Idle Control System: Overview Honda Ridgeline I рестайлинг

Scheme 286

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine. Hold the engine speed at 3,000 rpm without load (in P or N) until the radiator fan comes on, then let it idle for 20 seconds or more.
4. Check for these conditions in the DATA LIST with the HDS: ECT SENSOR 1 above 158°F (70°C) IAT SENSOR above 32°F (0°C) VSS is 0 mph (0 km/h) ST FUEL TRIM between 0.73 and 1.47 FSS is CLOSED
5. Monitor the OBD STATUS for DTC P0506 in the DTCs MENU with the HDS. Does the HDS indicate FAILED? YES -Go to step 6. NO -If the HDS indicates PASSED, Go to step 15 If the HDS indicates EXECUTING, keep idling until a result comes on. If the HDS indicates OUT OF CONDITION or NOT COMPLETED, go to step 4 and recheck.
6. Remove the intake air duct from the throttle body.
7. Check for dirt, carbon, or damage in the throttle bore. Is there dirt, carbon, or damage in the throttle bore? YES -If there is dirt or carbon, clean the throttle body (see «THROTTLE BODY CLEANING»(ref-336463-S24328405052009072700000) ). Also check for damage at the air cleaner element (see «AIR CLEANER ELEMENT INSPECTION/REPLACEMENT»(ref-336463-S05364324282009072700000) ), then go to step 9 If there is damage in the throttle bore, go to step 8. NO -Check the A/C system or the power steering system, then Go to step 17
8. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-336463-S20687507372009072700000) ).
9. Reset the PCM with the HDS.
10. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-336473-S09468920992009072700000) ).
11. Start the engine. Hold the engine speed at 3,000 rpm without load (in P or N) until the radiator fan comes on, then let it idle for 20 seconds or more.
12. Check for these conditions in the DATA LIST with the HDS: ECT SENSOR 1 above 158°F (70°C) IAT SENSOR above 32°F (0°C) VSS is 0 mph (0 km/h) ST FUEL TRIM between 0.73 and 1.47 FSS is CLOSED
13. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0506 indicated? YES -Go to step 1 and recheck. NO -Go to step 14.
14. Monitor the OBD STATUS for DTC P0506 in the DTCs MENU with the HDS. Does the HDS indicate PASSED? YES -Troubleshooting is complete. If any other Pending or Confirmed DTCs were indicated in step 13, go to the indicated DTC's troubleshooting. NO -If the HDS indicates FAILED, check the A/C system and/or power steering system, then Go to step 1 If the HDS indicates EXECUTING, keep idling until a result comes on. If the HDS indicates OUT OF CONDITION or NOT COMPLETED, go to step 12
15. Remove the intake air duct from the throttle body.
16. Check for dirt, carbon, or damage in the throttle bore. Is there dirt, carbon, or damage in the throttle bore? YES -If there is dirt or carbon, clean the throttle body (see «THROTTLE BODY CLEANING»(ref-336463-S24328405052009072700000) ). Also check for damage at the air cleaner element (see «AIR CLEANER ELEMENT INSPECTION/REPLACEMENT»(ref-336463-S05364324282009072700000) ), then go to step 9 If there is damage in the throttle bore, go to step 8 NO -Go to step 17.
17. Recheck with different load conditions (turn on the headlights, blower motor, rear window defogger and/or A/C, change the gear position, etc.).
18. Monitor the OBD STATUS for DTC P0506 in the DTCs MENU with the HDS.

Does the HDS indicate PASSED?

YES -Intermittent failure, the system is OK at this time.

NO -If the HDS indicates FAILED, check the A/C system and/or power steering system, then go to step 1 If the HDS indicates EXECUTING, keep idling until a result comes on. If the HDS indicates OUT OF CONDITION or NOT COMPLETED, go to step 12

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine. Hold the engine speed at 3,000 rpm without load (in P or N) until the radiator fan comes on, then let it idle.
4. Monitor the OBD STATUS for DTC P0507 in the DTCs MENU with the HDS. Does the HDS indicate FAILED? YES -Go to step 5. NO -If the HDS indicates PASSED, intermittent failure, the system is OK at this time. If the HDS indicates EXECUTING, keep idling until a result comes on. If the HDS indicates OUT OF CONDITION, recheck with different load conditions (electrical, A/C, gear position, etc.), then Go to step 3
5. Check for vacuum leaks at these parts: PCV valve PCV hose EVAP canister purge valve Throttle body Intake manifold Brake booster hose Brake booster Are there any leaks? YES -Repair or replace the leaking part(s), then Go to step 6. NO -Go to step 6.
6. Turn the ignition switch to ON (II).
7. Reset the PCM with the HDS.
8. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-336473-S09468920992009072700000) ).
9. Start the engine. Hold the engine speed at 3,000 rpm without load (in P or N) until the radiator fan comes on, then let it idle.
10. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0507 indicated? YES -Check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 NO -Go to step 11.
11. Monitor the OBD STATUS for DTC P0507 in the DTCs MENU with the HDS.

Does the HDS indicate PASSED?

YES -Troubleshooting is complete. If any other Pending or Confirmed DTCs were indicated in step 10, go to the indicated DTC's troubleshooting.

NO -If the HDS indicates FAILED, check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 If the HDS indicates EXECUTING, keep idling until a result comes on. If the HDS indicates OUT OF CONDITION, recheck with different load conditions (turn on the headlights, blower motor, or A/C; change the gear position, etc.), then Go to step 9
