Automatic Transaxle System: Overview Hyundai Accent II рестайлинг

DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION

DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION

SELECTOR LEVER OPERATION CHECK

1. Shift the selector lever to each range and check to see that the lever moves smoothly and is controlled. Check to see that the position indicator is correct.
2. Check to be sure that the selector lever can be shifted to each position.
3. Start the engine and check to see if the vehicle moves forward when the selector lever is shifted from "N" to "D" and moves backward when shifted to "R".
4. When the shift lever malfunctions, adjust the control cable and the selector lever sleeve. Check for worn shift lever assembly sliding parts.

Scheme 44

Scheme 45

1. Place selector lever in "N" (Neutral) position.
2. Loosen the manual control lever lock nut to separate the cable and lever.
3. Place the manual control lever in the "N" (Neutral) position.
4. Turn the transaxle range switch body until the 12 mm (0.47 in.) wide end of the manual control lever aligns with the switch body flange [12 mm (0.472 in.) wide portion].
5. Tighten the attaching bolts (2 pcs.) to the specified torque. Transaxle Range Switch Attaching Bolt: 10-12 N.m (100-120 kg.cm, 7-9 lb.ft) NOTE: When setting up the switch body, be careful that the O-ring does not drop from the switch body. Tighten the attaching bolts carefully.
6. Make sure that the selector lever is in the "N" (Neutral) position.
7. Adjust the flange nut so that there is no slack in the control cable and make sure that the selector lever operates smoothly.
8. Run the vehicle and confirm that the transaxle is set in each range when the selector lever is shifted to each position.

DESCRIPTION

1. Detects the point of time when K/D band starts operation to control fluid pressure when K/D band operates.

Scheme 46

Scheme 47

Scheme 48

Scheme 49

1. Detects non-operating area of damper clutch
2. Detects turbine RPM for control of fluid pressure during a shift

Scheme 50

Scheme 51

Scheme 52

Scheme 53

1. Detects number of revolutions of the transfer driven gear to monitor vehicle speed.

Scheme 54

Scheme 55

Scheme 56

Scheme 57

1. Control fluid pressure that is acting on the shift control valve (SCV) through ON/OFF signals from the PCM to control shifting.

Scheme 58

Scheme 59

Scheme 60

Scheme 61

1. Controls fluid pressure that is acting on the shift control valve (SCV) through ON/OFF signals from the PCM to control shifting.
2. If resistance value of SCSV-B is too high or low, PO755 is output, (open or short circuit).

Scheme 62

Scheme 63

Scheme 64

Scheme 65

1. Controls fluid pressure that is acting on the control switch valve (CSV) through ON/OFF signals from the PCM to control shifting.
2. If resistance value of SCSV-C is high, P0760 is output. (open circuit).

Scheme 66

Scheme 67

Scheme 68

Scheme 69

1. Controls fluid pressure that is acting on the Pressure Control Valve-A (PCV-A) through Pulse Width Modulation signals from the PCM to control pressure during a shift.

Scheme 70

Scheme 71

Scheme 72

Scheme 73

1. Controls fluid pressure that is acting on the pressure control valve-B (PCV-B) through Pulse Width Modulation signals from the PCM to control pressure during a shift.

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. Controls fluid pressure that is acting on the damper clutch control valve through Pulse Width Modulation signals from the PCM to control the operation of the damper clutch.
2. If damper clutch solenoid drive duty continues at 100% for 4 sec. or more, there is an abnormality in the damper clutch control system at DTC P0743 is output.

Scheme 78

Scheme 79

1. If the value resulting from driving the PG-A output (input shaft rotation speed) by the 1st gear ratio does not match the PG-B output (output shaft rotation speed) after 1st gear is engaged, DTC P0731 is output.

Scheme 80

Scheme 81

Scheme 82

1. If the value resulting from driving the PG-A output (input shaft rotation speed) by the 2nd gear ratio does not match the PG-B output (output shaft rotation speed) after 2nd gear is engaged, DTC P0732 is output.

Scheme 83

Scheme 84

Scheme 85

1. If the value resulting from driving the PG-A output (input shaft rotation speed) by the 3rd gear ratio does not match the PG-B output (output shaft rotation speed) after 3rd gear is engaged, DTC P0733 is output.

Scheme 86

Scheme 87

Scheme 88

1. If the value resulting from driving the PG-A output (input shaft rotation speed) by the 4th gear ratio does not match the PG-B output (output shaft rotation speed) after 4th gear is engaged, DTC P0734 is output.

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

GENERAL INFORMATION (A4AF3)

Automatic transaxle overhaul section has been separated from the shop manual.

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

1. Remove the battery terminal and the battery.
2. Removal the air cleaner.
3. Remove the transaxle range switch connector.
4. Remove the solenoid valve connector and the oil temperature sensor connector.
5. Remove the cotter pin of the control cable.
6. Remove the oil filler tube.
7. Remove the clip of the control cable.
8. Remove the oil cooler hose.
9. Remove the speedometer driven gear connector, (speed sensor connector)
10. Remove the u-joint.
11. Remove the power steering return hose.
12. Remove the tire.
13. Remove the starter motor.
14. Remove the bolt for the upper connection of the engine and the transaxle.
15. Remove the caliper after lifting up the vehicle.
16. Separate the tie rod end from the pin and nut.
17. Remove the oil drain plug and drain the oil.
18. Remove the transaxle side cover.
19. Remove the wheel speed sensor and the knuckle mounting bolt.
20. Remove the drive shaft and the left side hub nut.
21. Install the special tool, the engine support fixture on the engine assembly.
22. Remove the transaxle mounting bracket after removing the hole cover and the mounting bolts.
23. Remove the front roll stopper.
24. Remove the rear roll stopper.
25. Remove the front muffler.
26. Remove the bell housing cover. (Bolts: 5EA)
27. Remove the torque converter mounting plate bolts (3EA).
28. Remove the cylinder block plate bolt.
29. Install the jack for supporting transaxle.
30. Remove the lower mounting bolts (2EA) of the transaxle.
31. Remove the sub frame.
32. Remove the transaxle.
