Automatic Transaxle Diagnosis: Other Hyundai Accent III

Verification of Vehicle Repair

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 333

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 334

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 335

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 336

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 337

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 338

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 339

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 340

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 341

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 342

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 343

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 344

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 345

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 346

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 347

Check PCM/TCM

1. Connect scan tool to data link connector (DLC)
2. Ignition "ON" & Engine "OFF".
3. Select A/T Solenoid valve Actuator test and Operate Actuator test.
4. Can you hear operating sound for using "TCC SOLENOID VALVE" Actuator Testing Function? YES Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S07027669392010121800000) " procedure NO Replace PCM/TCM as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S07027669392010121800000) " procedure NOTE: ACTUATOR TEST CONDITION IG SWITCH ON TRANSAXLE RANGE SWITCH is normal P RANGE Vehicle Speed 0 km/h Throttle position sensor < 1 V IDLE SWITCH ON ENGINE RPM 0

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 348

1. Connect scan tool to data link connector (DLC)
2. Ignition "ON" & Engine "OFF"
3. Select A/T Solenoid valve Actuator test and Operate Actuator test.
4. Can you hear operating sound for using "PRESSURE CONTROL SOLENOID VALVE-A" Actuator Testing Function? YES Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S33255474432010121800000) " procedure NO Replace PCM/TCM as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S33255474432010121800000) " procedure NOTE: ACTUATOR TEST CONDITION IG SWITCH ON TRANSAXLE RANGE SWITCH is normal P RANGE Vehicle Speed 0 km/h Throttle position sensor < 1 V IDLE SWITCH ON ENGINE RPM 0

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 349

1. Connect scan tool to data link connector (DLC)
2. Ignition "ON" & Engine "OFF".
3. Select A/T Solenoid valve Actuator test and Operate Actuator test.
4. Can you hear operating sound for using "SHIFT CONTROL SOLENOID VALVE-A" Actuator Testing Function? YES Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S18380681842010121800000) " procedure NO Replace PCM/TCM as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S18380681842010121800000) " procedure NOTE: ACTUATOR TEST CONDITION IG SWITCH ON TRANSAXLE RANGE SWITCH is normal P RANGE Vehicle Speed 0 km/h Throttle position sensor < 1 V IDLE SWITCH ON ENGINE RPM 0

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 350

1. Connect scan tool to data link connector (DLC)
2. Ignition "ON" & Engine "OFF".
3. Select A/T Solenoid valve Actuator test and Operate Actuator test.
4. Can you hear operating sound for using "SHIFT CONTROL SOLENOID VALVE-B" Actuator Testing Function? YES Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S24018106862010121800000) " procedure NO Replace PCM/TCM as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S24018106862010121800000) " procedure NOTE: ACTUATOR TEST CONDITION IG SWITCH ON TRANSAXLE RANGE SWITCH is normal P RANGE Vehicle Speed 0 km/h Throttle position sensor < 1 V IDLE SWITCH ON ENGINE RPM 0

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 351

1. Connect scan tool to data link connector (DLC)
2. Ignition "ON" & Engine "OFF".
3. Select A/T Solenoid valve Actuator test and Operate Actuator test.
4. Can you hear operating sound for using "SHIFT CONTROL SOLENOID VALVE-C" Actuator Testing Function? YES Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S28472649332010121800000) " procedure NO Replace PCM/TCM as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S28472649332010121800000) " procedure NOTE: ACTUATOR TEST CONDITION IG SWITCH ON TRANSAXLE RANGE SWITCH is normal P RANGE Vehicle Speed 0 km/h Throttle position sensor < 1 V IDLE SWITCH ON ENGINE RPM 0

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 352

1. Connect scan tool to data link connector (DLC)
2. Ignition "ON" & Engine "OFF".
3. Select A/T Solenoid valve Actuator test and Operate Actuator test.
4. Can you hear operating sound for using "PRESSURE CONTROL SOLENOID VALVE-B" Actuator Testing Function? YES Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S40241341822010121800000) " procedure NO Replace PCM/TCM as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380338-S40241341822010121800000) " procedure NOTE: ACTUATOR TEST CONDITION IG SWITCH ON TRANSAXLE RANGE SWITCH is normal P RANGE Vehicle Speed 0 km/h Throttle position sensor < 1 V IDLE SWITCH ON ENGINE RPM 0

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 353

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 354

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 355

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
2. Using a scan tool, Clear DTC.
3. Operate the vehicle within DTC Enable conditions in General information.
4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.
