Special Service Tools
SPECIAL SERVICE TOOLS DESCRIPTION CHART Tool (Number and name) Illustration Use Crankshaft front oil seal installer (09231-2J300) (09231-H1100) Installation of the front oil seal Ring gear (09231-2B100) Removal and installation of the crankshaft pulley Torque angle adapter (09221-4A000) Installation of bolts & nuts needing an angular method Valve stem seal installer (09222-28200) Installation of the valve stem seal Valve spring compressor & holder (09222-3K000) (09222-3C300) Removal and installation of the intake or exhaust valves A: 09222-3K000 B: 09222-3C300 (holder) Crankshaft rear oil seal installer (09231-2J400) (09231-H1100) Installation of the crankshaft rear oil seal Oil pan remover (09215-3C000) Removal of oil pan Oil seal installer (09231-2J500) (09231-H1100) Installation of the cylinder head cover oil seal & timing chain upper cover oil seal. Timing chain locking tool (09231-2J600) Holds the timing chain with timing chain guide & timing chain tensioner arm during installation
