ADJUSTMENT

Operate the horn, and adjust the tone to a suitable level by turning the adjusting screw.

Note. After adjustment, apply a small amount of paint around the screw head to keep it from loosening

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Disconnect the negative (-) battery terminal.
2. Remove the 2 bolts and disconnect the airbag connector and the horn connector, then remove the airbag module. NOTE: Remove the horn pad only for vehicle without airbag.
3. Remove the steering wheel lock nut.
4. Remove the steering wheel with special tool (09561-11002) NOTE: Do not hammer on the steering wheel to remove it. Doing so may damage the collapsible mechanism.
5. Remove the steering column shroud after removing 3 screws.
6. Remove the screws holding the multi-function switch, then disconnect the wire connector. Remove the multi-function switch assembly.
7. Remove the steering column mounting bolts.
8. Remove the key lock assembly from the steering column shaft.
9. Installation is the reverse of removal.

Scheme 13

Scheme 14

1. Remove the driver's side crash pad lower panel.
2. Disconnect the ignition switch connector and the door warning switch connector under the steering column.
3. Check for continuity between the terminals.
4. If continuity is not as specified, replace the switch.

Scheme 15
