Automatic Transaxle System (A4CF2): Removal & Installation Hyundai Elantra IV

REPLACEMENT

If you have a fluid changer, use this changer to replace the fluid. If you do not have a fluid replace the fluid by the following procedure.

Scheme 111

1. Disconnect the hose, which connects the transmission and the oil cooler (inside the radiator).
2. Start the engine and let the fluid drain out. Running conditions: "N" range with engine idling CAUTION: The engine should be stopped within one minute after it is started. If the fluid has all drained out before then, the engine should be stopped at that point.
3. Remove the drain plug (A) from the bottom of the transmission case to drain the fluid. see scheme 21: Identifying Drain Plug
4. Install the drain plug via the gasket, and tighten it the specified torque. TORQUE: 35-45 Nm (3.5~4.5kgf.m, 25-32lb-ft)
5. Pour the new fluid in through the oil filler tube. CAUTION: Stop pouring if the full volume of fluid cannot be poured in.
6. Repeat the procedure in step ( 2 ). NOTE: Check the old fluid for contamination. If it has been contaminated, repeat the steps (5) and (6).
7. Pour the new fluid in through the oil filler tube.
8. Reconnect the hose, which was disconnected in step ( 1 ) above, and firmly replace the oil level gauge. (In case of this "replace", this means after wiping off any dirt around the oil level gauge, insert it into the filler tube.)
9. Start the engine and run it at idle for 1 -2 minutes.
10. Move the select lever through all positions, and then move it to the "N" or "P" position.
11. Drive the vehicle until the fluid temperature rises to the normal temperature (70~80°C (158~176°F)), and then check the fluid level again. The fluid level must be at the HOT mark.
12. Firmly insert the oil level gauge into the oil filler tube.

REMOVAL

Note. Mark all wiring and hoses to avoid misconnection.

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

1. Remove the engine cover (A). see scheme 145: Identifying Engine Cover
2. Remove the battery (A) after removing the battery terminal. see scheme 146: Identifying Battery
3. Remove the air duct assembly (A). (Scheme 112): Identifying Air Duct Assembly
4. Remove the air cleaner assembly (D) by disconnecting the AFS (Air Flow Sensor) connector (A), the clamp (B) and the ECM connector (C). (Scheme 113): Identifying Air Cleaner Assembly, Air Flow Sensor Connector And ECM Connector
5. Remove the battery tray (A). (Scheme 114): Identifying Battery Tray
6. Remove the ground cable from transaxle (A). (Scheme 115): Identifying Ground Cable
7. Disconnect the inhibitor switch connector (A), solenoid valve connector (B) and the input shaft speed sensor connector (C). (Scheme 116): Identifying Inhibitor Switch Connector, Solenoid Valve Connector And Input Shaft Speed Sensor Connector
8. Disconnect the output shaft speed sensor connector (A). (Scheme 117): Identifying Output Shaft Speed Sensor Connector
9. Remove the control cable assembly (A). (Scheme 118): Identifying Control Cable Assembly
10. Remove the oil cooler hoses (A). (Scheme 119): Identifying Oil Cooler Hoses
11. Install the special tools (09200-38001), the engine support fixture and the adapter on the engine assembly. (Scheme 120): Identifying Special Tools (09200-38001) And Engine Support Fixture On Engine Assembly
12. Remove the transaxle upper mounting bolts (A-2ea) and the starter motor mounting bolts (B-2ea). (Scheme 121): Identifying Transaxle Upper Mounting Bolts And Starter Motor Mounting Bolts
13. After removing the four bolts, take the transaxle support bracket (A) off. (Scheme 122): Identifying Transaxle Support Bracket Bolts
14. Remove the steering joint assembly bolt (A), (refer to «STEERING COLUMN/SHAFT»(ref-287417-S31023919302008061200000) in ST group) (Scheme 123): Identifying Steering Joint Assembly Bolt
15. Remove the front wheels and tires, (refer to «TIRES/WHEELS»(ref-287421-S13809713782008061200000) )
16. Remove the side mud cover (A). (Scheme 124): Identifying Side Mud Cover
17. Remove the under shield cover (A, B). (Scheme 125): Identifying Under Shield Cover (1 Of 2) (Scheme 126): Identifying Under Shield Cover (2 Of 2)
18. Drain the transaxle fluid by removing the oil drain plug (A). (Scheme 127): Identifying Oil Drain Plug
19. Remove the lower arm ball joint mounting nut, the stabilizer link mounting nut, and the tie rod end mounting nut from the front knuckles, (refer to «FRONT SUSPENSION SYSTEM»(ref-287426-S05999657062008061200000) in SS group)
20. Remove the roll stopper mounting bolts (A, B). (Scheme 128): Identifying Roll Stopper Mounting Bolts (1 Of 2) see scheme 164: Identifying Roll Stopper Mounting Bolts (2 Of 2)
21. Remove the muffler hanger rubber (A). (Scheme 129): Identifying Muffler Hanger Rubber
22. Supporting the sub frame (A) with a jack and the Special tool (09624-38000), remove the mounting bolts (refer to «REAR STABILIZER BAR»(ref-287427-S06240422142008061200000) ). (Scheme 130): Supporting Sub Frame With Jack And Special Tool (09624-38000)
23. Disconnect the drive shafts (A,B) from the transaxle. (Scheme 131): Identifying Drive Shaft (1 Of 2) (Scheme 132): Identifying Drive Shaft (2 Of 2)
24. Remove the drive plate mounting bolts (A-4ea). (Scheme 133): Identifying Drive Plate Mounting Bolts
25. Supporting the transaxle with a jack, remove the transaxle lower mounting bolts (A-3ea, B-2ea). (Scheme 134): Identifying Transaxle Lower Mounting Bolts
26. Lowering the jack slowly, remove the transaxle.

Scheme 137

Scheme 138

Scheme 139

Scheme 140

1. Install the transaxle lower mounting bolts (A-3ea, B-2ea) after fitting the transaxle assembly into the engine assembly. TORQUE: 43-55Nm (4.3-5.5kgf.m, 31.1-39.8lb-ft) (Scheme 135): Identifying Transaxle Lower Mounting Bolts
2. Install the drive plate mounting bolts (A-4ea). TORQUE: 46-53Nm (4.6-5.3kgf.m, 33.3-38.3lb-ft) (Scheme 136): Identifying Drive Plate Mounting Bolts
3. Connect the drive shafts (A, B) to the transaxle. see scheme 173: Identifying Drive Shaft (1 Of 2) see scheme 174: Identifying Drive Shaft (2 Of 2)
4. Supporting the sub frame (A) with a jack and the Special tool (09624-38000), install the mounting bolts, (refer to «REAR STABILIZER BAR»(ref-287427-S06240422142008061200000) ). TORQUE: 140-160Nm (14-16kgf.m, 101-118lb-ft) see scheme 175: Supporting Sub Frame With Jack And Special Tool (09624-38000)
5. Install the muffler hanger rubber (A). see scheme 176: Identifying Muffler Hanger Rubber
6. Install the roll stopper mounting bolts (A, B). TORQUE: 50-65Nm (5-6.5kgf.m, 36.2-47.0lb-ft) see scheme 177: Identifying Roll Stopper Mounting Bolts (1 Of 2) see scheme 178: Identifying Roll Stopper Mounting Bolts (2 Of 2)
7. Install the lower arm ball joint mounting nut, the stabilizer link mounting nut, and the tie rod end mounting nut to the front knuckles, (refer to «FRONT SUSPENSION SYSTEM»(ref-287426-S05999657062008061200000) in SS group)
8. Install the under shield cover (A, B). see scheme 179: Identifying Under Shield Cover (1 Of 2) see scheme 180: Identifying Under Shield Cover (2 Of 2)
9. Install the side mud cover (A). see scheme 181: Identifying Side Mud Cover
10. Install the front wheels and tires, (refer to «TIRES/WHEELS»(ref-287421-S13809713782008061200000) )
11. Install the steering joint assembly bolt (A), (refer to «STEERING COLUMN/SHAFT»(ref-287417-S31023919302008061200000) in ST group) see scheme 182: Identifying Steering Joint Assembly Bolt
12. Install the transaxle support bracket bolts (A). TORQUE: 60-80Nm (6.0-8.0kgf.m, 43.4-57.8lb-ft) (Scheme 137): Identifying Transaxle Support Bracket Bolts
13. Install the transaxle upper mounting bolts (A-2ea) the starter motor mounting bolts (B-2ea). TORQUE: [A] 60-80Nm (6.0-8.0kgf.m, 43.4-57.8lb-ft) [B] 39-60Nm (3.9-6.0kgf.m, 28.2-43.4lb-ft) see scheme 184: Identifying Transaxle Upper Mounting Bolts And Starter Motor Mounting Bolts
14. Remove the special tool (09200-38001). see scheme 185: Identifying Special Tool (09200-38001)
15. Connect the transaxle oil cooler hoses (A) to the tubes by fastening the clamps. see scheme 186: Identifying Transaxle Oil Cooler Hoses
16. Install the control cable assembly (A). see scheme 187: Identifying Control Cable Assembly
17. Install the output speed sensor connector (A). see scheme 188: Identifying Output Speed Sensor Connector
18. Connect the inhibitor switch connector (A), solenoid valve connector (B) and the input shaft speed sensor connector (C). see scheme 189: Identifying Inhibitor Switch Connector, Solenoid Valve Connector And Input Shaft Speed Sensor Connector
19. Install the ground cable (A) to transaxle. see scheme 190: Identifying Ground Cable
20. Install the battery tray (A). see scheme 191: Identifying Battery Tray
21. Install the air cleaner assembly (D) by connecting the AFS (Air Flow Sensor) connector (A), the clamp (B) and the ECM connector (C). see scheme 192: Identifying Air Cleaner Assembly, Air Flow Sensor Connector And ECM Connector
22. Install the air duct assembly (A). see scheme 193: Identifying Air Duct Assembly
23. Install the battery (A) and the battery terminal. see scheme 194: Identifying Battery
24. Install the engine cover (A). see scheme 195: Identifying Engine Cover After completing the installation perform the following procedure; Adjust the shift cable. Refill the transaxle fluid. Clean the battery posts and cable terminals with sandpaper and grease them to prevent corrosion before installing. NOTE: When replacing the automatic transaxle, reset the automatic transaxle' s values by using the High-Scan Pro. Connect the Hi-Scan Pro connector to the data link connector under the crash pad and power cable to the cigar jack under the center fascia. Turn the ignition switch on and power on the Hi-Scan Pro. Select the vehicle's name. Select 'AUTOMATIC TRANSAXLE'. see scheme 196: High-Scan Pro Display - HYUNDAI VEHICLE DIAGNOSIS Select 'RESETTING AUTO T/A VALUES' and perform the procedure see scheme 197: High-Scan Pro Display - RESETTING AUTO T/A VALUES Perform the procedure by pressing F1 (REST). (Scheme 138): High-Scan Pro Display - RESETTING AUTO T/A VALUES

INSTALLATION

1. Install the solenoid valve (B). CAUTION: Apply the ATF oil or White Vaseline to the O-ring not to be damaged. see scheme 211: Identifying VFS Solenoid Valve Connector And Solenoid Valve
2. Connect the solenoid valve connector (A). CAUTION: When connecting the solenoid valve connector, check the connector for rust, dirt, or oil, then reconnect it.
3. Install the valve body (refer to Valve Body Reassembly in overhaul) TORQUE: 10~12Nm (1.0~1.2kgf.m, 7~8lb-ft)
4. Install the oil filter. TORQUE: 5~7Nm (0.5~0.7kgf.m, 4~5lb-ft)
5. Continue to apply liquid gasket at application points at the oil pan with ø2.5mm (0.098in) thickness. Liquid gasket Part name: Threebond 1281B see scheme 212: Identifying Liquid Gasket On Oil Pan
6. Tighten the mounting bolt with the specified torque after installing the oil pan. TORQUE: 10~12Nm (1.0~1.2kgf.m, 7~8lb-ft)
7. Install the drain plug. TORQUE: 35~45Nm (3.5~4.5kgf.m, 25~32lb-ft)
8. Installation is the reverse of the removal.

1. Install the new O-ring to the input shaft speed sensor.
2. Install the input shaft speed sensor (A). TORQUE: 10~12Nm (1.0~1.2kgf.m, 7~8lb-ft) CAUTION: While installing the input shaft speed sensor, do not allow dust or other foreign particles to enter the transaxle. see scheme 216: Identifying Input Shaft Speed Sensor
3. Check the connector for dust, dirt, or oil, and then connect the input shaft speed sensor connector (A) securely. see scheme 217: Identifying Input Shaft Speed Sensor Connector
4. Installation is the reverse of removal.

1. Remove the battery terminal.
2. Remove the battery and battery tray.
3. Remove the air duct.
4. Remove the air cleaner assembly (refer to «REMOVAL»(ref-287431-S12728302022008061200000) )
5. Remove the output shaft speed sensor connector (A). see scheme 219: Identifying Output Shaft Speed Sensor Connector
6. Remove the output shaft speed sensor (A).

Identifying Valve Body Main Harness Connector. Scheme 141

1. Install the new O-ring to the output shaft speed sensor.
2. Remove the output shaft speed sensor (A). TORQUE: 10~12Nm (1.0~1.2kgf.m, 7~8lb-ft) CAUTION: While installing the output shaft speed sensor, do not allow dust or other foreign particles to enter the transaxle. see scheme 221: Identifying Output Shaft Speed Sensor
3. Check the connector for dust, dirt, or oil, then connect the output shaft speed sensor connector (A) securely. see scheme 222: Identifying Output Shaft Speed Sensor Connector
4. Installation is the reverse of removal.

1. Remove the battery terminal.
2. Lift the vehicle.
3. Remove the under cover.
4. Loosen the drain plug and drain the transaxle oil.
5. Remove the oil pan.
6. Remove the oil filter.
7. Remove the valve body (refer to Valve Body Disassembly in overhaul)
8. Disconnect the main harness connector (A) from the valve body.

1. Connect the main harness connector (A) to the valve body. CAUTION: When connecting the oil temperature connector, check the connector for rust, dirt, or oil, then reconnect it. see scheme 225: Identifying Valve Body Main Harness Connector
2. Install the valve body (refer to Valve Body Reassembly in overhaul) TORQUE: 10~12Nm (1.0~1.2kgf.m, 7~8lb-ft)
3. Install the oil filter. TORQUE: 5~7Nm (0.5~0.7kgf.m, 4~5lb-ft)
4. Continue to apply liquid gasket at application points at the oil pan with 00.098in (2.5mm) thickness. Liquid gasket Part name: Threebond 1281B see scheme 226: Identifying Liquid Gasket On Oil Pan
5. Tighten the mounting bolt with the specified TORQUE after installing the oil pan. TORQUE: 10~12Nm (1.0~1.2kgf.m, 7~8lb-ft)
6. Install the drain plug. TORQUE: 35~45Nm (3.5~4.5kgf.m, 25~32lb-ft)
7. Installation is the reverse of the removal.

1. Set the inhibitor switch to the "N" position.
2. Set the inhibitor switch control shaft to the "N" position.
3. Install the inhibitor switch and manual control lever. TORQUE Shaft nut: 17~21 Nm (1.7~2.1 kgf.m, 12~15lb-ft) Bolt (2EA): 10~12Nm (1.0~1.2kgf.m, 7~8lb-ft)
4. Install the control cable (A) to the manual control lever. see scheme 231: Identifying Control Cable
5. Connect the inhibitor switch connector (A). see scheme 232: Identifying Inhibitor Switch Connector
6. Installation is the reverse of the removal.
7. Turn the ignition switch ON after installation. Move the shift lever from "P" range to "L" range, and verify that the A/T gear position indicator follows the transaxle range switch.

Identifying Shift Lever Components (1 Of 2). Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

1. Remove the shift lever knob (A). see scheme 235: Identifying Shift Lever Knob
2. Remove the center console cover (A). see scheme 236: Identifying Center Console Cover
3. Remove the center console, (refer to «CONSOLE»(ref-287418-S20078056982008061200000) in BD group) see scheme 237: Identifying Center Console
4. Remove the control cable assembly (B) by removing the clamp (A). see scheme 238: Identifying Control Cable Assembly
5. Disconnect the interlock switch connector (A). (Scheme 143): Identifying Interlock Switch Connector
6. Remove the shift lever assembly (A). (Scheme 144): Identifying Shift Lever Assembly
7. Remove the retainer (A) and nuts (B). NOTE: In case, remove the crush pad and cowl cross bar (refer to «CRASH PAD»(ref-287418-S12947596922008061200000) and «HEATER UNIT»(ref-287428-S34529287852008061200000) ). (Scheme 145): Identifying Retainer
8. Remove the control cable assembly from the transaxle (refer to «REMOVAL»(ref-287431-S12728302022008061200000) ).
9. Remove the control cable assembly.

1. Install the control cable assembly to transaxle (refer to «INSTALLATION»(ref-287431-S24092355322008061200000) ).
2. Install the retainer (A) and nuts (B). TORQUE: 12-15Nm (1.2-1,5kgf.m, 8.7-10.8lb-ft) NOTE: In case, install the crush pad and cowl cross bar (refer to «CRASH PAD»(ref-287418-S12947596922008061200000) and «HEATER UNIT»(ref-287428-S34529287852008061200000) ). (Scheme 146): Identifying Retainer
3. Install the shift lever assembly (A). TORQUE: 9-14Nm (0.9-1.4kgf.m, 8.7-10.8lb-ft) (Scheme 147): Identifying Shift Lever Assembly
4. Connect the interlock switch connector (A). (Scheme 148): Identifying Interlock Switch Connector
5. Install the control cable assembly (B) by installing the clamp (A). (Scheme 149): Identifying Control Cable Assembly
6. Install the center console, (refer to «CONSOLE»(ref-287418-S20078056982008061200000) in BD group) (Scheme 150): Identifying Center Console
7. Install the center console cover (A). see scheme 247: Identifying Center Console Cover
8. Install the shift lever knob (A).
