OBD-II system readiness tests

1. Catalyst monitoring The catalyst efficiency monitor is a self-test strategy within the ECM or PCM that uses the downstream Heated Oxygen Sensor (HO2S) to determine when a catalyst has fallen below the minimum level of effectiveness in its ability to control exhaust emission.
2. Misfire monitoring Misfire is defined as the lack of proper combustion in the cylinder due to the absence of spark, poor fuel metering, or poor compression. Any combustion that does not occur within the cylinder at the proper time is also a misfire. The misfire detection monitor detects fuel, ignition or mechanically induced misfires. The intent is to protect the catalyst from permanent damage and to alert the customer of an emission failure or an inspection maintenance failure by illuminating the MIL. When a misfire is detected, special software called freeze frame data is enabled. The freeze frame data captures the operational state of the vehicle when a fault is detected from misfire detection monitor strategy.
3. Fuel system monitoring The fuel system monitor is a self-test strategy within the ECM or PCM that monitors the adaptive fuel table The fuel control system uses the adaptive fuel table to compensate for normal variability of the fuel system components caused by wear or aging. During normal vehicle operation, if the fuel system appears biased lean or rich, the adaptive value table will shift the fuel delivery calculations to remove bias.
4. Engine cooling system monitoring The cooling system monitoring is a self-test strategy within the ECM or PCM that monitors ECTS (Engine Coolant Temperature Sensor) and thermostat about circuit continuity, output range, rationality faults.
5. O2 sensor monitoring OBD-II regulations require monitoring of the upstream Heated O2 Sensor (H2OS) to detect if the deterioration of the sensor has exceeded thresholds. An additional HO2S is located downstream of the Warm-Up Three Way Catalytic Converter (WU-TWC) to determine the efficiency of the catalyst. Although the downstream H2OS is similar to the type used for fuel control, it functions differently. The downstream HO2S is monitored to determine if a voltage is generated. That voltage is compared to a calibrated acceptable range.
6. Evaporative emission system monitoring The EVAP. monitoring is a self-test strategy within the ECM or PCM that tests the integrity of the EVAP. system. The complete evaporative system detects a leak or leaks that cumulatively are greater than or equal to a leak caused by a 0.040 inch and 0.020 inch diameter orifice.
7. Air conditioning system monitoring The A/C system monitoring is a self-test strategy within the ECM or PCM that monitors malfunction of all A/C system components at A/C ON.
8. Comprehensive components monitoring The comprehensive components monitoring is a self-test strategy within the ECM or PCM that detects fault of any electronic powertrain components or system that provides input to the ECM or PCM and is not exclusively an input to any other OBD-II monitor.
9. A/C system component monitoring

Requirement

If a vehicle incorporates an engine control strategy that alters off idle fuel and/or spark control when the A/C system is on, the OBD II system shall monitor all electronic air conditioning system components for malfunctions that cause the system to fail to invoke the alternate control while the A/C system is on or cause the system to invoke the alternate control while the A/C system is off.

Additionally, the OBD II system shall monitor for malfunction all electronic air conditioning system components that are used as part of the diagnostic strategy for any other monitored system or component.

Implementation plan

No engine control strategy incorporated that alters off idle fuel and/or spark control when A/C system is on. Malfunction of A/C system components is not used as a part of the diagnostic strategy for other monitored system or component.

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Connector [CTG-A]

ECM CONNECTOR CTG-A REFERENCE CHART

Connector [CTG-K]

ECM CONNECTOR CTG-K REFERENCE CHART

ECM CONNECTOR CTG-A REFERENCE CHART

ECM CONNECTOR CTG-K REFERENCE CHART

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

VIN programming procedure

VIN (Vehicle Identification Number) is a number that has the vehicle's information (Maker, Vehicle Type, Vehicle Line/Series, Body Type, Engine Type, Transmission Type, Model Year, Plant Location and so forth. For more information, please refer to the VIN. ). When replacing an ECM, the VIN must be programmed in the ECM. If there is no VIN in ECM memory, the fault code (DTC P0630) is set.

Scheme 125

Scheme 126

1. Select "VIN Writing" function in "Vehicle S/W Management".
2. Select "Write VIN" in "ID Resister".
3. Input the VIN. WARNING: Before inputting the VIN, confirm the VIN again because the programmed VIN cannot be changed.
4. Turn the ignition switch OFF, then back ON.

Fail-safe mode

FAIL-SAFE MODE REFERENCE CHART

Note. When throttle value is stuck at 5°, engine speed is limited at below 1,500rpm and vehicle speed at maximum 40 ~ 50 km/h (25 ~ 31mph).

Throttle position sensor (TPS)

1. Connect the GDS on the Data Link Connector (DLC).
2. Start engine and check output voltages of TPS 1 and 2 at C.T and W.O.T. Specification: Refer to «SPECIFICATION»(ref-417731-S13022555622011083000000) Section.
3. Turn ignition switch OFF and disconnect the GDS from the DLC.
4. Disconnect ETC module connector and measure resistance between ETC module terminals 1 and 2. Specification: Refer to «SPECIFICATION»(ref-417731-S13022555622011083000000) Section.

ETC motor

1. Disconnect ETC module connector and measure resistance between ETC module terminals 3 and 6. Specification: Refer to «SPECIFICATION»(ref-417731-S13022555622011083000000) Section.

ETC system initialization

When ignition switch is turned from OFF to ON, ETC system learns the throttle angle in 1 sec.

1. Throttle valve moves from limp-home position to close position.
2. And then, it opens to about 15° and moves to limp-home position.

Scheme 127

Scheme 128

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Remove the air duct (A), the air cleaner upper cover (B) and the air intake hose (C).
3. Disconnect the ETC module connector (A).
4. Disconnect the coolant hose (B).
5. Remove the installation bolts, and then remove the ETC module (C) from the engine.
