Specification
| Pressure (kPa) | Output Voltage (V) |
|---|---|
| 20.0 | 0.79 |
| 46.66 | 1.84 |
| 101.32 | 4.0 |
MANIFOLD ABSOLUTE PRESSURE SENSOR SPECIFICATIONS
Scheme 21
| Temperature [°C (°F)] | Resistance (kohms) |
|---|---|
| 40 (-40) | 40.93 ~ 48.35 |
| 30 (-22) | 23.43 ~ 27.34 |
| 20 (-4) | 13.89 ~ 16.03 |
| 10 (14) | 8.50 ~ 9.71 |
| 0 (32) | 5.38 ~ 6.09 |
| 10 (50) | 3.48 ~ 3.90 |
| 20 (68) | 2.31 ~ 2.57 |
| 25 (77) | 1.90 ~ 2.10 |
| 30 (86) | 1.56 ~ 1.74 |
| 40 (104) | 1.08 ~ 1.21 |
| 60 (140) | 0.54 ~ 0.62 |
| 80 (176) | 0.29 ~ 0.34 |
INTAKE AIR TEMPERATURE SENSOR SPECIFICATIONS
Scheme 22
| Temperature [°C (°F)] | Resistance (kohms) |
|---|---|
| 40 (-40) | 48.14 |
| 20 (-4) | 14.13 ~ 16.83 |
| 0 (32) | 5.79 |
| 20 (68) | 2.31 ~ 2.59 |
| 40 (104) | 1.15 |
| 60 (140) | 0.59 |
| 80 (176) | 0.32 |
ENGINE COOLANT TEMPERATURE SENSOR SPECIFICATIONS
| Throttle Angle | Output Voltage (V) |
|---|---|
| C.T | 0.2 ~ 0.7 |
| W.O.T | Min. 4.0 |
THROTTLE POSITION SENSOR OUTPUT VOLTAGE SPECIFICATIONS
| Item | Specification |
|---|---|
| Sensor Resistance (kohms) | 1.6 ~ 2.4 (20 °C) |
THROTTLE POSITION SENSOR SPECIFICATIONS
| Item | Specification |
|---|---|
| Coil Resistance (ohms) | 774 ~ 946 (20 °C) |
CRANKSHAFT POSITION SENSOR SPECIFICATIONS
Scheme 23
This example shows a typical Crankshaft Position Sensor (CKPS) and Camshaft Position Sensor (CMPS) waveform at idle.
The PCM controls the injection and ignition timing by using these signals. Generally CKPS signal is used to detect the piston's position and CMPS signal is used to detect the Top Dead Center of each cylinder.
| Item | Specification |
|---|---|
| Capacitance (pF) | 950 ~ 1,350 |
| Resistance (mohms) | 4.87 |
KNOCK SENSOR SPECIFICATIONS
| A/F Ratio (lambda) | Output Voltage (V) |
|---|---|
| Rich | 0.6 ~ 1.0 |
| Lean | 0 ~ 0.4 |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE SPECIFICATIONS
| Item | Specification |
|---|---|
| Heater Resistance (ohms) | Approx. 9.0 (20 °C) |
HEATED OXYGEN SENSOR SPECIFICATIONS
Scheme 24
If you release the accelerator pedal suddenly after engine running about 4000 RPM, fuel supply will stop for short period and the O2 sensor service data in the Hi-Scan (Pro) will display values 200 mV or lower. When you suddenly press on the accelerator pedal down, the voltage will reach 0.6 ~ 1.0 V.
When you let the engine idle again, the voltage will fluctuate between 200 mV or lower and 0.6 ~ 1.0 V.
In this case, the O2 sensor can be determined as good.
| Pressure (kPa) | Output Voltage (V) |
|---|---|
| 6.67 | 0.5 |
| 0 | 2.5 |
| +6.67 | 4.5 |
FUEL TANK PRESSURE SENSOR OUTPUT VOLTAGE SPECIFICATIONS
Scheme 25
| Item | Specification |
|---|---|
| Coil Resistance (ohms) | 13.8 ~ 15.2 [20 °C (68 °F)] |
FUEL TANK PRESSURE SENSOR SPECIFICATIONS
| Item | Specification |
|---|---|
| Opening Coil Resistance (ohms) | 14.6 ~ 16.2 [20 °C (68 °F)] |
| Closing Coil Resistance (ohms) | 11.1 ~ 12.7 [20 °C (68 °F)] |
IDLE SPEED CONTROL ACTUATOR SPECIFICATIONS
| Duty (%) | Air Flow Rate (m 3 /h) |
|---|---|
| 15 | 0.7 ~ 1.7 |
| 35 | 6.0 ~ 11.2 |
| 70 | 30.0 ~ 42.0 |
| 96 | 45.0 ~ 55.0 |
AIR FLOW RATE SPECIFICATIONS
| Item | Specification |
|---|---|
| Coil Resistance (ohms) | 14.0 ~ 18.0 [20 °C (68 °F)] |
PURGE CONTROL SOLENOID VALVE SPECIFICATIONS
| Item | Specification |
|---|---|
| Coil Resistance (ohms) | 6.9 ~ 7.9 [20 °C (68 °F)] |
CVVT OIL CONTROL VALVE SPECIFICATIONS
| Item | Specification |
|---|---|
| Coil Resistance (ohms) | 23.0 ~ 26.0 (20 °C) |
CANISTER CLOSE VALVE SPECIFICATIONS
