Automatic Transaxle System (A4CF2): Adjustments Hyundai Elantra IV

ADJUSTMENT

1. Install the transaxle control cable and adjust as follows.
2. Move the shift lever and the transaxle range switch to the "N" Position, and install the control cable.
3. When connecting the control cable to the transaxle mounting bracket, install the clip until it contacts the control cable.
4. Remove any free-play in the control cable by adjusting nut and then check to see that the select lever moves smoothly.
5. Check to see that the control cable (A) has been adjusted correctly.

Adjusting method for the control cable

Scheme 33

1. Set room side lever and T/M side lever (A) to "N" position.
2. Connect the room side lever and shift cable, (refer to «INSTALLATION»(ref-287431-S07798271182008061200000) )
3. Connect the T/M side lever (A) to cable (B) in this following order; Push the cable (B) lightly to "F" direction shown to eliminate FREE PLAY of the cable (B). Tighten the adjusting nut (C). see scheme 249: Identifying T/M Side Lever And Cable
4. After adjusting the cable (B) according to procedure no. 2-3, check to be sure that this part operates surely at each range of T/M side corresponding to each position of room lever.
