LIGHTING SWITCH INSPECTION

With the multifunction switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multifunction switch.

Scheme 16

Scheme 16: LIGHTING SWITCH INSPECTION

Scheme 17

Scheme 17: LIGHTING SWITCH (CONNECTOR NO. : M10-2)

Scheme 18

Scheme 18: DIMMER & PASSING SWITCH (CONNECTOR NO. : M10-2)

Scheme 19

Scheme 19: TURN SIGNAL SWITCH (CONNECTOR NO. : M10-2)

WIPER & WASHER SWITCH INSPECTION

With the multifunction switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multifunction switch.

Scheme 20

Scheme 20: WIPER & WASHER SWITCH INSPECTION

Scheme 21

Scheme 21: WIPER SWITCH (CONNECTOR NO. : M10-1)

Scheme 22

Scheme 22: WASHER SWITCH (CONNECTOR NO. : M10-1)

Scheme 23

Scheme 23: COMPONENTS

Scheme 24

Scheme 24: REMOVAL & INSTALLATION

Remove the bolt and disconnect the horn connector, then remove the horn.
Installation is the reverse of removal.

INSPECTION

Test the horn by connecting battery voltage to the 1 terminal and ground the 2 terminal.
The horn should make a sound. If the horn fails to make a sound, replace it.
