Air conditioner
| Item | Specification | |
|---|---|---|
| Compressor | Type | VS x 18 |
| Oil type & Capacity | FD46XG (PAG) 150 ± 10cc | |
| Pulley type | 6PK-TYPE | |
| Displacement | 180cc/rev | |
| Condenser | Heat rejection | 157,000 ± 5% kcal/hr |
| APT (A/C pressure transducer) | The method to measure the pressure | Voltage = 0.00878835 *Pressure + 0.5 |
| Expansion valve | Type | Block |
| Refrigerant | Type | R-134a |
| Capacity [oz. (g)] | 22.9 ± 0.88 (650 ± 25) | |
AIR CONDITIONER SPECIFICATIONS
Blower unit
| Item | Specification | |
|---|---|---|
| Fresh and recirculation | Operating method | Actuator |
| Blower | Type | Sirocco |
| Speed step | Auto + 8 speed (Automatic) | |
| Speed control | Power mosfet | |
| Air filter | Type | Particle filter |
BLOWER UNIT SPECIFICATIONS
Heater and evaporator unit
| Item | Specification | |
|---|---|---|
| Heater | Type | Pin & Tube type |
| Heating capacity | 4,850 ± 5% kcal/hr | |
| Mode operating method | Actuator | |
| Temperature operating method | Actuator | |
| Evaporator | Temperature control type | Evaporator temperature sensor |
| A/C ON/OFF [°C (°F)] | ON : 2.1 ± 0.5 (35.7 ± 32.9), OFF: 0.6 ± 0.5 (33.0 ± 32.9) | |
HEATER AND EVAPORATOR UNIT SPECIFICATIONS
Special Service Tools
SPECIAL SERVICE TOOLS CHART Tool (Number and name) Illustration Use 09977-29000 Disc & hub assembly bolt remover Removal and installation of disc & hub assembly
