Generators & Regulators: Adjustments Hyundai Accent II рестайлинг

Generator Drive Belt Adjustment

1. Loosen the generator support bolt "A" and the generator lock bolt "B". (Scheme 2)
2. Using the tension adjuster bolt, adjust belt tension to specification. See «GENERATOR BELT ADJUSTMENT SPECIFICATIONS»(ref-167604-S32449103742004101800000) table.
3. Tighten the generator lock bolt "B". See «TORQUE SPECIFICATIONS»(ref-167604-S09050272022004101800000).
4. Tighten the generator support bolt "A". See «TORQUE SPECIFICATIONS»(ref-167604-S09050272022004101800000).
5. Check the belt tension or deflection, adjust if necessary.

Scheme 2
