Scheme 105
Scheme 106
| Callout | Component Name |
|---|---|
| 1 | A/T Shift Lock Control Solenoid |
| 2 | Inflatable Restraint Sensing and Diagnostic Module (SDM) |
| 3 | Automatic Transmission Floor Shift Control |
Scheme 107
| Connector Part Information OEM: 12064762 Service: 12125665 Description: 6-Way F Metri-Pack 150 Series (GY) |
|---|
| Terminal Part Information Pin: A Terminal/Tray: 12047767/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A (GY) Pins: B-F Terminal/Tray: 120064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
Automatic Transmission Floor Shift Control Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | BK | 1450 | Ground |
| B | BN | 323 | Shift Solenoid Supply Voltage |
| C | YE | 1996 | Remote Shift Selector Signal |
| D-E | Not Used | ||
| F | YE | 243 | Accessory Voltage |
Automatic Transmission Floor Shift Control Connector Terminal Identification
Test Description
The numbers below refer to the step numbers on the diagnostic table.
- 2: Listen for an audible click when the automatic transmission shift lock control solenoid operates. Command both the ON and OFF states. Repeat the commands as necessary.
- 4: This step tests for ground at the control circuit of the automatic transmission shift lock control solenoid.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Shift Lock Control Schematics Connector End View Reference: Shift Lock Control Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, command the Brake to Shift Relay Output Control parameter ON and OFF. Does the automatic transmission shift lock control solenoid turn ON and OFF with each command? | Go to Testing for Intermittent Conditions and Poor Connections | Go to Step 3 |
| 3 | Turn OFF the ignition. Disconnect the automatic transmission shift lock control solenoid. Connect a test lamp between the controlled voltage circuit of the automatic transmission shift lock control solenoid at the connector of the automatic transmission shift lock control solenoid and a good ground. Turn ON the ignition, with the engine OFF. With a scan tool, command the Brake to Shift Relay Output Control parameter ON and OFF. Does the test lamp turn ON and OFF with each command? | Go to Step 4 | Go to Step 5 |
| 4 | Turn OFF the ignition. Connect a test lamp between the controlled voltage circuit and the ground circuit of the shift lock solenoid at the connector of the automatic transmission shift lock control solenoid. Turn ON the ignition, with the engine OFF. With a scan tool, command the brake to shift output control ON and OFF several times. Does the test lamp illuminate ON and OFF with each command? | Go to Step 6 | Go to Step 8 |
| 5 | Test the controlled voltage supply circuit of the automatic transmission shift lock control solenoid for an open or short to ground. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 11 | Go to Step 7 |
| 6 | Inspect for poor connections at the harness connector of the automatic transmission shift lock control solenoid. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 11 | Go to Step 9 |
| 7 | Inspect for poor connections at the harness connector of the body control module (BCM). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 11 | Go to Step 10 |
| 8 | Repair the open in the automatic transmission shift lock control solenoid ground circuit. Refer to Circuit Testing and Wiring Repairs . Did you complete the repair? | Go to Step 11 | |
| 9 | Replace the automatic transmission shift lock control solenoid. Refer to Automatic Transmission Shift Lock Actuator Replacement . Did you complete the replacement? | Go to Step 11 | |
| 10 | Replace the BCM. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | Go to Step 11 | |
| 11 | Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
DTC B2707
The numbers below refer to the step numbers on the diagnostic table.
- 2: Listen for an audible click when the automatic transmission shift lock control solenoid operates. Command both the ON and OFF states. Repeat the commands as necessary.
- 3: Tests the control circuit of the automatic transmission shift lock control solenoid.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Shift Lock Control Schematics Connector End View Reference: Shift Lock Control Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, command the brake to shift relay output control ON and OFF. Does the automatic transmission shift lock control solenoid turn ON and OFF with each command? | Go to Testing for Intermittent Conditions and Poor Connections | Go to Step 3 |
| 3 | Test the control circuit of the automatic transmission shift lock control solenoid for a short to battery voltage. Did you find and correct the condition? | Go to Step 6 | Go to Step 4 |
| 4 | Inspect for poor connections at the harness connector of the body control module (BCM). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 6 | Go to Step 5 |
| 5 | Replace the BCM. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | Go to Step 6 | |
| 6 | Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
DTC B2708
| IMPORTANT | Review the system operation in order to familiarize yourself with the system functions. Refer to Automatic Transmission Shift Lock Control Description and Operation . |
