Electronic Stability Control (Esc) System Components: Specifications Hyundai Equus II

Anti-Lock/traction Control 3 illustrations

Specifications

DescriptionSpecificationRemarks
Operating voltage8 ~ 16V
Current ConsumptionMax. 250mA
Operating temperature40 ~ 85°C
Yaw-rate sensor Measurement range75 ~ 75°/sec
Lateral G sensor Measurement range1.7gN ~ +1.7gN

LATERAL G SENSOR SPECIFICATIONS CHART

Scheme 1

Scheme 1: External Diagram
Scheme 1: External Diagram

Scheme 2

Scheme 2: Replacement
Scheme 2: Replacement
  1. Turn ignition switch OFF and disconnect the negative (-) battery cable
  2. Remove the floor console. (Refer to the «CONSOLE»(ref-417751-S12034632032011083000000) )
  3. Disconnect the yaw rate & lateral G sensor connector.
  4. Remove the mounting bolts (A). Tightening torque: 6.9 ~ 8.8 N.m (0.7 ~ 0.9 kgf.m, 5.1 ~ 6.5 Ib-ft)
  5. Installation is the reverse of removal.

Specification

DescriptionSpecification
Operating voltage8 ~ 16V
Operating temperature40 ~ 85°C
Current consumptionMax.150mA
Measuring rangeAngle700 ~ 900°
Angular velocity0 ~ 1016°/sec

STEERING ANGLE SENSOR SPECIFICATIONS CHART

Scheme 3

Scheme 3: Circuit Diagram
Scheme 3: Circuit Diagram
