HVAC System: Overview Hyundai Accent II рестайлинг

OPERATION

The triple switch is a combination of a middle switch as well as conventional low pressure and high pressure switches. The low pressure switch will turn off to stop compressor operation if refrigerant pressure is low. The high pressure switch will turn off to stop compressor operation if refrigerant pressure is too high. The middle switch will it turn on at a medium level pressure to determine the A/C system is overheating. It will cool the A/C system by operating the radiator fan and the condenser fan at high speed.

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

1. Discharge the refrigerant.
2. Remove the tension bolt.
3. Remove the V-belt.
4. Remove the suction hose and discharge hose from the compressor.
5. Remove the 4 mounting bolts on the compressor.
6. Remove the compressor downwards.

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Remove the clutch hub supporting bolt using a spanner wrench.
2. Pull out the clutch hub and shim from the compressor shaft. If it is hard to pull out, insert a 8mm bolt into the shaft hole to remove the hub from the shaft.
3. Remove the pulley supporting the snap ring.
4. Remove the pulley and bearing assembly from the compressor.

Scheme 15

1. Remove the clutch hub and pulley.
2. Install a shaft protection tool at the compressor opening.
3. Install the pulley at the compressor. Place the puller screw end at the shaft protectors center concave and the puller projection around the rear side field coil.
4. Turn the puller screw using a wrench and remove the coil. CAUTION: Do not use air tools.
