SPECIFICATIONS (A/T)

ItemA4AF3
Torque converter typeD3-element, 1-stage, 2-phase type
Transaxle typeD4-speed forward, 1-speed reverse
Engine displacement1.5 SOHC1.6 DOHC
Gear ratio1st2.846<
2nd1.581<
3rd1.000<
4th0.685<
Reverse2.176<
Final gear ratio3.6564.041
End play (mm)Front clutch snap ring0.5 ± 0.1
Rear clutch snap ring0.8 ± 0.1
End clutch snap ring0.5 ± 0.1
Low and reverse brake snap ring0.675~0.987

General Specifications

TIGHTENING TORQUE (A/T)

ItemN.mKg.cm
Shift lever mounting bolt12 -- 15120 -- 150
Starter motor mounting bolt27 -- 34270 -- 340
Shift lever cam rod nut14 -- 20140 -- 200
Knob and lever assemblyMore than 2More than 20
Bell housing cover to engine8 -- 1080 -- 100
Transaxle mounting bracket to body frame30 -- 40300 -- 400
Transaxle mounting insulator bolt90 -- 110900 -- 1100
Front roll stopper to subframe30 -- 40300 -- 400
Front roll stopper insulator bolt45 -- 60450 -- 600
Rear roll stopper to subframe bolt30 -- 40300 -- 400
Rear roll stopper insulator bolt45 -- 60450 -- 600
Kick down servo lock nut15 -- 22150 -- 220
Lever indicator panelMore than 15More than 150
Oil drain plug, filler plug30 -- 35300 -- 350
Transaxle range switch10 -- 12100 -- 120

Torque Specifications

Scheme 1

Scheme 1: LUBRICANT

Scheme 2

Scheme 2: SPECIAL TOOLS (A/T)

Scheme 3

Scheme 3: TROUBLESHOOTING (A/T)

Scheme 4

Scheme 4: ROAD TEST

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7: INSPECTION CHART FOR DIAGNOSTIC TROUBLE CODES

Scheme 8

Scheme 8

Scheme 9

Scheme 9: FAIL-SAFE ITEM

Scheme 10

Scheme 10: INSPECTION CHART FOR TROUBLE SYMPTOMS

Scheme 11

Scheme 11: INSPECTION PROCEDURE 1

Scheme 12

Scheme 12

Scheme 13

Scheme 13: INSPECTION PROCEDURE 2

Scheme 14

Scheme 14

Scheme 15

Scheme 15: INSPECTION PROCEDURE 3

Scheme 16

Scheme 16

Scheme 17

Scheme 17: INSPECTION PROCEDURE 4

Scheme 18

Scheme 18

Scheme 19

Scheme 19: INSPECTION PROCEDURE 5

Scheme 20

Scheme 20

Scheme 21

Scheme 21: INSPECTION PROCEDURE 6

Scheme 22

Scheme 22

Scheme 23

Scheme 23: INSPECTION PROCEDURE 7

Scheme 24

Scheme 24

Scheme 25

Scheme 25: INSPECTION PROCEDURE 8

Scheme 26

Scheme 26

Scheme 27

Scheme 27: INSPECTION PROCEDURE 9

Scheme 28

Scheme 28

Scheme 29

Scheme 29: INSPECTION PROCEDURE 10

Scheme 30

Scheme 30

Scheme 31

Scheme 31: INSPECTION PROCEDURE 11

Scheme 32

Scheme 32

Scheme 33

Scheme 33: INSPECTION PROCEDURE 12

Scheme 34

Scheme 34

Scheme 35

Scheme 35: INSPECTION PROCEDURE 13

Scheme 36

Scheme 36

Scheme 37

Scheme 37: INSPECTION PROCEDURE 14

Scheme 38

Scheme 38

Scheme 39

Scheme 39: INSPECTION PROCEDURE 15

Scheme 40

Scheme 40

Scheme 41

Scheme 41: INSPECTION PROCEDURE 16

Scheme 42

Scheme 42

STALL SPEED ABOVE SPECIFICATION IN "D"

If stall speed is higher than specification, the rear clutch or overrunning clutch of the transaxle is slipping. In this case, perform a hydraulic test to locate the cause of slippage.

STALL SPEED ABOVE SPECIFICATION IN "R"

If the stall speed is higher than specification, the front clutch of the transaxle or low-reverse brake is slipping. In this case, perform a hydraulic test to locate the cause of slippage.

STALL SPEED BELOW SPECIFICATION IN "D" & "R"

If the stall speed is lower than specification, insufficient engine output or a faulty torque converter is suspected. Check for engine misfiring, improper ignition timing, or valve clearance etc. If these are good, the torque converter is faulty.

Scheme 43

Scheme 43: TRANSAXLE FLUID LEVEL INSPECTION
  1. Drive the vehicle until the fluid reaches normal operating temperature [80-90°C (176-194°F)].
  2. Place the vehicle on a level surface.
  3. Move the selector lever through all gear positions. This will fill the torque converter and hydraulic system with fluid, then place lever in "N" (Neutral) position.
  4. Before removing the dipstick, wipe all contaminants from around the dipstick. Then take out the dipstick and check the condition of the fluid. The transaxle should be overhauled under the following conditions. If there is a "burning" door. If the fluid color has become noticeably black. If there is a noticeably excessive amount of metal particles in the fluid.
  5. Check to see if the fluid level is in the "HOT" range on dipstick. If fluid level is low, add automatic transaxle fluid until the level reaches the "HOT" range. Transaxle fluid: GENUINE DIAMOND ATF SP-III Low fluid level can cause a variety of abnormal conditions because it allows the pump to take in air along with fluid. Air trapped in the hydraulic system forms bubbles which are compressible. Therefore, pressures will be erratic, causing delayed shifting, slipping clutches and brakes, etc. Improper filling can also raise fluid level too high. When the transaxle has too much fluid, gears churn up foam and cause the same conditions which occur with low fluid level, resulting in accelerated deterioration of automatic transaxle fluid. In either case, air bubbles can cause overheating, and fluid oxidation, which can interfere with normal valve, clutch, and servo operation. Foaming can also result in fluid escaping from the transaxle vent where it may be mistaken for a leak.
  6. Be sure to examine the fluid on the dipstick closely.
