DTC P2118: Throttle Actuator Current Range/Performance Problem Honda Ridgeline I рестайлинг

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ). Information marked with an asterisk (*1) applies to '09-11 models. Information marked with an asterisk (*2) applies to '12 model.

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

Scheme 332

Scheme 333

1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Slowly press the accelerator pedal to the floor.
4. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2118 indicated? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the PCM.
5. Turn the ignition switch to LOCK (0).
6. Jump the SCS line with the HDS.
7. Disconnect the throttle body 6P connector.
8. Disconnect PCM connector B (49P).
9. Check for continuity between PCM connector terminal B33 and throttle body 6P connector terminal No. 4. Is there continuity? YES -Go to step 10. NO -Repair open in the wire between the throttle body and the PCM (B33), then Go to step 18 .
10. Check for continuity between throttle body 6P connector terminals No. 5 and No. 6. Is there continuity? YES -Repair short in the wires between throttle body 6P connector terminal No. 5 (ETCS-line) and No. 6 (ETCS+ line), then Go to step 18 . NO -Go to step 11.
11. Check for continuity between body ground and throttle body 6P connector terminals No. 5 and No. 6 individually. Is there continuity? YES -Repair short in the wire between the throttle body 6P connector and body ground, then Go to step 18 . NO -Go to step 12.
12. At the throttle body side, measure the resistance between throttle body 6P connector terminals No. 5 and No. 6 with the throttle fully closed. Is there about 1.0-1.0 kohms? YES -Go to step 13. NO -Go to step 17 .
13. Disconnect PCM connector C (49P).
14. Connect throttle body 6P connector terminals No. 5 and No. 6 with a jumper wire.
15. Check for continuity between PCM connector terminals C2 and C3. Is there continuity? YES -Go to step 16. NO -Repair open in the wire between the throttle body and the PCM (C2, C3), then Go to step 18 .
16. At the throttle body side, check for continuity between body ground and throttle body 6P connector terminals No. 5 and No. 6 individually. Is there continuity? YES -Go to step 17. NO -Go to step 26 .
17. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-336463-S20687507372009072700000) ).
18. Reconnect all connectors.
19. Turn the ignition switch to ON (II).
20. Reset the PCM with the HDS.
21. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-336473-S09468920992009072700000) ).
22. Turn the ignition switch to LOCK (0).
