Electronic Stability Control (Esc) System Components: Adjustments Hyundai Equus II

Calibration (Setting up the zero angle)

Steering Wheel Angle Sensor of a absolute angle type (CAN type) measures the angle under the standard of the zero angle set

Calibration must be performed as following cases.

1. Replacement of the Steering Wheel Angle Sensor
2. Replacement or repair of the Steering column
3. Detection of DTC codes (C1260, C1261)
4. Replacement of the sensor cluster
5. Replacement of HECU

Calibration Procedure

Perform wheel alignment and stand the steering wheel in a line within ±3°error.

Scheme 27

1. Connect the GDS. (CAN line or OBD connector)
2. Turn ignition switch on.
3. Press calibration button of the Steering Wheel Angle Sensor.
4. HECU calibration procedure is performed. (Calibration records, DTC codes erasure)
5. Turn ignition switch off after calibration procedure.
6. Confirm success or failure of calibration. Warning lamp must not be lighted when driving test (Turning left and right). The ESC system will light the ESC OFF warning lamp when system detects a sensor error.
