diagram
Scheme 545: Circuit Diagram

ON/OFF Solenoid Valve

  1. Control type: Normal low type
Control pressure kpa (kgf/cm 2 , psi)539.36 (5.5, 78.23)
Internal resistance(ohms)10~11

Scheme 546

Scheme 546: Circuit Diagram
Scheme 546: Circuit Diagram
  1. Type: Combination of output signals from 4 terminals
Power supply (V)12
Output typeCombination of output signals
PIN No.PP-RRR-NNN-DD
S112V12VOOOOO
S2O12V12V12VOOO
S3OOO12V12V12VO
S4OOOOO12V12V

SIGNAL CODE

Scheme 547

Scheme 547: Circuit Diagram
Scheme 547: Circuit Diagram
