Controller (Heating, Ventilation & Air Conditioning): Specifications Hyundai Genesis I

Automatic HVAC System 24 illustrations ~1643 words

Specification

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3 ± 0.15V
Max. warm4.7 ± 0.15V

Scheme 41

Scheme 41: Diagnostic Circuit Diagram

Scheme 42

Scheme 42: Check Actuation Test
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal temperature after engine start
  3. Select "Air Mix Door Potentiometer-Passenger" parameter on the current data with scantool
  4. Perform Actuation Test for "Passenger Air Mix Door -0%/50%/100%.
  5. With performing Actuation test, check that the value of Air Mix Door Potentiometer is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test.
  6. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345976-S01806188052009102300000) " procedure. NO Go to Inspection/Repair procedure.

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3 ± 0.15V
Max. warm4.7 ± 0.15V

Voltage value of Intake potentiometer as a function of position of Intake door

Door positionVoltage
FRE0.3 ± 0.15V
REC4.7 ± 0.15V

Scheme 43

Scheme 43: Diagnostic Circuit Diagram

Scheme 44

Scheme 44: Check Actuation Test
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal temperature after engine start
  3. Select "Intake Potentiometer" parameter on the current data with scantool
  4. Perform Actuation Test for Air Inlet Mode Selection - Recirculation/Fresh in order.
  5. With performing Actuation test, check that the value of each position sensors are changing. Specification: Recirculation : About 90%, Fresh : About 10%.
  6. Are the value of each position sensors changed when performing actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345976-S11245013762009102300000) " procedure. NO Go to Inspection/Repair procedure.

Voltage value of Intake potentiometer as a function of position of Intake door

Door positionVoltage
FRE0.3 ± 0.15V
REC4.7 ± 0.15V

Resistance value of incar temp sensor as a function of temperature.

Temperature (°C/°F)Resistance (kohms)Temperature (°C/°F)Resistance (kohms)
207-4285.620/6837.4
10/1416930/8624.1
0/3297.740/10415.9
10/5059.6750/12210.8

Scheme 45

Scheme 45: Diagnostic Circuit Diagram

Scheme 46

Scheme 46: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "In-car temperature sensor" parameter.
  4. Is the Incar temperature sensor normal? YES Go to Inspection and Repair procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345976-S20472857552009102300000) " procedure.

Resistance value of incar temp sensor as a function of temperature.

Temperature (°C/°F)Resistance (kohms)Temperature (°C/°F)Resistance (kohms)
20/-4285.620/6837.4
10/1416930/8624.1
0/3297.740/10415.9
10/5059.6750/12210.8

Resistance value of ambient temp.sensor as a function of temperature.

Temperature (°C/°F)Resistance (kohms)Temperature (°C/°F)Resistance (kohms)
20/-4271.450/12211
0/3295.160/1407.58
25/7730

Scheme 47

Scheme 47: Diagnostic Circuit Diagram

Scheme 48

Scheme 48: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Ambient Air Temperature sensor" parameter.
  4. Is the ambient sensor normal? YES Go to Inspection and Repair procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345976-S25189622202009102300000) " procedure.

Resistance value of ambient temp.sensor as a function of temperature.

Temperature (°C/°F)Resistance (kohms)Temperature (°C/°F)Resistance (kohms)
20/-4271.450/12211
0/3295.160/1407.58
25/7730

Resistance value of evaporator sensor as a function of temperature.

Temperature (°C/°F)Resistance (kohms)Temperature (°C/°F)Resistance (kohms)
20/-443.320/6812.1
0/3227.630/868.3
10/501840/1045.8

Scheme 49

Scheme 49: Diagnostic Circuit Diagram

Scheme 50

Scheme 50: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Evaporator sensor" parameter on scantool.
  4. Is the Evaporator Sensor normal? YES Go to Inspection and Repair procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345976-S36629718942009102300000) " procedure.

Resistance value of evaporator sensor as a function of temperature.

Temperature (°C/°F)Resistance (kohms)Temperature (°C/°F)Resistance (kohms)
20/-443.320/6812.1
0/3227.630/868.3
10/501840/1045.8

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3 ± 0.15V
Max. warm4.7 ± 0.15V

Scheme 51

Scheme 51: Diagnostic Circuit Diagram

Scheme 52

Scheme 52: Actuation Test
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Air Mix Door Potentioner-Driver" parameter on scantool.
  4. Select and perform Actuation test Air Mix Door Potentioner-Driver - 0%/50%/100% in order.
  5. With performing Actuation test, check that the value of Air Mix Door Potentiometer follows is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test.
  6. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345976-S42867259662009102300000) " procedure. NO Go to Inspection/Repair procedure.

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3 ± 0.15V
Max. warm4.7 ± 0.15V

Voltage value of potentiometer as a function of mode door position.

Mode Door PositionVoltage
VENT0.3 ± 0.15V
BI-LEVEL1.4 ± 0.4V
FLOOR2.5 ± 0.4V
MIX3.6 ± 0.4V
DEF4.7 ± 0.15V

Scheme 53

Scheme 53: DTC Detecting Condition

Scheme 54

Scheme 54: Actuation Test
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Direction Potention" parameter on scantool.
  4. Select and perform Actuation test Driver Mode Door - Face/Foot/Defrost in order.
  5. Check that the value of all the parameters are changed when performing the actuation test. Specification: Face - About below 10%, Foot: About 50%, Defrost: About 90%.
  6. Are all the parameters changed when performing Actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345976-S21610764982009102300000) " procedure. NO Go to Inspection/Repair procedure.

Voltage value of potentiometer as a function of mode door position.

Mode Door PositionVoltage
VENT0.3 ± 0.15V
BI-LEVEL1.4 ± 0.4V
FLOOR2.5 ± 0.4V
MIX3.6 ± 0.4V
DEF4.7 ± 0.15V

Voltage value of AQS sensor as a function of position of operating condition.

Operating conditionVoltageNote
Right after IGN "ON"2.5V ± 0.3VStay at Pre-Position
Normal4.3V ± 0.3VIntake door: REC
Gas detected0.9V ± 0.3VIntake door: FRE

Preheating Time : (35 ± 2 sec.)

Scheme 55

Scheme 55: DTC Detecting Condition

Scheme 56

Scheme 56: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "AQS sensor" parameter on scantool.
  4. Is the AQS sensor normal? YES Go to Inspection and Repair procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345976-S37533513792009102300000) " procedure.

Voltage value of AQS sensor as a function of position of operating condition.

Operating conditionVoltageNote
Right after IGN "ON"2.5V ± 0.3VStay at Pre-Position
Normal4.3V ± 0.3VIntake door: REC
Gas detected0.9V ± 0.3VIntake door: FRE

Preheating Time : (35 ± 2 sec.)

Voltage value of AQS sensor as a function of position of operating condition.

Operating conditionVoltageNote
Right after IGN "ON"2.5V ± 0.3VStay at Pre-Position
Normal4.3V ± 0.3VIntake door: REC
Gas detected0.9V ± 0.3VIntake door: FRE

Preheating Time : (35 ± 2 sec.)

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
COOL1.18 ± 0.15V
WARM3.82 ± 0.15V

Scheme 57

Scheme 57: DTC Detecting Condition

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
COOL1.18 ± 0.15V
WARM3.82 ± 0.15V

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
COOL1.18 ± 0.15V
WARM3.82 ± 0.15V

Scheme 58

Scheme 58: DTC Detecting Condition

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
COOL1.18 ± 0.15V
WARM3.82 ± 0.15V

Voltage changes according to Console switch position

Console SwitchVoltage
COOL0.3 ± 0.15V
WARM4.7 ± 0.15V

Scheme 59

Scheme 59: DTC Detecting Condition

Scheme 60

Scheme 60: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal temperature after engine starts
  3. Check that the value of Console temperature actuator and switch is changeable according to changing direction with switch. Specification: 1. COOL Position : About below 5.5%. 2. Warm Position : About 90%.
  4. Is the value of the Console air mix switch potentiometer normal? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345976-S23414135392009102300000) " procedure. NO Go to Inspection and Repair procedure.

Voltage changes according to Console switch position

Console SwitchVoltage
COOL0.3 ± 0.15V
WARM4.7 ± 0.15V

Hz of Defogger sensor according to Humidity

(%RH)(Hz)(%RH)(Hz)
037.196034.8
2036.48034
4035.610033.2

Scheme 61

Scheme 61: DTC Detecting Condition

Scheme 62

Scheme 62: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal temperature after engine starts
  3. Select and monitor "Auto defogger humidity sensor" parameter on scantool.
  4. Is the defogger sensor normal? YES Go to Inspection and Repair procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345976-S00611799732009102300000) " procedure.

Hz of Defogger sensor according to Humidity

(%RH)(Hz)(%RH)(Hz)
037.196034.8
2036.48034
4035.610033.2

Voltage output according to Actuator position

Door positionVoltage
CLOSE (VENT, B/L)About 4.7V
FLOORAbout 3.94V
MIXAbout 3.29V
OPEN (DEF)About 1V

Scheme 63

Scheme 63: DTC Detecting Condition

Scheme 64

Scheme 64: Actuation Test
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal temperature after engine start
  3. Select and monitor "Auto defogger mode direction potentioner" parameter on current data
  4. Perform Actuation Test for "Auto Defogger Mode Door -0% (close)/50%/100% (open)" in order.
  5. Check that the value of auto defogger mode actuator is changed with performing actuation test. Specification: 0% (close) : About 90%, 50% : About 55%, 100% (open): About 20%.
  6. Does the value of auto defogger mode actuator follow the specification? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345976-S13814708132009102300000) " procedure. NO Go to Inspection/Repair procedure.

Voltage output according to Actuator position

Door positionVoltage
CLOSE (VENT, B/L)About 4.7V
FLOORAbout 3.94V
MIXAbout 3.29V
OPEN (DEF)About 1V

The voltage of auto defogger mode actuator in accordance with position

Door positionVoltage
CLOSE (VENT, B/L)About 4.7V
FLOORAbout 3.94V
MIXAbout 3.29V
OPEN (DEF)About 1V

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3 ± 0.15V
Max. warm4.7 ± 0.15V

Voltage value of Intake potentiometer as a function of position of Intake door

Door positionVoltage
FRE0.3 ± 0.15V
REC4.7 ± 0.15V

Voltage value of potentiometer as a function of mode door position.

Mode Door PositionVoltage
VENT0.3 ± 0.15V
BI-LEVEL1.4 ± 0.4V
FLOOR2.5 ± 0.4V
MIX3.6 ± 0.4V
DEF4.7 ± 0.15V

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3 ± 0.15V
Max. warm4.7 ± 0.15V

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
COOL1.18 ± 0.15V
WARM3.82 ± 0.15V

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
COOL0.3 ± 0.15V
WARM4.7 ± 0.15V
