Engine Timing System: Removal & Installation Hyundai Equus II

Mechanical 23 illustrations ~548 words

Removal

Engine removal is required for this procedure.

CAUTIONUse fender covers to avoid damaging painted surfaces. To avoid damage, unplug the wiring connectors carefully while holding the connector portion. When handling a metal gasket, take care not to fold the gasket or damage the contact surface of the gasket. To avoid damage, unplug the wiring connectors carefully while holding the connector portion.

Note. Mark all wiring and hoses to avoid misconnection. Turn the crankshaft pulley so that the No. 1 piston is at top dead center.

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58
  1. Remove the engine and transmission assembly from the vehicle. (Refer to «ENGINE AND TRANSMISSION ASSEMBLY»(ref-417713) in this group)
  2. Remove the cylinder head assembly. (Refer to «CYLINDER HEAD ASSEMBLY»(ref-417715) in this group)
  3. Remove the alternator (A).
  4. Remove the alternator bracket (A).
  5. Remove the air conditioner compressor (A). (Refer to «REMOVAL»(ref-417800-S24480767272011083000000) )
  6. Remove the drive belt idler (A).
  7. Remove the drive belt tensioner (A).
  8. Remove the water pump pulley (A).
  9. Remove the oil filter & cooler assembly (B).
  10. Remove the lower oil pan(A). Insert the blade of SST(09215-3C000) between the upper oil pan and the lower oil pan. Cut off applied sealer and remove the lower oil pan. NOTE: Insert the SST between the lower oil pan and the upper oil pan by tapping it with a plastic hammer in the direction of (1) arrow. After tapping the SST with a plastic hammer along the direction of (2) arrow around more than 2/3 edge of the lower oil pan, remove it from the lower oil pan. Do not use the SST as a prybar. Hold the tool in position (on the gasket line) and tap in with a light hammer. Be careful not to damage the contact surfaces of Upper oil pan and lower oil pan.
  11. Remove the upper oil pan (A). Insert the blade of SST(09215-3C000) between the upper oil pan and the cylinder block. Cut off applied sealer and remove upper oil pan. NOTE: Insert the SST between the upper oil pan and the cylinder block by tapping it with a plastic hammer in the direction of (1) arrow. After tapping the SST with a plastic hammer along the direction of (2) arrow around more than 2/3 edge of the upper oil pan, remove it from the upper oil pan. Do not use the SST as a prybar. Hold the tool in position (on the gasket line) and tap in with a light hammer. Be careful not to damage the contact surfaces of Upper oil pan and cylinder block.
  12. Remove the crankshaft pulley (A). NOTE: Use the SST (ring gear stopper, 09231-2B100) to remove the crankshaft pulley bolt, after remove the starter.
  13. Remove the front oil seal (A).
  14. Remove the water pump (A).
  15. Remove the water temperature control assembly (A).
  16. Remove the O-ring (A) from the water temperature control assembly.
  17. Remove the timing chain lower cover (A).

Scheme 59

Scheme 59: [Front]
Scheme 59: [Front]

Scheme 60

Scheme 60: [Rear]
Scheme 60: [Rear]

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66
  1. 18. Remove the O-ring (A) from the timing chain cover.
  2. 19. Remove the timing chain tensioner arm (A) and the timing chain guide (B) and then remove the timing chain.
  3. 20. Insert a set pin after compressing the oil pump chain tensioner (A) and then remove the oil pump sprocket (B) and chain (C).
  4. 21. Remove the crankshaft sprocket (A) and friction plates (B).
  5. 22. Remove the tensioner adapter (A) and the timing chain guide bolts (B).
