Automatic Transaxle Diagnosis: Specifications Hyundai Accent III

Automatic Trans 31 illustrations ~1086 words

Specification

TEMP. (°C)RESISTANCE (kohms)TEMP. (°C)RESISTANCE (kohms)
40 (-40 °F)139.580 (176 °F)1.08
20 (-4 °F)47.7100 (212 °F)0.63
0 (32 °F)18.6120 (248 °F)0.38
20 (68 °F)8.1140 (284 °F)0.25
40 (104 °F)3.8160 (320 °F)0.16
60 (140 °F)1.98

TERMINAL RESISTANCE REFERENCE

Scheme 140

Scheme 140: Schematic Diagram

Scheme 141

Scheme 141: Monitor Scan Tool Data

Scheme 142

Scheme 142

Scheme 143

Scheme 143
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TRANSAXLE FLUID TEMPERATURE SENSOR" parameter on the scan tool Specification : Increasing Gradually
  4. Does "TRANSAXLE FLUID TEMPERATURE SENSOR" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S07311714372010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380338-S06152340032010121800000) " procedure
TEMP. (°C)RESISTANCE (kohms)TEMP. (°C)RESISTANCE (kohms)
40 (-40 °F)139.580 (176 °F)1.08
20 (-4 °F)47.7100 (212 °F)0.63
0 (32 °F)18.6120 (248 °F)0.38
20 (68 °F)8.1140 (284 °F)0.25
40 (104 °F)3.8160 (320 °F)0.16
60 (140 °F)1.98

TERMINAL RESISTANCE REFERENCE

Scheme 144

Scheme 144: Schematic Diagram

Scheme 145

Scheme 145: Monitor Scan Tool Data

Scheme 146

Scheme 146

Scheme 147

Scheme 147
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TRANSAXLE FLUID TEMPERATURE SENSOR" parameter on the scan tool Specification : Increasing Gradually
  4. Does "TRANSAXLE FLUID TEMPERATURE SENSOR" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S38489591542010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380338-S26010050622010121800000) " procedure
TEMP. (°C)RESISTANCE (kohms)TEMP. (°C)RESISTANCE (kohms)
40 (-40 °F)139.580 (176 °F)1.08
20 (-4 °F)47.7100 (212 °F)0.63
0 (32 °F)18.6120 (248 °F)0.38
20 (68 °F)8.1140 (284 °F)0.25
40 (104 °F)3.8160 (320 °F)0.16
60 (140 °F)1.98

TERMINAL RESISTANCE REFERENCE

Scheme 148

Scheme 148: Schematic Diagram

Scheme 149

Scheme 149: Monitor Scan Tool Data

Scheme 150

Scheme 150

Scheme 151

Scheme 151
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TRANSAXLE FLUID TEMPERATURE SENSOR" parameter on the scan tool Specification : Increasing Gradually
  4. Does "TRANSAXLE FLUID TEMPERATURE SENSOR" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S42142116242010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380338-S20083425002010121800000) " procedure

Input shaft & Output shaft speed sensor

  1. Type : Magnetic Inductive Type
  2. sensor body and sensor connector have been unified as one.

Scheme 152

Scheme 152: Schematic Diagram

Scheme 153

Scheme 153: Signal Waveform

Scheme 154

Scheme 154: Monitor Scan Tool Data

Scheme 155

Scheme 155

Scheme 156

Scheme 156

Scheme 157

Scheme 157
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "INPUT SPEED SENSOR" parameter on the scan tool
  4. Driving at speed of over 19 Mile (30 km)/h Specification : Increasing Gradually
  5. Does "INPUT SPEED SENSOR (PG-A)" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S41071190272010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380338-S05165096282010121800000) " procedure

Input shaft & Output shaft speed sensor

  1. Type : Magnetic Inductive Type
  2. sensor body and sensor connector have been unified as one.

Scheme 158

Scheme 158: Schematic Diagram

Scheme 159

Scheme 159: Signal Waveform

Scheme 160

Scheme 160: Monitor Scan Tool Data

Scheme 161

Scheme 161

Scheme 162

Scheme 162

Scheme 163

Scheme 163
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "INPUT SPEED SENSOR" parameter on the scan tool
  4. Driving at speed of over 19 Mile (30 km)/h Specification : Increasing Gradually
  5. Does "INPUT SPEED SENSOR (PG-A)" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S11407680502010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380338-S33995725202010121800000) " procedure

Input shaft & Output shaft speed sensor

  1. Type : Magnetic Inductive Type
  2. sensor body and sensor connector have been unified as one.

Scheme 164

Scheme 164: Schematic Diagram

Scheme 165

Scheme 165: Signal Waveform

Scheme 166

Scheme 166: Monitor Scan Tool Data

Scheme 167

Scheme 167

Scheme 168

Scheme 168
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "OUTPUT SPEED SENSOR (PG-B)" parameter on the scan tool
  4. Driving at speed of over 19 Mile (30 km)/h Specification : Increasing Gradually
  5. Does "OUTPUT SPEED SENSOR (PG-B)" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S17758847492010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380338-S32018157372010121800000) " procedure

Check Torque Converter Clutch Solenoid Valve

  1. Connect scan tool to data link connector (DLC)
  2. Ignition "ON" & Engine "OFF".
  3. Select A/T Solenoid valve Actuator test and perform Actuator test.
  4. Can you hear operating sound for TCC SOLENOID VALVE Actuator Testing Function? YES Go to " «CHECK OIL PRESSURE»(ref-380338-S05107329622010121800000) " as below. NO Repair or Replace as necessary and then go to "TCC SOLENOID VALVE" and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S31250165692010121800000) " procedure

Scheme 169

Scheme 169: Check Oil Pressure
  1. Connect Oil pressure gauge to "DA" port.
  2. Engine "ON".
  3. After connecting Scan Tool and monitor the "TCC SOLENOID VALVE DUTY" parameter on the Scan Tool data list.
  4. Operate vehicle with 3rd or 4th gear and operate the "TCC SOLENOID VALVE DUTY" more than 40%.
  5. Is oil pressure value within specifications? Specification : Oil pressure gauge approx 637 ~ 793 kPa (7.5 kg/cm 2 ) - (In condition that TCC SOL. DUTY > 40%) YES Repair TORQUE CONVERTER CLUTCH (REPLACE Torque Converter) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S31250165692010121800000) " procedure. NO Replace A/T ass'y (possible to BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S31250165692010121800000) " procedure.
  1. Connect scan tool to data link connector (DLC)
  2. Ignition "ON" & Engine "OFF".
  3. Select A/T Solenoid valve Actuator test and perform Actuator test.
  4. Can you hear operating sound for TCC SOLENOID VALVE Actuator Testing Function? YES Go to " «CHECK OIL PRESSURE»(ref-380338-S01080422062010121800000) " as below. NO Repair or Replace as necessary and then go to "TCC SOLENOID VALVE" and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S41092233442010121800000) " procedure

Scheme 170

Scheme 170: Check Oil Pressure
  1. Connect Oil pressure gauge to "DA" port.
  2. Engine "ON".
  3. After connecting Scan Tool and monitor the "TCC SOLENOID VALVE DUTY" parameter on the Scan Tool data list.
  4. Operate vehicle with 3rd or 4th gear and operate the "TCC SOLENOID VALVE DUTY" more than 40%.
  5. Is oil pressure value within specifications? YES Repair TORQUE CONVERTER CLUTCH (REPLACE Torque Converter) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S41092233442010121800000) " procedure. NO Replace A/T ass'y (possible to BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S41092233442010121800000) " procedure.
